5300 - Pressure washer Gerni - Free user manual and instructions
Find the device manual for free 5300 Gerni in PDF.
| Product Type | Pressure Washer |
| Brand | Gerni |
| Model | 5300 |
| Power Source | Electric |
| Max Pressure | 130 bar |
| Flow Rate | 500 L/h |
| Motor Power | 1800 W |
| Weight | 15 kg |
| Dimensions (L x W x H) | 400 x 300 x 600 mm |
| Hose Length | 8 m |
| Power Cable Length | 5 m |
| Noise Level | 75 dB(A) |
| Adjustable Pressure | Yes |
| Detergent Injection | Yes |
| Safety Lock Trigger | Yes |
| Water Filter | Yes |
| Maintenance | Clean filter regularly, check oil level |
| Repairability | Spare parts available online |
Frequently Asked Questions - 5300 Gerni
User questions about 5300 Gerni
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
Download the instructions for your Pressure washer in PDF format for free! Find your manual 5300 - Gerni and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. 5300 by Gerni.
USER MANUAL 5300 Gerni
GERNI Warranty Process
Our goods come with guarantees that cannot be excluded under Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
GERNI – 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175 provides the following warranty in relation to your Gerni Pressure Washer machine.
DOMESTIC WARRANTY
Definition; A machine purchased for domestic household use.
Gerni warrants that, subject to the exclusions and limitations below, the product will be free from defects in the materials and workmanship for the duration of the warranty period from the date of purchase.
2 YEAR STANDARD WARRANTY
Machines & accessories included are as follows: Gerni 3300*, 3600*, 5000*, 9000
*Subject to an additional 3 year extended warranty with online registration at www.gerni.com.au 5 YEAR STANDARD WARRANTY
Machines included are as follows: Gerni 5300*, 7000*, 7300*
*Subject to an additional 2 year extended warranty with online registration at www.gerni.com.au 2 YEAR STANDARD WARRANTY
All Gerni accessories are subject to a 2 year standard warranty, to qualify for an exchange of your product you must have proof of purchase*.
*Extended warranty is not applicable to Gerni accessories, only pressure washer machines.
GERNI Warranty Claims
Equipment defects covered by the warranty will be repaired or replaced by one of our Authorised agents within the Gerni organisation. Find your local service agent here: www.gerni.com.au
- If a fault occurs, the user must first take their pressure washer machine to the closest Gerni Authorised Agent to be diagnosed for fault. It is important that you have the pressure washer serial number accompanied with your proof of purchase receipt and a copy of your Gerni online-registration certificate to ensure your pressure washer is covered under warranty.
- If a fault is diagnosed and your machines is inside stated warranty period, then your machine will be repaired or replaced at no cost. If your machine is diagnosed faulty but your machine has fallen outside the stated warranty period, the cost of diagnosis or repair will be covered by the user.
Exclusions:
- The product has been modified, repaired, or serviced by someone other than a Gerni authorised service centre.
- The product has been used other than for the purpose to which it is designed.
- The product has been exposed to user abuse such as knocks, bumps and extreme temperatures conditions.
Gerni 1-23 LETCON DRIVE, BANGHOLME, VICTORIA, AUSTRALIA 3175.
0820
SPECIFICATIONS
VOLTAGE: 230-240V \~50Hz
POWER: 2100W
MAX. PRESSURE: 13 MPa (1885psi)
RATED PRESSURE: 12.5 MPa (1813psi)
MAX. INLET PRESSURE: 1 MPa (145 psi)
RATED FLOW: 7.5L/min
MAX. FLOW RATE: 8.3L/min
HOSE LENGTH: 9m
MAX. WATER INLET TEMP.: 40°C
IP RATING: IPX5
WEIGHT: 18kg
WARRANTY
5 Year Standard +2 Year Online Extension
Gerni 1-23 LETCON DRIVE, BANGHOLME, VICTORIA, AUSTRALIA 3175.
GPW-5300
| Using an Extension Lead |
| Always use an approved extension lead suitable for the power input of this tool. Before use, inspect the extension lead for signs of damage, wear and ageing. Replace the extension lead if damaged or defective. |
| When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not suitable for the power input of the tool or which is damaged or defective may result in a risk of fire and electric shock. |
| Residual Current Device (RCD) |
| The pressure washer must be protected by a residual current device (rated at 30mA or less). A residual current device reduces the chance of electric shock. |
| WARNING: When using mains-powered tools, basic safety precautions, including the following, should always be followed to reduce risk of fire, electric shock, personal injury and material damage. |
| Read the whole manual carefully and make sure you know how to switch the tool off in an emergency, before operating the tool. |
| Save these instructions and other documents supplied with this tool for future reference. |
| The electrical motor has been designed for 230V and 240V only. Always check that the power supply corresponds to the voltage on the rating plate. |
| Note: The supply of 230V and 240V on Germ tools are interchangeable for Australia and New Zealand.If the supply cord is damaged, it must be replaced by an electrician or a power tool repairer in order to avoid a hazard. |
| a. If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards. b. Do not let familiarity gained from frequent use of tools allow you to become complacent and c.gmore power tool safety principles. A careless action can cause severe injury within a fraction of it a second. 4. Power tool use and care. a. Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed. b. Do not use the power tool if the switch does not turn on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired. c. Disconnect the plug from the power sources and/or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally. d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users. e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool's operation. It damaged, have the power tool repaired before. Many accidents are caused by poorly maintained power tools. f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are left (likely to bind) and are easier to control. g. Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation. h. Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and grasping surfaces do not allow for safe handling and control of the tool in unspecified situations. i. Service a. Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. |
| WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.Save all warnings and instructions for future reference. The term "power tool" in the warnings refers to your main causes (corded) power tool or battery-operated (cordless) power tool.1. Work area safetya. Keep work area clean and well it. Cluttered or dark areas invite accidents.b. Not operate power tools in explosive atmospheres, such as in the presence of flammals liquids, gases or dust. Power tools create sparks which may ignite the dust or furnes.c. Keep children and bystanders away while operating a power tool. Distractions can cause you from those tools2. Electrical safetya. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any power tool. Unmodified plugs and matching outlets will reduce risk of electric shock.b. Avoid body contact with barbed or grounded surfaces, such as pipes, radiators, rangers and refrigerators. There is an increased risk of electric shock. Your body is earched or grounded.c. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase risk of electric shock.d. Do not expose the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or enlarged cords into the risk of electric shock.e. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use cord suitable for outdoor use reduces the risk of electric shock.3. Personal safetya. Stay alert, watch what you are doing and use common sense when operating a power tool. Not use a power tool while you are tired or under the influence of drugs, alcohol or medicine.A moment of intentionally while operating power tools may result in serious personal injury.b. Use preunitional starting. Ensure the switch is in the off-position before connecting power source and/or battery pack, picking up or carrying the tool. Carrying power tools with finger on the switch or energising power tools that have the switch on invites accidents.d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key letter attached to a rotating part of the power tool may result in personal injury.e. Do not overreach. Keep proper footing and balance at all times. This enables better control of power tool in unexpected situations.f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts.. Loose clothes, jewellery or long hair can be caught in moving parts. |
HOSE HOOK
TRANSPORT HANDLE
ATTRACH INPUT COUPLING
SETUP HIGH PRESSURE HOSE
ASSEMBLE SPRAY GUU
FIT AN ACCESSORY
COMPONENTS
2 X 18MM SCREW
MID PATIO CLEANER
- Variable spray adjustment.
- Suitable for brick, cement & wood.
- For cleaning horizontal surfaces.
FOAM SPRAYER
GACC-FS
cleaning.
Allowing for use of
detergent & chemicals.
• For general purpose
- For removing ingrained dirt.
- High impact rotating jet.
- Covers a larger area.
JET SPRAY NOZZLE
GACC-JSN
VARIABLE SPRAY NOZZLE
GACC-VSN
- For general purpose cleaning.
- Twist to adjust pressure.
- 15° Fan shaped spray.
0.1M
(1)
=
H2N470 OYJ QIMLY
2.X 18MIN SCREW
CONNECT TO TAP TAKE A BREAK
WARNING! High pressure jets can be dangerous if not used properly. Do not direct the jet at persons, animals, live electrical equipment or the pressure washer itself.
SYMPTOM POSSIBLE CAUSE RECOMMENDED ACTION
| SYMPTOM POSSIBLE CAUSE RECOMMENDED ACTION | ||
| Fluctuating Pressure Pump is drawing in air Check that hoses and connections are airtight | ||
| Insufficient water supply | Increase water supply at the tap, check for blockages or kinks in the hose and/or swap to a larger diameter hose | |
| Accessory nozzle dirty or blocked | Clean accessory nozzle bore as there may be a blockage from dirt or debris please use cleaning needle provided | |
| The machine stops mid-use | Incorrect mains voltage | Check that the mains voltage corresponds to the specification on the model tag |
| Thermal sensor activated Leave pressure washer for 5 minutes to cool down | ||
| Nozzle partially blocked Please refer to Care & Cleaning (step 5) section of the user manual | ||
| Machine Pulsating/ inconsistent spray | Air in the inlet hose/pump | Press & hold the spray gun trigger and allow the machine to run until normal working pressure resumes |
| Kinked water hose Unwind the water hose fully | ||
| Insufficient water supply | Increase water supply at the tap, check for blockages or kinks in the hose and/or swap to a larger diameter hose. | |
| No water emitted Water filter blocked Clean the inlet filter | ||
| Blocked nozzle Use cleaning needle to clean outlet | ||
| Machine often starts and stops by itself | Spray gun may be leaking due to worn/damaged O-ring | Please contact your closest Gerni Authorised Repair Agent www.gerni.com.au |
WARNING! High pressure jets can be dangerous if not used properly. Do not direct the jet at persons, animals, live electrical equipment or the pressure washer itself.
WARNING! Perform the procedure below if taking a break for more than 5 minutes. Failure to do so may damage the pump or cause the equipment to overheat and malfunction.
STORAGE CARE & CLEANING DEFINITIONS
DISPOSAL ADVICE
NING! Ensure the tool is turned off and disconnected from the supply before performing any of the following operations.
WARNING! Ensure the tool is turned off and disconnected from the power supply before performing any of the following operations.
Drain High Pressure Use
NEED HELP?
www.gerni.com.au
customerservice@gerni.com.au
AUS 1300 162 689
NZ 0800 700 124
Read instruction manual
Double insulated
Regulatory compliance mark
Warning!
Wear eye protection
Wear gloves
Not suitable for connection to potable water mains
Warning! High pressure jets can
be dangerous if not used properly
Do not direct the jet at persons,
animals, live electrical equipment ofthe pressure washer itself
Volts
Hertz
Alternating Current
Watts
Litres per minute
Pounds per square inch
Mega Pascals
Ingress protection from water
v
Hz
\~
W
L/min
osi
Mpa
IPX5
