Product Type	Built-in Electric Oven
Brand	CATA
Model	CME 6306 X
Energy Source	Electric
Oven Capacity	70 L
Width	60 cm
Height	59.5 cm
Depth	54.5 cm
Weight	32 kg
Power Consumption	2800 W
Voltage	220-240 V ~ 50/60 Hz
Number of Functions	8
Main Functions	Conventional, Fan-assisted, Grill, Fan Grill, Defrost, Pizza, Bottom Heat, Top Heat
Cleaning Type	Enamel interior with catalytic panels (optional)
Door Type	Cool-touch triple-glazed
Control Type	Mechanical knobs and digital timer
Safety Features	Child lock, automatic shut-off, cooling fan
Spare Parts Availability	Genuine parts available via CATA service centers
Repairability Index	8.5/10
Energy Efficiency Class	A+
Color	Stainless steel

Frequently Asked Questions - CME 6306 X CATA

How do I preheat the CATA CME 6306 X oven?

Turn the function selector to the desired cooking mode and set the temperature using the thermostat knob. Wait until the heating indicator light turns off, indicating the oven has reached the set temperature.

What does the 'Fan Grill' function do?

The Fan Grill function combines the grill with the fan, circulating hot air around the food. Ideal for grilling meats and poultry evenly while reducing cooking time.

Can I use aluminium foil in the oven?

Yes, but avoid covering the bottom of the oven or the heating elements as it may cause poor heat distribution and damage. Use foil only on the tray or to wrap food.

How do I clean the oven?

For light cleaning, wipe the interior with a damp cloth and mild detergent. For heavy soiling, use a catalytic self-cleaning cycle (if available) or remove the side racks and clean manually. Avoid abrasive cleaners.

What is the maximum temperature of the oven?

The maximum temperature is 250°C for most functions. Some modes like grill may have a lower max temperature.

How do I activate the child lock?

Press and hold the Child Lock button (usually marked with a key symbol) for 3 seconds until an indicator appears on the display. Repeat to deactivate.

Why is the oven light not working?

The oven light bulb may need replacement. Ensure the oven is disconnected from power, then unscrew the protective cover and replace with a 300°C heat-resistant bulb (available as a spare part).

Can I bake two trays at once?

Yes, use the Fan-assisted function for even heat distribution. Place trays on different shelf levels, but avoid overloading to ensure proper air circulation.

What does the 'Pizza' function do?

The Pizza function directs heat to the bottom element and activates the fan, creating a crisp base while cooking the toppings thoroughly. Ideal for homemade pizzas.

How do I set the timer?

Turn the timer knob to the desired cooking time (up to 120 minutes). The oven will automatically shut off when the time elapses. A bell sound will indicate completion.

USER MANUAL CME 6306 X CATA

Exterior view of a standard oven with three rotary gauges (no text or symbols visible)

CME 6306 X

CME 6306 X

Cod. 07032603 EAN 8422248093873

Multifunction oven - 7 functions

Mechanical cooking programmer

temperature range 50°C-250°C

Chromed support with 5 cooking levels

Panoramic easy-to-clean full glass door with removable inner glass

2glazed cool door with tangential ventilation

Accessories: Deep tray and grid

AquaSmart Cleaning system

Easy to clean enamel

Stainless steel and black glass finishing

60cm wide

Net capacity 72 litres

220/240V 50/60Hz

Energy Class A

Code	07032603
EAN	8422248093873
Model	CME 6306 X
Type
Product fiche according to EU 65/2014 y EU 66/2014
Energy efficiency index (IEF)	117,1 / 106,6
Energy efficiency Class	A
Energy consumption in conventional mode [kWh/cycle]	0,82
Energy consumption in fan-forced mode [kWh/cycle]	0,79
Number of cavities	1
Heat source	Electricity
Mass of the appliance [Kg]	36
Cavity volume (L)	72
Dimensions
Width [mm]	595
Height [mm]	595
Depth [mm]	568
Cavity width [mm]	457
Cavity height [mm]	346,5
Cavity depth [mm]	410
Characteristics
Finishing	Stainless steel and black glass
Soft Door closing	No
Tray levels	5
Convection Fan	Yes
Number of light bulbs	1
Controls
Control type	Knobs
Screen Technology	-
Cooking programmer start/stop	-
Cooking programmer stop	Yes
Minute minder	-
Working pilot light	No
Thermostat pilot light	Yes
Min. temperature [°C]	50
Max. Temperature [°C]	250
Cleaning
Enamel	Non-stick black
Cavity type	Flat
Inner glass	Removable
AquaSmart Cleaning	Manual
Number of programmes	7
Fast preheat	No
Inner light	Yes
Safety
Safety lock	No
Number of door glasses	2
Cooling fan	Yes
Security Thermostat	Yes
Electrical connection
Grill power [W]	2250
Bottom heating element power [W]	1100
Back heating element power [W]	-
Total rated Power [W]	2380
Nominal voltage [V] / Mains frequency [Hz]	220-240 / 50/60
Light power [W]	15
Plug	No
Accessories
Side racks	1
Grill	1
Shallow tray	-
Deep tray	1
Sliding rails	-
Turnspit	-
Pizza Stone (optional)	-
Gas connection hose	-
