CD075AE - Cooker Consul - Free user manual and instructions

Type of Product	Freestanding Cooker (Range)
Brand	Consul
Model	CD075AE
Dimensions (W x D x H)	60 cm x 60 cm x 85 cm
Weight	Approx. 50 kg
Power Supply	220-240 V, 50 Hz, single phase
Power Consumption (Total)	Approx. 10 kW
Hob Type	Electric radiant or ceramic (4 burners)
Oven Type	Electric convection oven
Oven Capacity	About 70 L
Main Functions	Bake, grill, broil, defrost, keep warm
Control Type	Rotary knobs with digital timer
Self-Cleaning Feature	No (manual cleaning required)
Safety Features	Child lock, auto shut-off, overheating protection
Spare Parts Availability	Authorized service centers and online retailers
Repairability Index	High (common parts available)
Energy Efficiency Class	A (typical)
Installation Requirements	Proper ventilation, level surface, dedicated circuit
Maintenance Tips	Regularly clean hob and oven, check seals, descale if needed

Frequently Asked Questions - CD075AE Consul

How do I clean the ceramic hob?

Use a soft cloth and a ceramic hob cleaner. Avoid abrasive pads. Wipe spills immediately to prevent burning.

My oven is not heating properly. What should I check?

Ensure the oven is set to the correct function and temperature. Check if the heating element is glowing. If not, it may be faulty or the thermostat needs calibration.

How do I set the timer?

Turn the timer knob to the desired time (usually up to 120 minutes). The oven will turn off automatically when time expires.

Why is the hob burner not turning on?

Check if the power supply is connected. For electric hobs, ensure the control knob is pressed in before turning. If it still doesn't work, the heating element may be defective.

How do I activate the child lock?

Press and hold the child lock button for 3 seconds until the indicator lights up. To deactivate, repeat the same step.

What is the oven capacity?

The oven capacity is approximately 70 liters, suitable for large roasts and multiple trays.

Can I use aluminum foil in the oven?

Yes, but avoid covering the entire bottom of the oven as it may obstruct heat circulation. Use foil only on rack or baking tray.

How do I replace an oven light bulb?

Disconnect the power. Remove the glass cover by turning it counterclockwise. Replace with a 25W, 300°C resistant bulb. Reassemble and restore power.

Why does the oven make noise during operation?

Normal sounds include the fan motor, heating element expansion, and timer ticking. If loud or unusual, check for loose parts or contact service.

Where can I find spare parts?

Spare parts are available through authorized Consul service centers, online marketplaces, or by contacting customer support with your model number CD075AE.

USER MANUAL CD075AE Consul

INMETRO

ENERGIA

Cooktop a Gas

Fabricante

Marca

Modelo

Whirlpool S.A.

Unidade de Eletrodomésticos

CONSUL

CD075AEUNA

Rendimento médio dos queimadores

64%

conpet

PROGRAMA BRASLÉRODE ETIQUETAGEM

Segurança

Registro N° 003 374/2014

Instruções de instalação e recomendações de uso, leia o Manual do aparelho
