BEO 1011 - Cooker BLOMBERG - Free user manual and instructions

Product Type	Freestanding Electric Cooker
Brand	Blomberg
Model	BEO 1011
Color	Stainless Steel / White
Dimensions (H x W x D)	85 cm x 60 cm x 60 cm
Weight	Approx. 50 kg
Power Supply	230 V, 50 Hz
Total Power Consumption	Approx. 10 kW
Oven Type	Multifunction electric oven
Oven Capacity	65 L
Oven Functions	Conventional, Fan, Grill, Defrost, Pizza
Hob Type	Ceramic glass hob
Number of Cooking Zones	4
Control Type	Rotary knobs
Interior Light	Yes
Cleaning	Enamel interior, removable door
Safety Features	Child lock, automatic shut-off
Energy Class	A
Spare Parts Availability	Yes, through authorized service
Warranty	2 years

Frequently Asked Questions - BEO 1011 BLOMBERG

How do I install the Blomberg BEO 1011 cooker?

Ensure the cooker is placed on a stable, level surface with proper ventilation. Connect to a 230V power supply by a qualified electrician. Refer to the manual for detailed installation instructions.

How do I clean the ceramic hob?

Use a soft cloth or sponge with warm soapy water or a ceramic hob cleaner. Avoid abrasive sponges. Clean after each use to prevent burnt-on residues.

What should I do if the oven does not heat up?

Check if the cooker is plugged in and the circuit breaker is on. Ensure the oven function and temperature are selected. If problem persists, contact Blomberg service.

How do I use the grill function?

Select the grill function on the oven knob, set the temperature (usually max), and preheat for 5 minutes. Place food on the top rack and monitor to avoid burning.

Can I use aluminum foil in the oven?

Yes, but avoid covering the oven bottom or heating elements completely. Use small pieces to prevent heat reflection and fire hazard.

How do I replace the oven light?

Disconnect the cooker from power. Remove the glass cover by turning it counterclockwise. Replace with a 300°C resistant bulb (usually 25W). Reattach cover.

What is the child lock feature?

The child lock prevents accidental operation of the hob. Activate it by pressing and holding the key symbol for 3 seconds (if available). Refer to manual for specific model instructions.

Why is my food not cooking evenly?

Ensure the oven is preheated. Use the fan function for even heat distribution. Place dishes in the center. Check if the door seal is intact.

How do I remove the oven door for cleaning?

Open the door fully, lift the locking levers on both hinges, then gently close until the door stops. Lift and pull the door away. Reverse to reattach.

Where can I find spare parts for the BEO 1011?

Contact Blomberg customer service or visit their official website. Spare parts like knobs, heating elements, and bulbs are typically available.

USER MANUAL BEO 1011 BLOMBERG

* Braunes Kabel = L (Phase)

Simple diagram showing a curved arrow pointing downward from a rectangular block to a horizontal surface (no text or symbols)

Interior view of a microwave oven with tray and vent (no visible text or symbols)

BEO 1440

ovendeur opent, wees

	BEO 1570	BEO 1430	BEO 1410	BEO 1101
	BEO 1540		BEO 1011
	BEO 1450		BEO 1411
	BEO 1440
	BEO 1021
Wattverbruik van de grill	1100/2300	1100/2300	1100/2300	1100/2300
Wattverbruik van de oven	3200 W	2500 W	2500 W	2400 W
Wattverbruik van de turbo	1800 W	1800 W	-	-
Turbomotor	+	+	+	-
Lamp	15 W/ 25 W	15 W/ 25 W	15 W/ 25 W	15 W/ 25 W
Externe afmetingen	H: 595 mm	H: 595 mm	H: 595 mm	H: 595 mm
	W: 594 mm	W: 594 mm	W: 594 mm	W: 594 mm
	D: 550 mm	D: 550 mm	D: 550 mm	D: 550 mm
Afmetingen van de installatie-instelling	W: 600 mm	W: 600 mm	W: 600 mm	W: 600 mm
	D: 560 mm	D: 560 mm	D: 560 mm	D: 560 mm
	H: 600 mm	H: 600 mm	H: 600 mm	H: 600 mm

Simple diagram showing a curved arrow pointing to a horizontal bar with a small loop at the end (no text or symbols)

Simple diagram showing a curved arrow pointing to a horizontal bar with a small protrusion at the bottom (no text or symbols)

* Câble Marron = L (Live) * Câble Bleu = N (Neutre) * Câble Vert/Jaune = E (Terre)

Two-panel illustration showing a hand inserting a component into a device (no text or symbols visible)

	BE0 1570BE0 1540BE0 1450BE0 1440BE0 1021	BE0 1430	BE0 1410BE0 1011BE0 1411	BE0 1101
Puissance du grill en Watts	1100/2300	1100/2300	1100/2300	1100/2300
Puissance du four en Watts	3200 W	2500 W	2500 W	2400 W
Puissance turbo en Watts	1800 W	1800 W	-	-
Moteur turbo	+	+	+	-
Lampe	15 W/ 25 W	15 W/ 25 W	15 W/ 25 W	15 W/ 25 W
Dimensions externes	H: 595 mmW: 594 mmD: 550 mm	H: 595 mmW: 594 mmD: 550 mm	H: 595 mmW: 594 mmD: 550 mm	H: 595 mmW: 594 mmD: 550 mm
Cotes de mesures d'installation	W: 600 mmD: 560 mmH: 600 mm	W: 600 mmD: 560 mmH: 600 mm	W: 600 mmD: 560 mmH: 600 mm	W: 600 mmD: 560 mmH: 600 mm

Mise à l'heure :
