| Product Type | Powered Subwoofer |
| Brand | BASSBOSS |
| Model | ZV28-MK3 |
| Dimensions (H x W x D) | 710 x 510 x 610 mm |
| Weight | 45 kg |
| Power Supply | 100-240 VAC, 50/60 Hz |
| Amplifier Power | 2000W RMS, Class D |
| Driver | 28" custom woofer |
| Frequency Response | 20 - 100 Hz (±3 dB) |
| Maximum SPL | 140 dB (peak, half space) |
| Input/Output Connectors | XLR balanced input and link, Neutrik powerCON |
| Controls | DSP presets, volume, phase, EQ settings |
| Enclosure Material | Birch plywood with durable coating |
| Recommended Use | Professional sound reinforcement for concerts and events |
| Maintenance & Cleaning | Wipe with dry cloth; avoid moisture and direct sunlight |
| Safety Instructions | Do not expose to rain or liquids; disconnect power before cleaning |
| Spare Parts & Repairability | Contact BASSBOSS service center for genuine parts |
Frequently Asked Questions - ZV28-MK3 BASSBOSS
How do I connect the ZV28-MK3 to my mixing console?
Use a balanced XLR cable from the console output to the XLR input on the subwoofer. Use the XLR link output to daisy-chain additional subwoofers. Ensure the powerCON cable is connected to AC power.
What is the power consumption of the ZV28-MK3?
The subwoofer has a 2000W RMS Class D amplifier. Typical power consumption is around 1200-1800W at full output, depending on program material. Use a dedicated 15A circuit.
Can I use the ZV28-MK3 outdoors?
Yes, the enclosure is designed for outdoor use but must be protected from direct rain and moisture. Do not submerge in water. Use a weather cover if necessary.
How do I set the DSP presets?
Use the front panel controls to select from factory presets (e.g., Music, Live, Cardioid). Refer to the manual for detailed settings. You can also connect via USB for advanced DSP tuning.
What are the dimensions and weight of the ZV28-MK3?
Dimensions are 710 x 510 x 610 mm (height x width x depth). Weight is approximately 45 kg. Ensure adequate support and handling equipment.
Does the subwoofer have built-in protection?
Yes, the DSP includes over-current, thermal, and over-excursion protection. The amplifier will automatically limit to prevent damage.
Can I use the ZV28-MK3 as a standalone speaker?
No, the ZV28-MK3 is a subwoofer and reproduces only low frequencies (20-100 Hz). It must be paired with full-range speakers for a complete system.
How do I clean and maintain the subwoofer?
Wipe the enclosure with a slightly damp, lint-free cloth. Do not use solvents or abrasive cleaners. Inspect connectors and cables regularly for damage.
What is the warranty period?
BASSBOSS typically offers a 6-year warranty for the driver and 3 years for the amplifier. Check with your dealer for specific terms.
Where can I find the user manual?
The user manual can be downloaded in PDF format from the BASSBOSS website or from notice-facile.com by selecting your language and providing your email.
