Product Type	USB Update Cable
Brand	Metra
Model	USB-CAB
Category	Computer Accessory
Compatibility	Axxess Interface Boxes (4-pin serial port)
Primary Function	Firmware update for Axxess interfaces
Connectivity	USB Type-A to 4-pin serial connector
Software Required	Webxpress Updater, USB Bootloader Program
Driver Installation	Automatic via Windows (may require manual for Vista)
Dimensions (approx.)	1.5 m cable length
Weight (approx.)	50 g
Material	PVC jacket, copper conductors
Safety Warning	Contains lead (California Proposition 65)
Country of Origin	China
Manufacturer	Metra Electronics
Installation	Plug into computer and interface, follow software prompts
Compatible OS	Windows (Vista, 7, 8, 10, 11)
Additional Notes	Sold separately; not for general data transfer

Frequently Asked Questions - USB-CAB Metra

What is the Metra USB-CAB used for?

The Metra USB-CAB is a specialized update cable designed to connect your computer to an Axxess interface box for firmware updates. It is not a standard data transfer cable.

Which Axxess interfaces are compatible with the USB-CAB?

The USB-CAB works with any Axxess interface that has a 4-pin serial port for firmware updates. Common models include the Axxess ASWC-1, XSVI-2003, and others with similar ports.

How do I install drivers for the USB-CAB on Windows?

Drivers are typically installed automatically when you connect the cable. If prompted, follow the on-screen instructions. For Windows Vista, right-click the software icon and select 'Run as Administrator'.

What software do I need to use the USB-CAB?

You need the Webxpress Updater program, available for download from www.axxessinterface.com. After installation, use the USB Bootloader Program to update the interface.

How do I update an Axxess interface using the USB-CAB?

1. Connect the USB-CAB to your computer. 2. Open the USB Bootloader Program. 3. Click 'Update Unit Board'. 4. When prompted, plug the other end into the interface's 4-pin port. The update will start automatically.

Is the USB-CAB compatible with Mac or Linux?

The provided software is designed for Windows only. Compatibility with other operating systems is not guaranteed and may require additional drivers or workarounds.

What does the California Proposition 65 warning mean?

The cable contains lead, which is known to the state of California to cause cancer and birth defects. Always wash your hands after handling and avoid ingestion.

Can I use the USB-CAB for data transfer or charging?

No. The USB-CAB is specifically designed for firmware updates only. It does not support standard data transfer or charging functions.

What should I do if the update fails or the cable is not recognized?

Ensure you have installed the latest Webxpress software and drivers. Try using a different USB port, restart your computer, or run the software as administrator. If issues persist, contact Axxess support.

Where can I download the latest Webxpress Updater?

Visit www.axxessinterface.com and click on the 'Firmware Downloads' tab. Download the Webxpress Updater program for your operating system.

USER MANUAL USB-CAB Metra

USB-CAB INSTRUCTIONS

For installation and operation instructions, please go to: www.axxessinterface.com (http://www.axxessinterface.com/) and click on the "Firmware Downloads" tab

1. Download the webxpress updater program from www.axxessinterface.com.
2. Once downloaded double click the webxpress program icon located on your desktop and follow prompts. (note: For windows Vista users right click on icon and click "run as administrator").
3. Once installed connect the USB-CAB to your computer (sold separately) and follow prompts to install drivers. (Note: not all computers will need to do this).
4. Once drivers are installed open the USB bootloader program which is located in the "all program" section of your start menu.
5. Open up the Axxess interface box that needs to be updated to access the 4-pin serial port on the circuit board.
6. With the USB boot loader program opened, click "update unit board". When prompted, plug the USB-CAB into the 4-pin serial port of the Axxess interface and the board will begin to update to the latest version.

"WARNING: This product contains chemicals, including lead, known to the state of California to cause cancer and birth defects or other reproductive harm. Wash hands after handling".

MADE IN CHINA

AXXESSINTERFACE.COM

460 WALKER STREET

HOLLY HILL, FL 32117-2699

800-221-0932

USB-CAB

AXXESS UPDATE CABLE
