Download the instructions for your Oven in PDF format for free! Find your manual CDDS60 - Euromaid and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. CDDS60 by Euromaid.
USER MANUAL CDDS60 Euromaid
• Double Electric Oven & Grill
• Side opening lower oven
• Ceramic glass cooktop
- Top Oven Static with Grill,
34 Litre gross capacity
• Bottom oven Fan Forced,
• 77 Litre gross capacity
- Self clean catalytic oven liners in oven & grill
• Automatic programmable oven
• A Class energy efficiency
• European made
Total Power: 10 kW
Grill Wattage: 2.2 kw
Direct Wired: 43 amps hardwired
Power: 220 - 240 volt/50Hz
Hotplate - Front Left: 180mm - 1700W
Hotplate - Rear Left: 140mm - 1200W
Hotplate - Front Right: 140mm - 1200W
Hotplate - Rear Right: 180mm - 1700W
dimensions
Product Dimensions: 600mm (W) 900mm (H) x 600mm (D)
warranty - customer service
Warranty
2 year Parts and Labour
Customer Service
Our Nationwide Service Team can
be contacted on 1800 805 300
or by logging on to
customersupport.hapl.com.au
HOME APPLIANCES
20 Carlotta Street
Artarmon NSW 2064
T:02 9958 3111
F: 02 9958 3555
E: info@hapl.com.au
www.euromaid.com.au
Brand : Euromaid
Model : CDDS60
Category : Oven
