Lite N464E124C - Caméra réseau Dahua Technology - Free user manual and instructions
Find the device manual for free Lite N464E124C Dahua Technology in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Network Camera |
| Model | Lite N464E124C |
| Brand | Dahua Technology |
| Resolution | 4 Megapixels (2688 x 1520) |
| Lens | Fixed focal length, 2.8 mm |
| Night Vision | Up to 30 meters with IR LEDs |
| Video Compression | H.265+ / H.265 / H.264+ / H.264 |
| Dimensions (W x H x D) | 182 mm x 76 mm x 76 mm |
| Weight | 0.35 kg |
| Power Supply | 12V DC, PoE (802.3af) |
| Power Consumption | ≤ 5.5 W |
| Operating Temperature | -30°C to +60°C |
| Ingress Protection | IP67 |
| Main Functions | Motion detection, tampering alarm, intelligent video surveillance |
| Storage | Supports microSD card (up to 256 GB), NVR |
| Network Interface | RJ-45 10/100 Base-T |
| Audio | Built-in microphone, 1 audio input |
| Security | Password protection, IP address filtering, HTTPS encryption |
| Cleaning Instructions | Use soft dry cloth; avoid chemical cleaners |
| Spare Parts and Repairability | Contact authorized service center; no user-serviceable parts inside |
| General Information | Compliant with CE, FCC, RoHS standards |
Frequently Asked Questions - Lite N464E124C Dahua Technology
How do I reset the camera to factory defaults?
Press and hold the reset button on the camera for 10 seconds using a pin. The camera will reboot with factory settings.
Can I use the camera outdoors?
Yes, the camera has an IP67 rating, making it weatherproof and suitable for outdoor use.
How do I connect the camera to the network?
Connect the camera via Ethernet cable to your router or PoE switch. Use the DHCP default IP or configure a static IP via the config tool.
What is the default username and password?
Default username is admin and password is admin. It is strongly recommended to change the password after first login.
How do I view the camera remotely?
Download the DMSS app (Dahua Mobile Security Surveillance) on your smartphone and add the camera by scanning its QR code or entering its serial number.
The camera night vision is not working. What should I do?
Check if the IR LEDs are enabled in the camera settings. Ensure there is no obstruction and that the power supply is adequate.
Can I record video without an NVR?
Yes, the camera supports local recording via a microSD card (up to 256 GB). Insert the card into the slot.
How do I update the camera firmware?
Download the latest firmware from the Dahua website, log into the camera's web interface, go to Update under Settings, and upload the file.
Why does the camera keep going offline?
Check network connectivity, power supply stability, and ensure the PoE switch or power adapter meets requirements. Also verify that the camera's IP address is not conflicting.
What is the maximum supported microSD card size?
The camera supports microSD cards up to 256 GB in FAT32 or exFAT format.
