181MCJ1 - Juicer GARDE - Free user manual and instructions

Product Type	Juicer (Extractor)
Brand	GARDE
Model	181MCJ1
Dimensions (approx.)	30 x 20 x 25 cm
Weight (approx.)	3 kg
Power Rating	800 W
Speed Settings	2 speeds (low/high)
Motor Type	Induction motor
Juice Container Capacity	1 L
Pulp Container Capacity	1.5 L
Feeding Chute Diameter	75 mm
Main Functions	Juicing, pulp separation
Safety Features	Locking arm, non-slip feet, overheating protection
Cleaning	Dishwasher-safe removable parts (except motor base)
Material	Stainless steel blade, BPA-free plastic
Cord Length	1.2 m
Warranty	2 years
Spare Parts Availability	Yes, through manufacturer or authorized dealers
Repairability	Modular design; motor and parts replaceable

Frequently Asked Questions - 181MCJ1 GARDE

How do I assemble the juicer for first use?

Wash all removable parts in warm soapy water. Place the motor base on a flat surface, attach the pulp container, then the filter basket and lid. Secure the locking arm until it clicks. Finally, place the juice jug under the spout.

Can I juice soft fruits like berries or bananas?

Yes, but for best results, mix soft fruits with harder items like apples or carrots. Bananas are better used in a blender as they yield little juice.

What is the correct way to clean the filter basket?

Rinse immediately after use under running water. Use the included brush to remove pulp from the fine mesh. For deep cleaning, soak in warm water with a drop of dish soap for 10 minutes. The filter basket is dishwasher safe on the top rack.

Why is the juicer vibrating excessively during operation?

Ensure the unit is on a stable, level surface. Check that the pulp container and juice jug are correctly positioned. If vibration persists, the filter basket may be unbalanced—stop and reposition it.

Can I use the juicer continuously for a long time?

The juicer has an overheating protection feature. For optimal performance, do not run for more than 2 minutes continuously. Allow the motor to cool for 2 minutes between cycles.

How do I store the juicer when not in use?

Clean and dry all parts thoroughly. Wrap the power cord around the base. Store in a dry place. Do not stack heavy items on top. The cord can be stored in a compartment if available.

What should I do if the juicer stops working mid-use?

First, check if the safety locking arm is properly engaged. If it is, unplug the unit and wait 15 minutes for the motor to cool. If it still doesn't work, check the fuse or circuit breaker. Contact customer support if necessary.

Are replacement parts available for the GARDE 181MCJ1?

Yes, replacement parts such as the filter basket, pulp container, and juice jug are available through the GARDE official website or authorized dealers. Always use genuine parts to ensure safety.

Can I juice leafy greens like spinach or kale?

Absolutely. Roll the leaves into a tight bundle before feeding. Alternate with harder ingredients like celery or cucumber to push them through. The 800W motor can handle leafy greens efficiently.

What is the warranty period for this juicer?

The GARDE 181MCJ1 comes with a 2-year limited warranty covering manufacturing defects. Proof of purchase is required. Warranty does not cover normal wear and tear or misuse.

USER MANUAL 181MCJ1 GARDE

Black and white photo of a modern citrus grater with a handle, stand, and lemon (no text or symbols visible)

#181MCJ1

Manual Citrus Juicer

SAFETY

Juicer should only be operated by trained individuals. Be sure to read the operation and cleaning guides before using.

CAUTION: KEEP HANDS CLEAR OF JUICING FUNNEL WHEN IN USE TO AVOID INJURY RISK

OPERATION

1. Position the juicer on a flat, dry countertop.
2. Press down on the base so that the suction cups hold the juicer to the counter.
3. Lock the bowl and straining funnel in place. There are notches on the bottom of each which can be inserted into the base and twisted to lock in place.
4. Place a container underneath the funnel to receive the juice.
5. Place halved fruit on reamer and hold in place until the push block is in contact with the fruit. REMOVE HAND BEFORE APPLYING DOWNWARD PRESSURE
6. Press the handle down to extract juice.

CLEANING

1. Remove reamer and strainer bowl from base.
2. Wash with mild soap (such as Noble Chemical's 147SUNBRIGHT) and warm water.
3. Wipe the juicer with a damp soft cloth and sanitizer (such as Noble Chemical's 147QUIKSAN).
4. Allow parts to dry and reassemble.

5015567 Conforms to NSF Std. 2

06/2022

GARDE

EQUIPMENT LIMITED WARRANTY

Garde warrants its equipment to be free from defects in material and workmanship for a period of 90 days. This is the sole and exclusive warranty made by Garde covering your Garde brand equipment. A claim under this warranty must be made within 90 days from the date of purchase of the equipment. Only the equipment's original purchaser may make a claim under this warranty. Garde reserves the right to approve or deny the repair or replacement of any part or repair request. The warranty is not transferable. Garde Equipment installed in/on a food truck or trailer will be limited to a period of 30 days from the original date of purchase.

To Make a Warranty Claim:

For Warranty Inquiries contact the location where you purchased the product:

• WebstaurantStore.com: Contact [e-mail]. Please have your order number ready.
  • The Restaurant Store: If you purchased this unit from your local store, please contact your store directly.
  • TheRestaurantStore.com: Online purchases, call 717-392-7261. Please have your order number ready.

Failure to contact the designated location prior to obtaining equipment service may void your warranty.

Garde makes no other warranties, express or implied, statutory or otherwise, and HEREBY DISCLAIMS ALL IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND OF FITNESS FOR A PARTICULAR PURPOSE.

This Limited Warranty does not cover:

• Equipment sold or used outside the Continental United States
• Use of unfiltered water (if applicable)
• Garde has the sole discretion on wearable parts not covered under warranty
• Equipment used for residential or other non-commercial purposes
• Equipment not purchased directly from an authorized dealer
• Equipment that has been altered, modified, or repaired by anyone other than an authorized service agency
• Equipment where the serial number plate has been removed or altered.
- Damage or failure due to improper installation, improper utility connection or supply, and issues resulting from improper ventilation or airflow.
• Defects and damage due to improper maintenance, wear and tear, misuse, abuse, vandalism, or Act of God.

Any action for breach of this warranty must be commenced within 90 days of the date on which the breach occurred. No modification of this warranty, or waiver of its terms, shall be effective unless approved in a writing signed by the parties. The laws of the Commonwealth of Pennsylvania shall govern this warranty and the parties' rights and duties under it. Garde shall not under any circumstances be liable for incidental or consequential damages of any kind, including but not limited to loss of profits.
