| Product Type | MOSFET Driver |
| Brand | Microchip |
| Model | TC1410 |
| Package | 8-pin DIP, SOIC, or similar |
| Supply Voltage | 4.5V to 18V |
| Output Current | Up to 2A peak |
| Rise Time | 25 ns typical |
| Fall Time | 25 ns typical |
| Operating Temperature | -55°C to +125°C |
| Input Logic | TTL/CMOS compatible |
| Mounting Type | Through-hole or SMD |
| Dimensions (approx) | 9.81mm x 6.35mm (DIP) |
| Weight | Less than 1 gram |
| Power Dissipation | 800 mW (max) |
| Output Configuration | Single channel, non-inverting |
| Maintenance | No routine maintenance required |
| Safety Precautions | ESD sensitive; handle with care |
| Spare Parts | Not applicable (integrated circuit) |
| Repairability | Non-repairable; replace if faulty |
Frequently Asked Questions - TC1410 Microchip
What is the TC1410?
The TC1410 is a MOSFET driver from Microchip designed to drive high-capacitive loads with high speed.
What is the supply voltage range?
The supply voltage range is 4.5V to 18V.
What is the maximum output current?
The TC1410 can deliver up to 2A peak output current.
Is the TC1410 TTL compatible?
Yes, the input logic is TTL/CMOS compatible.
What package options are available?
The TC1410 is available in 8-pin DIP and SOIC packages.
How do I connect the TC1410 in a circuit?
Refer to the datasheet for typical application circuits. Generally, connect VDD and VSS, input signal to IN, output to the MOSFET gate with a series resistor.
Can the TC1410 operate at high temperatures?
Yes, the operating temperature range is -55°C to +125°C.
What are the typical rise and fall times?
Typical rise and fall times are 25 ns with a 1nF load.
Is the TC1410 protected against latch-up?
Yes, the device is designed to be latch-up resistant.
Where can I find the full datasheet?
The full datasheet is available on the Microchip website or from authorized distributors.
