Product Type	Electric Storage Water Heater
Brand	Corbero
Model	CCE10FMGN
Capacity	10 Liters
Power Consumption	1500 W
Voltage	220-240 V ~ 50 Hz
Dimensions (H x W x D)	Approx. 40 x 30 x 30 cm
Weight	Approx. 5 kg
Temperature Range	30°C - 75°C (adjustable)
Heating Time (to max temp)	Approx. 30 minutes
Pressure Rating	0.6 MPa (6 bar)
Mounting	Wall-mounted (horizontal or vertical)
Water Connection	G 1/2 inch
Safety Features	Thermostat, thermal cut-out, pressure relief valve, anti-corrosion anode
Maintenance	Annual descaling and anode check
Spare Parts Available	Heating element, thermostat, anode rod, gaskets
Repair Index (France)	7.5 / 10
Energy Efficiency Class	B (typical for 10L electric)
Standby Consumption	< 0.5 W
Noise Level	< 25 dB
Included Accessories	Safety valve, mounting bracket, user manual
Warranty	2 years
Certification	CE, RoHS

Frequently Asked Questions - CCE10FMGN CORBERO

How do I install the Corbero CCE10FMGN water heater?

Installation must be done by a qualified professional. Mount the heater securely on a wall capable of supporting its weight (approx. 5 kg dry, 15 kg full). Connect to cold water supply using a pressure relief valve (included). Ensure electrical connection matches the rating (220-240V, 1500W) and is protected by an RCD.

What is the temperature setting range?

The thermostat can be adjusted between 30°C and 75°C. For normal use, set between 50-60°C to prevent scalding and reduce limescale buildup.

How long does it take to heat the water?

Heating from cold to 75°C takes approximately 30 minutes due to the 1500W element and 10L capacity. The exact time depends on incoming water temperature.

How do I maintain the water heater?

Annually, drain the tank and check the anode rod for corrosion. Replace if reduced to 50% or less. Descale the heating element if needed. Regularly test the pressure relief valve to ensure it opens and closes properly.

What safety features does it have?

It includes a thermostat to regulate temperature, a thermal cut-out to prevent overheating, a pressure relief valve to avoid overpressure, and an anti-corrosion anode to protect the tank.

Can it be mounted horizontally?

Yes, the CCE10FMGN can be installed both vertically and horizontally. Ensure the water connections are correctly oriented and the unit is level.

What spare parts are available?

Common spare parts include the heating element, thermostat, anode rod, gaskets, and pressure relief valve. Contact Corbero service centers or authorized dealers.

Is the water heater energy efficient?

It is rated energy class B, typical for small electric storage heaters. To improve efficiency, insulate hot water pipes and set a moderate temperature (55°C). Standby consumption is below 0.5W.

What does the error code mean?

This model may indicate faults via blinking lights. Common codes: 1 flash = sensor issue, 2 flashes = overheating. Refer to the manual for full list. If unresolved, contact technical support.

How do I drain the water heater for maintenance?

Turn off power and close the cold water inlet. Open a hot water tap to relieve pressure. Attach a hose to the drain valve (if present) or disconnect the safety valve outlet. Open the drain valve and allow water to flow out. Dispose of water appropriately.

USER MANUAL CCE10FMGN CORBERO

Exterior view of a white industrial water heater unit (no visible text or symbols on the device body)

Frontal

Lateral
