| Product Type | True Wireless Stereo (TWS) Earbuds |
| Model | AV-TW5003G |
| Brand | Avenzo |
| Dimensions (Earbuds) | Approx. 2.5 x 1.8 x 1.2 cm (each) |
| Weight (Earbuds) | Approx. 4 g each |
| Dimensions (Charging Case) | Approx. 6.0 x 4.5 x 2.5 cm |
| Weight (Charging Case) | Approx. 35 g |
| Power Supply | Built-in rechargeable lithium battery; charging via USB-C |
| Battery Life | Up to 4 hours (earbuds), extra 12 hours with charging case |
| Bluetooth Version | Bluetooth 5.0 |
| Wireless Range | Up to 10 meters (33 feet) |
| Main Functions | Music playback, hands-free calling, voice assistant support, touch controls |
| Microphone | Built-in omnidirectional mic |
| Water Resistance | IPX5 (sweat and splash proof) |
| Cleaning and Maintenance | Wipe with a dry, soft cloth; remove ear tips and rinse with water if needed |
| Safety | Keep away from high temperatures; do not disassemble; avoid prolonged exposure at high volume |
| Spare Parts and Repairability | Replacement ear tips available; battery not user-replaceable |
| General Information | Compatible with most Bluetooth devices; includes charging cable and user manual |
Frequently Asked Questions - AV-TW5003G Avenzo
How do I pair my Avenzo AV-TW5003G earphones with my phone?
Remove both earbuds from the charging case. They will automatically enter pairing mode. On your phone, enable Bluetooth and select Avenzo AV-TW5003G from the list.
What should I do if only one earbud is working?
Place both earbuds back in the charging case, close the lid, wait 10 seconds, then remove them again. This resets the connection. If the issue persists, perform a factory reset.
How do I reset the Avenzo AV-TW5003G earphones?
Ensure both earbuds are in the charging case. Press and hold the touch area on both earbuds for about 10 seconds until the LED flashes red twice, then release. The earphones will reset and automatically enter pairing mode.
What is the battery life of the AV-TW5003G?
Each earbud provides up to 4 hours of playtime. The charging case holds additional charges for a total of up to 16 hours.
How do I charge the earphones?
Place the earbuds in the charging case and close the lid. Connect the case to a USB-C power source. The LED on the case indicates charging status; a full charge takes about 1.5 hours.
Are the Avenzo AV-TW5003G earphones water resistant?
Yes, they have an IPX5 rating, meaning they are resistant to sweat and light rain. Do not submerge in water.
How do I control music and calls with these earphones?
Use the touch controls on each earbud: single tap to play/pause or answer/end call; double tap to skip track; triple tap to go back; long press to activate voice assistant.
Can I use only one earbud at a time?
Yes, you can use either earbud independently. Simply remove one from the case and it will connect as a mono headset.
The earphones keep disconnecting. What can I do?
Make sure there are no obstructions between the earphones and your device, and stay within 10 meters. Also, ensure the earphones have sufficient battery. Resetting the earphones may help.
How do I clean the earphones?
Use a soft, dry cloth to wipe the earbuds. Remove the ear tips and rinse them with water if needed, then dry thoroughly before reattaching. Avoid getting moisture into the charging contacts.
