USER MANUAL Alvar MIO

Read this instruction carefully before usage. Keep this safe for future reference.

Safety instructions

This product is made for dry and clean indoor environment (IP20). It should not be in contact with water, damp or any other fluid.

Only use a dry cloth for cleaning. Never use any acid detergent on the electrical parts.

The light bulb can get very hot. Pull out the plug and let the bulb cool down before replacing the light bulb.

Assembly instructions

1. Warning! Before installation, turn off the electrical feed at the circuit breaker (fuse) on your electrical service panel. Assemble the lamp according to the drawing. The cable can be shortened if required. The cable shall always be shortened in the ceiling cup.

2. If you have a ceiling unit the fixture can be hung directly onto the ceiling hook. If you don't have a ceiling unit, please use the terminal block to connect the cables.

3. The external flexible cable and cord for this product are not replaceable. If the cable or cord is damaged the product shall be discarded.

Specifications

Model No:

Voltage:

For indoor use only. MAX Power:

For dry and clean indoor environment.

Don't throw the article into normal domestic waste but hand it in for recycling. In this way you have a big hand in environmental protection. Please ask your local government for next staging area.

Mio AB, Box 59, 543 21 Tibro, Tel: 020 - 66 44 00, www.mio.se

ALVAR

Pure mechanical diagram showing a vertical rod with attached components and a magnified inset of a mechanical assembly (no text or symbols)

Pure mechanical diagram showing a vertical rod with attached components and directional arrows, no text or symbols present.

Pure mechanical diagram showing a suspended structure with spherical components and directional arrows (no text or symbols)

OBS! Stickpropp ingår ej/ plug is not included

Fas / Phase

Neutralledare / The neutral conductor

Jord / The protective conductor
