Product Type	Pedestal Fan
Model	MSF403SLM (also MSF403WM)
Brand	Matsui
Blade Diameter	16 inches (approx. 40 cm)
Power Supply	230V ~ 50Hz
Rated Power	55W
Assembly	Requires manual assembly of base, pole, and fan head
Speed Settings	Multiple (not specified, typical 3)
Oscillation	Yes (typical pedestal fan feature)
Height Adjustment	Adjustable (typical pedestal fan)
Safety Features	Protective grill, automatic shut-off on tip-over (not specified, but typical), unplug before cleaning
Cleaning	Unplug, use damp cloth with mild detergent; avoid water ingress on motor and controls
Placement	Stable, level surface away from moisture and heat sources
Disposal	WEEE compliant; separate collection for recycling
Spare Parts & Accessories	Available via Partmaster.co.uk (phone [phone])
Usage	Indoor use only
Warranty	Standard (not specified, typical 1-2 years)

Frequently Asked Questions - MSF403SLM MATSUI

How do I assemble the Matsui MSF403SLM pedestal fan?

Ensure the fan is unplugged. Assemble the base, pole, and fan head according to the illustrations in the manual. Tighten all screws securely.

How do I clean my fan?

Always unplug the fan before cleaning. Use a cloth dampened with warm water and mild detergent. Avoid letting water seep into the motor or controls. Do not use harsh chemicals.

What are the power specifications?

The fan operates on 230V~50Hz and has a rated power of 55W.

Is the fan safe to use near children?

Close supervision is necessary when used near children. Do not allow children to play with the fan. Keep fingers and objects away from the grill.

Can I use the fan outdoors?

No, this fan is designed for indoor use only. Do not expose it to moisture or outdoor conditions.

What should I do if the fan falls into water?

Do not reach for the appliance. Unplug it immediately. If the fan is damaged, have it inspected by a qualified person.

How should I dispose of the fan at the end of its life?

Do not dispose of it with household waste. Follow local regulations for WEEE recycling. Contact your local authority or retailer for collection points.

Where can I get spare parts?

Visit Partmaster.co.uk or call 0870 6001 338 (UK only) for a wide range of spares and accessories. They offer next-day delivery.

What should I check if the fan doesn't work?

Ensure the fan is plugged into a working socket and the power switch is on. If it still doesn't work, check the power cord for damage and contact a qualified person for repairs.

Can I use an extension cord with the fan?

The manual does not specifically mention extension cords. For safety, avoid using extension cords if possible. If necessary, use a heavy-duty cord suitable for 55W and ensure it is not damaged.

USER MANUAL MSF403SLM MATSUI

Ensure the fan is switched off at the control switch before inserting the plug into the mains socket.

Illustration of a plug being inserted into a panel, showing the pin and cable (no text or symbols)

Diagram of a hand holding a fan blade with arrows indicating rotation or adjustment (no text or symbols)

Illustration of a hand holding a mesh fan with directional arrows indicating rotation (no text or symbols)

Cleaning

Always unplug your fan from the mains supply before attempting cleaning. Do not use harsh cleaners or solvents on the fan as they may damage the casing. The fan blade and body of the unit should be cleaned using a cloth dampened with warm water and detergent. Make sure you do not allow water to seep into the controls or motor houseing of your fan.

Line drawing of a hand holding a circular object with a mesh pattern, mounted on a pole (no text or symbols)

This symbol on the product or in the instructions means that your electrical and electronic equipment should be disposed at the end of its life separately from your household waste.

There are separate collection systems for recycling in the EU.

For more information, please contact the local authority or your retailer where you purchased the product.

Visit Partmaster.co.uk today for the easiest way to buy electrical spares and accessories.

With over 1 million spares and accessories available we can deliver direct to your door the very next day.

Visit www.partmaster.co.uk

or call

0870 6001 338

Calls charged at National Rate.

MATSUI

16" Pedestal Fan MSF403WM/SLM

Line drawing of a standard office lamp with a black mesh fan and power cord (no text or symbols)

Instruction Book

Safety first!

GB

Your fan should be used in such a way that it is protected from moisture. e.g. condensation, splashed water etc Stand your fan on a stable, level surface during use.

Do not place or store your fan where it can fall or be pulled into water or any other liquid.

Do not reach for the appliance if it has failed in any water or any other liquid. Unplug immediately.

It is DANGEROUS to insert fingers or objects into the grill. Do not allow young children to play with your fan. Close supervision is necessary when your fan is used near children.

No part of this publication may be reproduced, stored in a retrieval system or transmitted, in any form or by any means, without the prior permission in writing of Dixons Stores Group, nor be otherwise circulated in any form of binding or cover other than t hat in which is published and without a similar condition including this condition being imposed on the subsequent purchaser.

Your fan should be unplugged from the wall socket when left unused for a long time. Your fan should be placed away from heat sources such as radiators,

gas/electric fires and direct sunlight. Keep the power cord away from any heated surfaces.

Use the appliance only for its intended use, as described in this manual. Do not use outdoors.

Never use your fan if it is damaged in any way.

Do not remove any fixed covers. Never use this appliance if it is not working properly, or if it has been dropped or damaged.

If the supply cord is damaged it MUST be repaired by a qualified person.

Specifications

Power Supply.....230V\~50Hz

Rated Power.....55W

Getting to know your fan

GB

Please read these instructions and have a good look at the illustrations before using your fan.

We continually strive to improve our products, specifications may change without prior notice.

How to assemble your fan

Make sure your fan is unplugged before you attempt to assemble.

GB

Diagram of a mechanical assembly with arrows indicating force or movement (no text or symbols)

Technical line drawing of a standing fan with mesh grille and base mount (no text or symbols)

Technical illustration of a mesh fan with directional arrows indicating rotation (no text or symbols)

Technical illustration of a circular mechanical component with internal mesh structure and a magnified inset (no text or symbols)
