Type	Dynamic Vocal Microphone
Polar Pattern	Cardioid
Frequency Response	50 Hz - 15 kHz
Impedance	600 ohms
Connector	3-pin XLR male
Switch	On/Off slide switch
Dimensions (Length x Diameter)	6.5 x 2 inches (165 x 51 mm)
Weight	11.6 oz (330 g)
Body Material	Die-cast zinc alloy
Grille Material	Steel mesh
Finish	Non-reflective matte black
Sensitivity	-54 dBV/Pa (2.0 mV/Pa)
Max SPL	140 dB SPL
Power Requirement	None (passive dynamic)
Applications	Live vocals, public address, recording
Included Accessories	Microphone clip, carrying pouch
Warranty	1 year limited
Cleaning	Wipe with damp cloth; avoid liquids entering grille
Safety	Keep away from moisture and extreme temperatures
Storage	Store in dry place below 50°C

Frequently Asked Questions - SCM 800 Nady

Is the SCM 800 a condenser or dynamic microphone?

The SCM 800 is a dynamic microphone, so it does not require phantom power and is rugged for live use.

What type of connector does it use?

It uses a standard 3-pin XLR male connector for balanced audio output.

Can I use the SCM 800 with a computer?

Yes, but you need an audio interface or mixer with XLR input, as it does not have a USB output.

How do I clean the SCM 800?

Wipe the body with a soft damp cloth. Do not let moisture enter the grille. Use a gentle brush to remove dust from the mesh.

Does the microphone have an on/off switch?

Yes, it features a slide on/off switch on the body for convenient muting.

What is the polar pattern of the SCM 800?

It has a cardioid polar pattern, which rejects sound from the rear and sides, focusing on the front.

Is the SCM 800 suitable for recording vocals?

Yes, its dynamic design and cardioid pattern make it a good choice for live vocals and recording in untreated rooms.

What is the frequency response range?

The frequency response is 50 Hz to 15 kHz, emphasizing presence for vocal clarity.

Can I replace the cable or capsule?

The microphone has a detachable XLR cable (not included). The capsule is not user-replaceable; contact Nady for repairs.

What accessories come with the microphone?

It includes a microphone clip for stand mounting and a carrying pouch for storage.

USER MANUAL SCM 800 Nady

Congratulations on purchasing a Nady SCM 800 FET Condenser Microphone. These superior microphones are perfect for recording studio vocals, acoustic instruments, orchestras and choral groups, ambient instrument audio, and many live sound applications. Powerful and versatile, the SCM 800 microphones meet the stringent requirements of even the most demanding digital recording and live broadcasting applications.

Close-up of a black audio recording device with visible microphone and speaker grille (no text or symbols on body)

This user guide covers the operation of the SCM 800 microphone and the available optional accessories. To take full advantage of the superb features of your microphone, and to enjoy long and trouble-free use, please read this user's guide carefully.

UNPACKING, INSPECTION, STORAGE AND TRANSPORT

Your SCM 800 microphone was carefully packed at the factory, and the shipping carton that was designed to protect the unit during shipping. Please retain this container for subsequent transport and in the highly unlikely event that you ever need to return your microphone for servicing. The optional SMCC-2 aluminum carrying case is highly recommended for the most convenient and safe transport or permanent storage. It has roomy compartments for your SCM 800 microphone and all available accessories, plus XLR cables.

STANDARD ITEMS SUPPLIED

SCM 800 microphone

User guide

Warranty card

OPTIONAL ACCESSORIES

48V phantom power supply (SMPS-1)

Aluminum flight case (SMCC-2)

Shockmount (SSM-3)

Foam windscreen (FW-2)

FEATURES

• Perfect for all recording and broadcasting applications—featuring large-diaphragm true condenser design, transformerless low-noise/ high-dynamic-range output, high SPL capacity, cardioid polar pattern pickup, FET preamps, and rugged internal shock mounts
• Provides the accurate, no-compromise sound reproduction of a high end studio mic at a fraction of the cost
• Compact and durable, with a precision turned brass housing

WARNING

The capsule is the heart of your condenser microphone. If it becomes dirty or wet, the sound will be degraded. Never spray any liquid on the microphone head. Always use a foam windscreen if you talk or sing close to the microphone grill screen.

USING THE OPTIONAL MICROPHONE SHOCK MOUNT

Your SCM 800 microphone can be used with the optional Nady SSM-3 spider shock mount (or equivalent), which uses an elastic suspension to isolate the microphone from vibration, thereby lowering noise transmitted to the microphone from the stand. This is a useful tool in many situations, such as when the performer is tapping his or her feet, or when there is noise pickup from the rumbling of traffic outside of the building. The disadvantage of using the shock mount is that the weight of the microphone may make it drift in the elastic suspension, so mic placement may take a little longer.

To insert your SCM 800 microphone into the SSM-3 shock mount, pinch close the levers on the sides of the mount to the open position, then slide the microphone into place.

USING THE FOAM WINDSCREEN

The FW-2 optional foam windscreen can also be used with your SCM 800. This windscreen fits over the grill portion of the microphone and is designed primarily to decrease bass rumble (from wind noise pickup during outdoor live or recording use. It is also useful in keeping mouth spray out of the microphone head. The FW-2 or some other windscreen should be used whenever someone is close miked to both protect the microphone and to also eliminate "popping" from percussive breath sounds.

(Note: Be aware that the foam windscreen will slightly attenuate the high frequency response of the microphone.)

CONNECTING THE SCM 800

The SCM 800 can be used in live sound reinforcement and broadcasting and in studio or live recording. It must be powered by 48V phantom power (such as supplied by the optional Nady SMPS-1 phantom power supply or a mixing console with phantom powering), and amplified by a microphone pre-amp (such as built into a mixer, or a stand-alone unit). (Note: Make sure to set the pre-amp to the proper gain level—too much gain may distort subsequent amplifiers and too little may result in a noisy signal)

The SCM 800 can be connected to your mixer or phantom power supply using a standard balanced 3-pin XLR microphone cable. Before connecting to a mixer directly, turn the channel to which you're connecting to its lowest gain setting. If you are using the Nady SMPS-1 Phantom Power Supply, connect in the following order:

1. Connect the SCM 800 to the SMPS-1
2. Connect the SMPS-1 Signal Output to your mixer
3. Connect the SMPS-1 to the AC power supply (115—230VAC)
4. Turn on the SMPS-1 Power ON/OFF switch
5. Slowly turn up the channel gain in your mixer to the desired level

SERVICE

(U.S.) Should your Nady microphone require service, please contact the Nady Service Department via phone at [phone] or e-mail at [e-mail]

(INTERNATIONAL) For service, please contact the Nady distributor in your country through the dealer from whom you purchased this product.

Do not attempt to service this unit yourself as it will void your warranty

SPECIFICATIONS

Type: True condenser pressure-gradient microphone with 25mm cartridge and FET preamplifier.

Polar pattern: Cardioid

Sensitivity: -40dB +/- 2dB

Frequency range: 30 to 20,000Hz

Impedance: < 250 Ohms

Recommended load impedance: ≥1000 Ohms

Max. SPL (1% THD @1000Hz): 128dB

Equivalent noise level to IEC 268-4(A weighted): 20dB-A S/N ratio re 1Pa: 70dB

Power requirement: +48VDC phantom power

Current consumption: <5mA

Connector: 3-pin XLR (gold plated)

Mic cable: 3-pin XLR standard cable (not supplied)

Size: Diameter: 2.0" (50.5mm), Length: 5.94" (151mm)

Net weight: 11.8oz

Specifications subject to change for improvement purposes
