3SB188XP - Tumble dryer BALAY - Free user manual and instructions

Product Type	Condenser Tumble Dryer
Installation Type	Freestanding
Energy Class	B
Capacity (kg)	8 kg
Number of Programs	15
Dimensions (H x W x D)	85 cm x 60 cm x 60 cm
Weight	42 kg
Power Consumption (kWh/cycle)	4.5 kWh
Noise Level (dB)	65 dB
Drying System	Condenser with Heat Pump
Control Type	Electronic with LED Display
Display	Digital
Door Type	Hinged, Reversible
Delay Start	Yes, up to 24h
Anti-Crease Function	Yes
Child Lock	Yes
Self-Cleaning Condenser	Yes
Filter Indicator	Yes
Water Tank Location	Top Left
Lint Filter	Yes, in door
Warranty (years)	2
Color	White

Frequently Asked Questions - 3SB188XP BALAY

How do I clean the lint filter on my Balay 3SB188XP dryer?

Open the door and pull the lint filter upwards from the door opening. Remove lint by hand or with a soft brush. Rinse under running water if needed, then dry thoroughly before reinserting.

Why is my dryer not heating?

Check that the heating setting is not set to 'Cool' or 'Air Fluff'. Ensure the lint filter and condenser are clean. If the problem persists, the thermal fuse or heating element may need replacement.

Can I install the dryer under a counter?

Yes, this model is designed for freestanding installation but can be placed under a counter with adequate clearance for ventilation. Ensure the exhaust is not blocked.

How often should I clean the condenser?

Clean the condenser every 10-15 cycles or when the condenser indicator lights up. Remove the condenser unit from the bottom front, rinse with water, and let it dry before reinserting.

What is the maximum load capacity?

The maximum load capacity is 8 kg for cotton items. For synthetics, reduce to 4 kg. Overloading may affect drying performance and efficiency.

How do I reverse the door?

The door is reversible. Remove the door hinge screws, rotate the door 180°, and reattach on the opposite side. Refer to the manual for step-by-step instructions.

What does the 'Anti-crease' function do?

The Anti-crease function tumbles the load periodically after the cycle ends to prevent wrinkles. It can be activated via the program selector or settings menu.

Why is the dryer taking longer than usual?

Check if the lint filter or condenser is clogged. Ensure the load is not too large or too small. The room temperature may be low; increase drying time accordingly.

Can I dry wool or delicate items?

Yes, use the Delicates or Wool program (if available). Place wool items in a mesh bag and select low heat. Do not overdry.

Where can I find spare parts?

Spare parts such as filters, belts, and heating elements are available through Balay authorized service centers or online retailers. Provide the model 3SB188XP when ordering.

USER MANUAL 3SB188XP BALAY

European Union flag with twelve yellow stars on a blue background (no text or symbols)

ENERG

енергия · ενεργεια

Balay

3SB188XP

A+++

A++

A+

A

B

C

D

A++

ENERGIA · ЕНЕРГИЯ · ЕНЕРГЕІА ENERGIJA · ENERGY · ENERGIE ENERGI

233

kWh/annum

Simple line icon of a washing machine connected to an electric plug, enclosed in a rounded rectangle (no text or symbols)

Blue speaker icon with sound waves, labeled 'dB' below (no additional text or symbols)

Simple icon of a bucket with liquid and downward arrows indicating water flow (no text or symbols)

ABCDEFGHIJKLMNOPQRSTUVWXYZ

* цикъл · cyklus · portion · zyklus прóураμμα · ciclo · tsükkel ohjelma · ciklus · ciklas · cikls čiklu · cyclus · cykl · ciclu program · torkomgång
