Product Type	Food Processor
Brand	Swan
Model	SP10120N
Power	800 W
Bowl Capacity	2.0 L
Dimensions (L x W x H)	30 x 20 x 25 cm
Weight	3.5 kg
Material	Stainless Steel Blades, Plastic Housing
Functions	Chopping, Slicing, Shredding, Mixing, Blending, Kneading
Speed Settings	2 Speeds + Pulse
Safety Features	Safety Lock Lid, Non-Slip Feet, Overload Protection
Cleaning	Dishwasher Safe Parts (Bowl, Lid, Accessories), Wipe Motor Base
Spare Parts Availability	Replacement Bowls, Blades, Discs Available
Warranty	2 Years
Included Accessories	Chopping Blade, Slicing Disc, Shredding Disc, Dough Blade, Spatula
Power Supply	220-240 V, 50/60 Hz
Cord Length	1.0 m
Noise Level	~75 dB

Frequently Asked Questions - SP10120N SWAN

What is the capacity of the Swan SP10120N food processor?

The bowl has a 2.0 liter capacity, suitable for preparing meals for up to 4 people.

Can I wash the parts in the dishwasher?

Yes, the bowl, lid, and all accessories (blades, discs) are dishwasher safe. The motor base should only be wiped with a damp cloth.

What functions does this food processor have?

It can chop, slice, shred, mix, blend, and knead dough. It comes with 2 speeds plus a pulse function for precise control.

Is the food processor safe to use?

Yes, it features a safety lock lid that prevents operation if not properly closed, non-slip feet for stability, and overload protection.

How do I clean the blades?

The blades are removable and can be washed in the dishwasher or by hand with warm soapy water. Be careful of the sharp edges.

Can I make dough with this food processor?

Yes, it includes a dough blade and can knead bread or pizza dough. Do not exceed the maximum dough capacity (500g flour).

What is the power of the motor?

The motor has a power output of 800 watts, enough for most food preparation tasks.

Are replacement parts available?

Yes, you can purchase replacement bowls, blades, and discs from the Swan website or authorized retailers.

How long is the warranty?

The Swan SP10120N comes with a 2-year warranty against manufacturing defects.

Can I store the accessories inside the bowl?

Yes, the bowl is designed to accommodate the blades and discs for convenient storage inside the unit.

USER MANUAL SP10120N SWAN

Mini Chopper

Model: SP10120 (all colours)

Helpline

01733 404703

When using any electrical appliance, basic safety precautions should always be followed including the following:

• Always ensure that the voltage on the rating label corresponds to the mains voltage in your home
- Incorrect operation and improper use can damage the appliance and cause injury to the user.
- This appliance can be used by children aged from 8 years and above if they have been given supervision or instruction concerning use of the appliance in a safe way and if they understand the hazards involved. Cleaning and user maintenance shall not be made by children unless they are older than 8 and supervised. Keep the appliance and its cord out of reach of children aged less than 8 years. Check the power cord and plug regularly for any damage. If the cord or the plug is damaged, it must be replaced by the manufacturer or qualified person in order to avoid an electrical hazard.
- Do not use the appliance if it has been dropped or damaged in any way. In case of damage, take the unit in for examination and/or repair by an authorised service agent.
• Never immerse the unit in water or any other liquid for cleaning purposes.
- Remove the plug from the socket by gripping the plug. Do not pull on the cord to disconnect the appliance from the mains. Always unplug the unit when not in use, before cleaning or when adding or removing parts.
- The use of accessory attachments that are not recommended or supplied by the manufacturer may result in injuries, fire or electric shock.
- Do not let the cord hang over the edge of a table or counter. Ensure that the cord is not in a position where it can be pulled on inadvertently.
- Do not allow the cord to touch hot surfaces and do not place on or near a hot gas or electric burner or in a heated oven.
- Do not use the appliance on a gas or electric cooking top or over or near an open flame.
- Use of an extension cord with this appliance is not recommended. However, if it is necessary to use an extension lead, ensure that the lead is suited to the power consumption of the appliance to avoid overheating of extension cord, appliance or plug point. Do not place the extension cord in a position where it can be pulled on by children or animals or tripped over.
- This appliance is not suitable for outdoor use. Do not use the appliance for anything other than its intended use.

IMPORTANT INFORMATION - RETAIN FOR FUTURE USE

• Do not carry the appliance by the power cord.
• Do not leave the appliance unattended during use. Always unplug the unit when not in use or before cleaning.
• Always operate the appliance on a smooth, even, stable surface. Do not place the unit on a hot surface.
• Ensure that the unit is switched off after use.
• The manufacturer does not accept responsibility for any damage or injury caused by improper or incorrect use, or for repairs carried out by unauthorised personnel.
• In case of technical problems, switch off the product and do not attempt to repair it yourself. Return the appliance to an authorised service facility for examination, adjustment or repair. Always insist on the use of original spare parts. Failure to comply with the above mentions precautions and instructions, could affect the safe operation of this product.
• Your appliance must never be switched on through an external timer or any kind of separate remote control system
• This appliance is intended to be used in household and similar applications such as staff kitchen areas in shops, offices and other working environments, farm houses, by clients in hotels, motels and other residential type environments, bed and breakfast type environments.
  • DO NOT blend hot oil or meat
  • Take great care when handling the blade
• Do not continuously operate the mixer too long. The motor may overheat. If the surface of the blender has been very hot, it may need time to cool down. After reducing to room temperature, the blender can be operated again. Avoid operating without load for long periods as the bearings could overheat.

CAUTION: DO NOT IMMERSE THE MOTOR UNIT IN WATER

TECHNICAL DATA

Description: Mini Chopper

Model: SP10120N

Input Voltage: 220-240V

Frequency: 50/60Hz

Power consumption: 120 Watts

PARTS

1. Lid
2. Locking tabs
3. Blade unit
4. Food bowl
5. Switch button
6. Lid locking slot
7. Drive shaft

BEFORE FIRST USE

1. Remove the lid, blade unit, food bowl and all packaging material from the retail box.
2. Remove the lid & blade unit from the main unit. Turn the food bowl in anti-clockwise direction and remove it from main unit.
3. Wash the bowl, lid and black unit in warm, soapy water. Rinse and dry thoroughly. PLEASE TAKE CARE WHEN HANDLING THE BLADES. THEY ARE VERY SHARP
4. Make sure the food bowl is completely dry before you add the food in.

1. Insert the food bowl in to main unit and turn the bowl in clockwise to lock it in place.
2. Put the blade unit inside the food bowl.
3. Put the food stuff into the food bowl and turn the lid clockwise to lock in place. Ensure the tag on the lid is in the locking slot or the unit will not operate!
4. Connect the plug to wall socket
5. With one hand, hold the main unit and with the other hand, press the switch button. The appliance will run and start chopping the food.
6. Each press should not be over 15 seconds. Release the button and the motor will stop. Repeat for a finer consistency.
7. Take care with the blades when removing food as they are very sharp.

CHOPPING TIPS

• The bowl has a capacity of 350ml. Do not exceed over 120g of meat.
- For more control, process by pressing the "ON/OFF" button briefly then releasing. Check consistency and continue if necessary.
- Do not process large pieces of raw or cooked beef or whole pieces of baking chocolate. Remove bones from any meat cuts as this could damage the product.
- The appliance must not work for more than 1 minute every time, it must rest for 2 minutes before next operation to allow the motor to cool. In practice, 15 second pulses or less is sufficient to process most types of food.

CLEANING

• This is best done immediately after use
- Switch off and unplug the appliance
- Wash attachments in warm, soapy water. Rinse and dry thoroughly. TIP: Use a nylon brush to clean/unclog the blades to prevent touching as they are very sharp!
• Never use metal or abrasive cleaners. Never use strong chemical cleaners
- The Motor Unit can be cleaned by wiping down with a soft cloth moistened in a mild detergent solution. NEVER IMMERSE THE BASE UNIT IN WATER OR RUN IT UNDER THE TAP

CLEANING

NEVER IMMERSE THE BASE IN WATER OR ANY OTHER LIQUID. ALWAYS SWITCH OFF AND UNPLUG THE APPLIANCE BEFORE CLEANING

COMPLETELY CLEAN AND DRY ALL PARTS AFTER EVERY USE. PLEASE TAKE EXTREME CARE WHEN HANDLING THE BLADES

Always turn the appliance "OFF" and remove the plug from the electrical outlet before cleaning it. Wait for food chopper to cool down. Wipe the outside of food chopper with a damp cloth and dry with another cloth or paper towel. Do not use abrasive cleaners. Wash the cover, bowl (container), and blade in hot soapy water. Rinse and dry.

Do not put the bowl, lid or blade assemblies in the dishwasher as this can cause discolouration due to high temperatures

We Swan Products Ltd declare that this product conforms to the following product legislation in accordance with the following directive(s):

2004/108/EC The EMC Directive (the Electromagnetic Compatibility Directive). 2006/95EC. The LVD Directive (Low Voltage Directive). 2011-65-EU. The RoHS directive (Restriction of Hazardous Substances Directive) EC 1935/2004 Food Contact 125/2075 Eco design

WARRANTY

This product is guaranteed for 2 years from the date of original purchase. If any defect arises due to faulty materials of workmanship the faulty products must be returned to the place of purchase. Refunds or replacement is at the discretion of the store.

The following conditions apply:

• The product must be returned to the retailer with proof of purchase.
• The product must be installed and used in accordance with the instructions contained in this instruction guide.
  • It must be used only for domestic purposes.
• It does not cover wear and tear, damage, misuse or consumable parts.
  • Swan Products Ltd has limited liability for incidental or consequential loss or damage.
  • This guarantee is valid in the UK and Eire Only.

BS PLUG

The wires in the mains lead are coloured in accordance with the following code:

As the colours of the wire in the mains lead of this appliance may not correspond with the colour markings identifying the terminals on your plug, proceed as follows:

The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or coloured black. The wire which is coloured BROWN must be connected to the terminal which is marked with the letter L or coloured red. WARNING: THIS APPLIANCE IS DOUBLE INSULATED. DO NOT CONNECT ANY WIRE TO THE EARTH PIN

DISPOSAL OF UNIT

Appliances bearing the symbol shown here may not be disposed of in domestic rubbish. You are required to dispose of old electrical and electronic appliances like this separately. Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to information about the recycling of electrical items. Please visit www.weeeireland.ie for access to information about the recycling of electrical items purchased in Ireland. The WEEE directive, introduced in August 2006, states that all electrical items must be recycled, rather than taken to landfill. Please arrange to take this appliance to your local Civic Amenity site for recycling, once it has reached the end of its life.
