UT-PETRUS 320 - Chopper Ursus Trotter - Free user manual and instructions

Product Type	Food Chopper / Mincer
Brand	Ursus Trotter
Model	UT-PETRUS 320
Power Consumption	320 W
Voltage	AC 220-240 V ~ 50/60 Hz
Safety Class	II
Motor Unit Material	Plastic
Bowl Material	Glass
Blade Material	Stainless Steel
Bowl Capacity	Approx. 500 ml
Safety Feature	Lid interlock prevents operation if lid is incorrectly attached
Operation Method	Press motor downwards to operate; release to stop
Maximum Continuous Operation	30 seconds
Cooling Time	Allow motor to cool completely before next use (approx. 15 minutes if operated for 1 minute)
Suitable For	Chopping vegetables, garlic, meat, nuts (soft to medium hardness)
Not Suitable For	Hard ingredients like coffee beans, ice, frozen foods
Cleaning Method	Motor unit: wipe with damp cloth; bowl and lid: wash with warm soapy water; blade: rinse with clear water
Care Instructions	Do not immerse motor unit in water; avoid abrasive cleaners; handle blade carefully
Repairability	No user-serviceable parts; contact authorized service center for repairs
Included Items	Motor unit, glass bowl, transparent lid, stainless steel blade insert

Frequently Asked Questions - UT-PETRUS 320 Ursus Trotter

How long can I use the chopper continuously?

The maximum continuous operation time is 30 seconds. After that, allow the motor to cool down completely before next use.

Can I chop ice or coffee beans with this chopper?

No. The chopper is not intended for hard ingredients such as coffee beans, ice, or frozen foods. Only use it for soft to medium-hard foods.

How do I clean the blade safely?

Always wash the blade under clear water so you can see its sharp edges. Never touch the blade with your fingers. Use a brush if needed.

What should I do if the blade does not rotate?

Unplug the device. Check for any obstructions in the bowl. Ensure the blade insert is correctly attached and can rotate freely. Remove some food if overfilled.

Can I wash the motor unit in water?

No. Never immerse the motor unit in water or any liquid. Only wipe it with a damp cloth.

How can I achieve even chopping?

Cut ingredients into pieces of the same size (e.g., 20x20x15 mm) and do not overfill above the MAX mark.

Is the chopper dishwasher safe?

No. The bowl, lid, and blade should be hand washed with warm soapy water and dried completely.

What is the maximum bowl capacity?

Do not fill the bowl above the MAX mark. For reference, about 300g of meat or 200g of garlic fits.

Why won't my chopper start?

Check that the lid is correctly attached. The chopper has a safety contact that prevents operation if the lid is not properly secured.

Can I use the chopper to grind nuts?

Yes, but only in short bursts. For almonds, pack 200g and process for 20 seconds. Do not overfill or run continuously.

USER MANUAL UT-PETRUS 320 Ursus Trotter

German Engineering & Design

FLEISCHWOLF

Picadora

Product photo of a Ursus Trotter kitchen tool with colorful bell peppers and carrot on the side (no text or symbols on main objects)

MANUAL DE USUARIO Y LETRA DE GARANTÍA

▶ The motor must never come into touch with water or any other liquid.

Never immerse the device into water or any other liquid!

For the same reason, do not operate the device close to wash basin, do not operate it with humid hands and do not place it on wet ground.
▶ Before continue to operate the appliance, apply to the authorized service center for the appliance examination and repair (if required).
▶ Do not operate outdoors.
▶ Keep children away from the appliance.
▶ Never leave the appliance unattended if it is connected to the supply line!
▶ Always unplug from the wall outlet before installation/removal of the accessories, cleaning of the appliance, or in case of malfunction.
▶ Disconnect the appliance from the power supply line by holding the plug, not by pulling the power cable.
▶ Keep the appliance and the connection cord away from heat, direct sunlight humidity, sharp edges and similar.
▶ Take special care while operating the knives, as they are very sharp.
The appliance is intended for the household purposes only. The continuous time of operation should not exceed 30 seconds, afterwards the break is required until the motor is cooled down completely.

▶ Do not use the appliance in case the power cord or the plug is damaged, also in case of malfunction during the operation, if the appliance is dropped down damaged in any other way.
▶ Do not disassemble and repair the appliance by yourself, always apply to the authorized service center.
▶ Do not allow children to use the appliance without supervision. Keep the appliance and its cord out of reach of children.
▶ If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or a qualified person in order to avoid a hazard.
The appliance is not be used by children or person with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction. Children should be supervised to ensure that they do not play with the appliance.

Before first use

Remove all packaging material and clean the container, the lids and the knife insert as described in the chapter "Cleaning".

The blades are very sharp. Wash with care. Never touch the blade with your finger.

Using the appliance

1. Take motor and lid away from the container and put the container onto a stable, dry and clean working surface.
2. Make sure that the knife insert is correctly positioned on the circle in the centre of the container.
3. Attach the lid. (device cannot be switched on if lid is attached incorrectly).
4. Put the motor onto the appliance and plug the mains plug into a socket.
5. Push the motor downwards. Once released, the motor will stop. Wait until the blades stop rotating completely.
6. Before removing the motor always disconnect the device from power supply plug.
7. Before emptying the container, first remove the blade insert.

Function Instruction

1. Minced garlics:

Remove the skin of garlics, packing 200g garlics in the glass bowl, cover the transparent lid, working for 20 seconds.

2. Minced pork:

Cut pork into pieces(about 20×20 mm×15mm ), packing 300g in the glass bowl, cover the transparent lid , working for 20 seconds.

3. Minced carrots:

Cut carrots into pieces (about 20x20 x15mm), packing 200g in the glass bowl, cover the transparent lid, working for 10 seconds.

1. Minced almonds or other nuts. Packing 200g almonds in the glass bowl, cover the transparent lid, working for 20 seconds.

Note:

Wet or soft food can be processed best by pressing briefly several times onto the motor.

The mixer operates extremely quickly and some types of food are crushed within a second. The mixer is designed for short intervals of use (maximally 1 minute). If your need to work with the mixer for a longer time, switch it off after one minute of operation and let it cool down for 15 minutes.

Tips of Using your Chopper

▶ The device has a safety contact preventing the device from switching on if the lid is not attached correctly.

The mixer is not intended for crushing hard ingredients, such as coffee beans, ice or frozen foods.

▶ Before putting foods into mixer, always attach the blade insert first.

▶ If the blade insert does not rotate or if it rotates hardly, unplug the power cord from power socket.

▶ Check if there is any obstacle inside the container and remove it if it is the case.

▶ Check if the blade insert is attached correctly and can rotate freely.

▶ If the blade insert does not reach its full rotation speed with in several seconds, unplug the device from power socket and before resuming to work, remove some of the foods from the container.

▶ If any humid foods remain attached to the container walls, scrape them away using spoon or similar object back to the centre of the container.

▶ Never use your fingers to do so!

▶ To achieve even crushing of foods, fill in pieces of the same size and do not overfill the container above the MAX sign.
▶ If you wish to fine-crush the ingredients to a mash, they must be boiled previously.
▶ Do not overfill the container.
▶ Do not switch the device on if the container is empty.

Cleaning

▶ Disconnect the motor block from the wall outlet before cleaning.
▶ Wipe the motor block with damp cloth. It is forbidden to immerse the motor block into the water or any other liquids.
▶ Do not use abrasive cleansers or the sponge with rough surface for cleaning.
▶ After using the chopper wash the chopper bowl and lids in the warm soapy water, rinse and leave until the complete dry out. Afterwards assemble the appliance. Remember, the remnants of the water could cause the mould. After processing the foodstuff containing the strong dye-stuffs (for example. carrot or beat root) the plastic parts of the appliance could be colored; you can remove the color by the cloth damped with the vegetable oil.

Cleaning the knife insert

Be careful - blades are sharp!

To preclude possible injuries, use clear water while washing the device. Like that, you can always see the blade.

Technical Data

Model: UT-PETRUS320

Rated Voltage: AC 220-240V

Rated Frequency: 50/60Hz

Rated Power Input: 320W

Safety class: II

POLIZA DE GARANTIA

Stylized emblem featuring a central eagle with a shield and wings, enclosed in a laurel wreath (no text or symbols)

Ursus Trotter
