USER MANUAL SmartSet CKSW5010 Emerson

15Watt Ultra Fast Wireless Charging SmartSet® Clock Radio with Bluetooth, USB Charge Out, Dual Alarm, LED Décor and 1.2" Cyan LED Display

(SmartSet® Patent No. 6,567,344)

OWNER'S MANUAL CKSW5010

Visit our website at www.emersonradio.com

WARNING

TO PREVENT ELECTRIC SHOCK HAZARD, DO NOT CONNECT TO MAINS POWER SUPPLY WHILE GRILLE IS REMOVED. TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE.

POUR ÉVITER TOUT DANGER DE CHOC ÉLECTRIQUE, NE PAS RACCORDER AU SECTEUR TANT QUE LA GRILLE N'APAS ÉTÉ REMISE EN PLACE. POUR RÉDUIRE LE RISQUE D'INCENDIE OU DE CHOC ÉLECTRIQUE, NE PAS EXPOSER CET APPAREIL SOUS LA PLUIE ET L'HUMIDITÉ.

IMPORTANT SAFETY INSTRUCTIONS

1.) Read these instructions. Keep these instructions. Follow all instructions. Heed all

warnings.

2.) Do not use this apparatus near water.

3.) Clean only with dry cloth.

4.) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.

1. Do not install near any heat sources such as radiator

5.) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

6.) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

7.) Protect the power cord from being walked on or pinched particularly at plugs

convenience receptacles, and the point where they exit from the a

8.) Only use attachments / accessories specified by the manufacturer. 9.) Unplug this apparatus during lightning storms or when unused for long periods of time. 10.) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged.

apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

11.) Use only with the cart, stand, tripod, bracket, or table specified by the manu cold with the apparatus. When a part is used, use option when moving the

sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

12.) The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on apparatus.

13.) Mains plug is used as disconnect device and it should remain readily operable during intended use. In order to disconnect the apparatus from the mains completely, the mains plug should be disconnected from the mains socket outlet completely.

14.) Battery shall not be exposed to excessive heat such as sunshine, fire or the like.

CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the

• minimum distances 10 cm around the apparatus for sufficient ventilations.

- the ventilation should not be impeded by covering the ventilation openings with items such

as newspaper, table, clothes, curtains etc.

- no naked flame sources such as lighted candles should be placed on the apparatus.

• Atacino source de hammino holo, let qu'ario bouglio, no dott o're piacoo sul ta; a intention should be drawn to the environmental concepts of battery disposal.

• attention should be drawn to the environmental aspects of battery and fuel.

- the use of apparatus in tropical and/or moderate climates.

Maximum recommended ambient temperature is 25°C.

Do not ingest the battery. Chemical Burn Hazard.

This product contains a coin/button cell battery.

If the coin/button is swallowed, it can cause severe internal burns in just 2 hours and can lead to death.

Keep new and used batteries away from children.

If the battery compartment does not close securely, stop using the product and keep it away from children

If you think batteries might have been swallowed or placed inside any part of the

Body, seek immediate medical attention.

AVERTISSEMENT

a) Remove and immediately recycle or dispose of used batteries according to local regulations and

keep away from children. Do NOT dispose of batteries in household trash or incinerate.

b) Even used batteries may cause severe injury or death.

c). Call a local poison control center for treatment information

c) Gain a local portion control center d) Comptibial battery type: GB2039

d) Compatible battery type: CR2032 e) Nominal battery voltage: 3.6%

6) Nominal Battery voltage: 3.0V

f) Non-rechargeable batteries are not to be recharged.

g) Do not force discharge, recharge, disassemble, heat above (manufacturer's specified

temperature rating) or incinerate. Doing so may result in injury due to venting, leakage or

explosion resulting in chemical burns.

h) Ensure the batteries are installed correctly according to polarity (+ and -).

1) Do not mix old and new batteries, different brands or types of batteries, sp

s carbon zinc, or isopercapable batteries.

i). Remove and immediately recycle or dispose of batteries from equipment not used for an

(1) Remove and immediately recycle or dispose of batteries extended period of time according to local populations.

extended period of time according to local regulations.

k) Always completely secure the battery compartment. If the battery compartment does not

securely, stop using the product, remove the batteries, and keep them away from children.

Important Notes

Avoid installing this unit in places • Operate controls and switches

exposed to direct sunlight or close to as described in the manual.

heat radiating appliances such as: * Before turning on the power,

electric heaters, on top of other stereo make certain that the AC

equipment that radiates heat, places adapter is properly installed.

lacking ventilation, dusty areas, places. * When moving the set, be sure

lacking ventilation, dusty areas, places subject to constant vibration and/or to first disconnect the AC

subject to constant vibration and/or adapter

humid or moist areas.

500 information

This equipment has been tested and found to comply with the limits for a Class B digital

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the ESC Rules. These limits are designed to provide

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses, and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on.

the user is encouraged to try to correct the interference by one o more of the following

measures

• Reorient or relocate the receiving antenna

- Increase the separation between the equipment and receiver

- Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the

- Connect the equipment

receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help. This device complies

with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may

cause undesired operation.

Changes or modifications to this unit not expressly approved by the party responsible for

compliance could void the use's authority to operate the equipment. This equipment

compliance should void the use of authority to operate the equipment. This equipment compiles with the FCC RE radiation exposure limits sel forth for an uncontrolled environment

This equipment should be installed and operated with a minimum distance of 20 centimeters.

This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiates and your body.

between the radiator and your body.

Thank you for purchasing this Emerson SmartSet® Dual Alarm Clock Radio. This clock

uses Emerson's patented SmartSet® Automatic Time Setting System. The first time you

connect this clock to your AC outlet, and after every power interruption, within seconds

the clock will automatically set itself to the correct Year, Month, Date, Day, and Time. In

addition, all changes from Standard Time to Daylight Saving Time, and back to Standard

Time, are made automatically. There are dual alarms that can be set and used

independently, and both of the alarms can be programmed for everyday operation.

weekdays only, or weekend's only. There is a long life lithium battery installed in this clock

Wednesday only, of weekends's only. There is a long time medium battery installed in this sheet when you buy it. This battery can maintain the time and alarm settings for 1 to 2 years, or

When you buy it: This battery can maintain the time and alarm settings for 1 to 2 years, or even longer. We have taken every precaution to make sure this clock was in perfect

even longer. We have taken every precaution to make sure this clock was in perfect working order when it left our factory. If you encounter any problems with the set up or

working order when it left our factory. If you encounter any problems with the set up of operation of this item, please call the Foreign Consumer Products Corp. Customers

operation of this item, please call the Emers

Service Hotline, toll free, at 1-800-898-9020.

3 Preparation For Use

Remove the clock from the carton and remove all packing material from the clock. Save the packing material, if possible, in case the clock ever needs to be serviced or transported. The original carton and packing material is the only safeway to pack your clock to protect it from damage in transit.

- Remove any descriptive labels, stickers or protective films on the front or top of the cabinet, if any.

• Do not remove any labels or stickers from the back or bottom of the cabinet. • Note the serial number on the bottom of your clock and write this number in the space provided on the Warranty page of this manual.

- Place your clock on a level surface such as a table, desk or shelf, convenient to an AC outlet, out of direct sunlight, and away from sources of excess heat, dirt, dust, moisture, humidity, or vibration.

• Unwind the antenna wire and extend it fully

Protect Your Furniture

This model is equipped with non-skid rubber 'feet' to prevent the product from moving when you operate the controls. These 'feet' are made from non-

migrating rubber material specially formulated to avoid leaving any marks or stains on your furniture. However certain types of oil based furniture polishes, wood preservatives, or cleaning sprays may cause the rubber 'feet' to soften, and leave marks or a rubber residue on the furniture. To prevent any damage to your furniture we strongly recommend that you purchase small self adhesive felt pads, available at hardware stores and home improvement centers everywhere, and apply these pads to the bottom of the rubber 'feet' before you place the product on fine wooden furniture.

Power Source

This clock is designed to operate on normal 120V 60Hz AC power only. Don't attempt to operate the clock on any other power source. You could cause damage to the clock that is not covered by your warranty. This clock should be connected to an AC outlet that is always 'live'. Do not connect it to an outlet that is controlled by a wall switch. When the power to the clock is interrupted, the built in lithium battery takes over to maintain the time and alarm settings. To maximize the life of the lithium battery keep the clock connected to a 'live' AC outlet at all times.

Package Contents

- OKSW5048 Clock Radiow1

- Owner's Manuel

- Watch Holdings:

5 Location of Controls and Indicators

1.1 (AL 1'Radio') Alarm Indicator

1. 1 (AL 1'Buzzer') Alarm Indicator

2. AM Indicator ('On'=AM-'Off'=RM)

3. SLD Sleep Indicator

4. SLP Sleep Indicator

5. ▲ Wireless Charging Indicator

6. Wireless Charging

7. DAY OF WEEK Indicators

8. DAY OF WEEK INDICATORS

9. LOW BATTERY Indicator

8.BT Indicator ('Solid'=Bluetooth

connected)

1. MHz FM Radio Indicator

10.2 (AL 2 'Buzzer') Alarm Indicator

10.24 (AL 2 'Buzzer') Alarm Indicat 11.37 (AL 2 'Radio') Alarm Indicat

11.293 (AL 2 Radio) Alarm Indicat 12. Foldable Wireless Charging Red

1. Foldable Wireless Charging Pad

2. Wireless Charging Earbuds Pad

3. TIME ZONE/ ON/OFF ('ON'/Standby)

Button

1. LED Décor Button

2. AL1 (Alarm 1) Set/VOL- Button

3. AL 2 (Alarm 2) Set/VOL + Button

4. 2N207E/2LEER/DINNER (1+ level)

5. SNOOZE /SLEEP/DIMMER (4-Level)

Bu

1. H / TUNE- Button

2. N/TUNE+Button

3. EMNEM (Mason) / STO (Stee)

4. FM

BT ▶I Button

1. CLOCK SET / M (Mode) Button

2. Adapter Cable

3. Adapter OA

4. AC Adapter

5. AC Adapter

6. Watch Charger Holder

7. FM Antenna V

8. USB-C Charging Port

9. USD-O Charging Port

10. USD-A Charging Port

11. USB-A Charging Port

12. Battery Cover/Door

6 Setting the Time Zone

Initial Default Setting at Clock Mode

IMPORTANT: The first time you connect your new SmartSet® clock radio to the AC outlet the internal computer will automatically set the time correctly for the Eastern Time Zone, which is the initial default setting. The display will scan for a few seconds and then show the correct Day and Time in the Eastern zone. If you live in the Eastern Time zone, there's nothing else to do. Your clock is set correctly and running. If you do not live in the Eastern Time zone you must change the default zone display to your own zone. You only do this one time and the SmartSet® will remember the new default zone setting and will always return to that setting after power interruption.

There are 7 time zones programmed into your SmartSet® clock radio as follows: ZONE 01 — Atlantic Time ZONE 02 — Eastern Time (Default Setting)

ZONE 01 — Atlantic Time ZONE 02 — Eastern Time (a) ZONE 03 — Central Time ZONE 04 — Mountain Time

ZONE 03 — Central Time ZONE 04 — Mountain Time ZONE 05 — Pacific Time ZONE 06 — Volley Time

ZONE 05 — Pacific Time

ZONE 07 — Hawaiian Time

1. Press and hold 2. Press ▶ or ▶

TIME ZONE 2.1 Stress ▶ or ▶ 3.1 Stress TIME ZONE again to save the new zone number and resume

TIME ZONE, then release

to clock mode

Note: Time zone and clock settings can only be adjusted in Standby mode, where the function of Radio and Bluetooth are disabled (i.e. indicator of MHz and BT are 'OFF').

7 Setting the Clock Manually

Checking the Current Year-Date-Day of Week-Time Settings

Press briefly the CLOCK SET button once to see the year, date in sequence. To restore time display mode, leave it idle for a few seconds.

To restore time display mode, leave it idle for a few seconds.

Setting the Year

① Press and hold the CLOCK SET button during Standby mode until the

Year 'Flashes', the release the button;

② Press the ◀ or ▶ button to adjust Year;

Setting the Date

③ Press the CLOCK SET button again and release, the Month'Flashes'

④ Press the ▶ or ▶ button to adjust the Month:

⑤ Press the CLOCK SET button again and

release, the Date 'Flashes': 11 17

⑥ Press the ▶ or ▶ button to adjust the Date: 9 in

- Press the N of P button to adjust the Date, For example, April 18th will arrive on (1.16)

For example, April 16th will appear as '4.16

Setting the Time

⑦ Press the CLOCK SET button again and release, the Hour 'Flashes';

⑧ Press the ◀ or ▶ button to adjust the Hour (where AM indicator 'On' is AM,

'Off' is PM);

⑤ Press the CLOCK SET button again and release

the Minute 'Flashes';

⑩ Press the RorButton to adjust the Minutes;

⑪ Press the CLOCK SET button again to store

all new settings and restore it to time display mode.

8 Daylight Saving and Leap Year Adjustment

All Daylight Saving Time (DST) and Leap Year adjustment are made

automatically by the SmartSet ^® internal computer as follows:

Start of Daylight Saving time:

At 2:00 AM on the 2nd Sunday in March, the clock will automatically advance

to 3:00 AM

End of Daylight Saving time:

At 3:00 AM on the 1st Sunday in November, the clock will automatically reset

to 2:00 AM

Leap Year:

At 12:00 Midnight on February 28th, the calendar display will change to "2.29".

IMPORTANT NOTES

Turn Daylight Saving Function OFF/ON (in Standby Mode Only) Daylight Saving Time is NOT observed in Hawaii, American Samoa, Guam, Puerto Rico, the Virgin Islands and in most of Arizona, with exception of the Navajo Indian Reservation in Arizona. If you do not want the clock to adjust itself automatically according to Daylight Saving Time, you can disable it by pressing and holding the TUNE- or TUNE+ buttons for about 5 seconds until '05' (On) shown on the display of the auto setting. The time has been enabled 'ON' by default). Press the TUNE- or TUNE+ button accordingly to toggle between 'OFF' and 'ON' for both DST start and end dates. Leave it idle for a few seconds to store your new DST settings and resume to clock mode. NOTE: If you manually adjust the time, your new setting is entered into the SmartSet® memory. If the power is interrupted, the display will return to your new setting, not the original setting, when the power is restored.

9 Setting the Alarm

IMPORTANT: Alarm settings can only be adjusted in Standby mode. Your clock radio has two separate alarms Alarm1 (AL1) and Alarm2 (AL2) that can be set and used independently. You may use the alarms to wake two persons at different times, or you may use one alarm for weekdays and the other one for weekends. Please ensure that you have set the wake up time and alarm week mode correctly.

Adjusting the Wake Up Time and Alarm Volume

The procedure for adjusting the wake up time is the same for both Alarm1 and Alarm2.

- Press and hold either the AL1 or AL2 button until the display changes current time to the Norm 4 on Norm 2, wake up time and the Load hibler

- Current time to the Alarm1 or Alarm2 wake up time and the Hour blinks. Release the AL1 (AL2) button, then press the ▶ or ▼ button to adjust

- Release the AL1 (AL2) button, then press the N or P button to adjust "Hour," press the AL1 (AL2) button again to confirm the hour & the Minute blinks: press

press the KEY (KEY) button again to the ◀ or ▶ button to adjust Minute.

- Press the AL1 (AL2)button again to adjust Alarm Volume V01-V16 by pressing

the ◀ or ▶ button.

- Press the AL1 (AL2) button again to adjust Alarm Week Mode if necessary by passing the 1 or 2 button.

pressing the ▼ or ▼ button.

- Press the AL1 (AL2) button to save the new alarm setting and resume to clock mode. Note: Be sure that you have set the wake up time correctly by observing the AM indicator. If the AM indicator is 'On' the wake up time is "AM". If it is 'Off', the wake up time is "BM".

the wake up time is PM

Selecting the Alarm Week Mode

Your SmartSet ^® clock radio allows you to select from three different alarm week modes for each alarm. The Alarm Week Modes are:

- Everyday - the alarm will turn on all 7 days

- Weekdays only - the alarm will only turn on Monday through Friday

• Weekends only - the alarm will only turn on Saturday

and Sunday

• If all 7 indicators are 'On', the Everyday mode is selected.

• If only the MON (Monday) through FRI (Friday) indicators are 'On', the Weekdays only mode is selected.

* If only the SAT (Saturday) and SUN (Sunday) indicators are

'On', the Weekends only mode is selected.

Checking the Wake Up Times and Alarm Week Mode

To check the wake up time or the alarm week mode settings, press either the AL1 or AL2 button. The display will change from current time to wake up time and the DAY OF WEEK indicators will show you the alarm week mode which is currently selected. It will return to the current time display in 3 seconds after showing the wake up time.

Activating and Deactivating the Alarm

- Press and release the AL1 or AL2 button continuously to turn On your desired Alarm Mode: Wake to Radio, Wake to Buzzer, or Off

• When the '1.5/2.5' indicator glows, the wake up to Radio alarm will be On.

- When the '1♥ / 2♥' Indicator glows, the wake up to Buzzer alarm will be On.

• To completely turn Off the alarm, press and release AL1 or AL2 button

continuously until the Radio '1/2' indicator or the Buzzer '1/2' indicator is Off

Indicator is Off.

Snooze Alarm

When the alarm comes On, press the SNOOZE button to pause it for 9 minutes.

to pause it for 9 minutes. Alarm indicator will flash during Snooze Alarm mode. To

turn off Snooze Alarm, press the ON/OFF button once.

Note: If not turned off, the Snooze Alarm will only be active for one hour.

10 Listening to FM Radio

- Extend the antenna wire fully and orient it for better FM reception.

- Press the ON/OFF button to turn the unit from Standby mode to On. - Press the MODE button repeatedly until the MHz indicator turns 'On', and

Press the MODE button repeatedly until the MHZ indicator turns "Off", and the FM station frequency displays.

Set the Volume by pressing the VOL+ or VOL- button to a level that suits your needs.

- When you finish listening to radio, press the ON/OFF button to turn the radio Off. The MHz indicator will then turn 'Off'.

Receive your desired station with the TUNING control:

- Press the ▶ / ◀ button briefly, the receiving frequency

will increase / decrease by one step.

- Press and hold the ▶ / ▶ button for 3 seconds then release. Auto Station Seeking will be engaged, the

Release, Auto Station Seeking will be engaged, the receiving frequency will increase / decrease automatically

until a station with acceptable reception is found.

Storing and Recalling Radio Station Memory Manually

When you have a few favorite radio stations to listen to, you may like to save them in specific memory locations and pick one of them in a few seconds.

them in specific memory locations and pick one of them in a few seconds without the need of searching it each time. Our digital tuning technology allows you to do this easily by following the steps listed below:

Storing Station to the Memory

- Turn the unit On and select Radio mode (MHz indicator 'On').

- Tune in the desired station by the TUNING control as described. - Press and hold the FM MEM./STO, button (for 2 seconds) until 'P

indicating the memory location to store the station currently tuned in

- While 'PXX' is blinking, press the ▶ or ◀ button can change the memory location from 1 through 20. For example, 'R 03' means the current listening

location from 1 through 20. For example, P-03 means the current listening station is about to be stored into the 3rd location of the memory.

• After deciding the memory location, press the FM MEM./STÓ.

the currently listening station is then stored accordingly.

- The display will show the frequency of the station, and after a few seconds, it will restore the current time.

Recalling Station from the Memory

• Turn the unit On and select Radio mode.

- Press the FM MEM./STO. button, "PXX" shows on the display, and the station according to the memory location will then be tuned in

• Repeatedly pressing the FM MEM./STO. button or the ▶/◀ button will

change the memory location from 1 through 20, and the station stored in th location will then be tuned in once the memory location is selected and all

location will then buttons released.

• The display will show the frequency of the station, and then returns to the current time after a previous

11 Listening to Bluetooth Speaker

- Press the ON/OFF button to turn the unit ON. - Press the MODE button to select Bluetooth/ht

- Press the MODE button to select Bluetooth(bt) mode (BT indicator: Flashes for pairing).

- Enable your Bluetooth device and select CKSW5010 from its Available/Paired device list. If gaining successful, the unit will prompt and RT indicator will become

device list. If pairing successful, the unit will prompt and BT indicator will become solid.

• Automatic connection with your Bluetooth devices is possible if they have been joined, successfully with this unit before.

paired successfully with this unit before • After paired, you can play your music.

• After paired, you can play your music through this Bluetooth Speaker. • Press briefly the ▶ll button can pause or resume playback streaming over

your Bluetooth device.

TIME ZONE

Note

- If pairing unsuccessful, all previously paired Bluetooth devices around should be disconnected first by pressing and holding the ▶ button until it prompts, or turn Off their Bluetooth connection, in order to avoid making any auto reconnection between them. Then, set this unit to Bluetooth mode, and tap the Bluetooth switch on your phone/device Off and back On again to refresh/search any nearby CKSW5010 for pairing.

- When it connects to an iOS device via Bluetooth, the clock time will be

automatically synchronized with the time of the connected device

12 Sleeping to Music Timer

Press the ON/OFF button to turn ON the unit, and press the MODE button to select either FM Radio, Bluetooth mode to play music or listen to radio

- Press the SLEEP button. The display will show the sleep timer

- Press the SLEEP button repeatedly to choose your desired sleep timer (10.00 min, 255). When a sleep time is repeated, the Sleep

(10-90 minutes or OFF). When sleep timer is counting down, the SLP indicator turns On.

Note: When you change the sleep timer from the 10-minute default timing to

a different setting, this new setting becomes the default timing. • To display the sleep timer during count down process, press the SLEEP.

To display the sleep timer during count down process, press the SELECT button.

• To cancel the sleep timer during count down process, press the ON/OFF

button to shut Off the unit.

13 Ultra Fast Wireless Charging

An Ultra Fast Wireless Charging Pad is built on top of this unit for wireless power transfer to any Qi-compatible smartphones or Qi-enabled receivers over a vertical distance of not more than 0.2 inches (5 mm).

① Place your Qi-compatible smartphone on top of the Wireless Charging Platform.

The center of your smartphone must be positioned properly right at t of this charging platform in order to maximize the charging efficiency.

② While wireless charging started or detected, the indicator will be

③ While wireless charging started of detected, the 44 indicator will be flashing 'Red' slowly.

③ To make sure wireless charging performs properly, check the charging

icon and/or charging message displays on your smartphone

④ while your smartphone is fully charged, the indicator will turn soil 'Cyan'. Please also check the charging icon and/or charging message on

- Syam! Please also check the charging key and/or charging message on your smartphone to ensure it is fully charged, then remove it from the wireless

charging platform.

Note:

• This wireless charging platform works with Qi-compatible device including 7.5

Watt iPhone 15/14/13/12/11/XS Max/XS/XR/X/8 Plus/8, 10 Watt Galaxy S10 Plus/

S10E/S10/S9, 15 Watt Galaxy S23, S22, S21, S20 and 5 Watt-15 Watt all Qi anchored phones.

• Wireless charging

- Wireless charging may not work properly if the protective case of accessory placed at the back of your smartphone is thicker than 0.2 inches (5 mm).

removed the protective case or accessory before placing your smartphone

(screen facing upward) on the wireless charging platform.

- Do not place any foreign objects, such as coins, keys, metallic objects, magnets,

and magnetic stripe cards, between your smartphone and the wireless charger, to avoid interference as overheating. While wireless charging area assumed, the v

avoid interference of overheating. While wireless charging error occurred, the indicator will be flashing 'Red' rapidly to alert user to get the erroneous receiver.

Indicator will be flashing. Red rapidly to alert user to get the erroneous receiver removed.

14 Charging the Wireless Charging Earbuds

Put the wireless charging earbuds on the wireless charging earbuds pad, the charging indicator of the earbuds will light up, and leave it till the lights indicate it is fully charged.

15 Charging the Watch

1. Insert the charging cable (not included) into the watch holder provided, at the back of the unit.

2.Plug it into the USB port at the back.

1. Hang your Apple Watch or Samsung Watch on the charging cable and aligns

it properly

You hear a chime when charging begins (unless your Apple Watch is in silent mode) and see a charging symbol on the watch.

You can replace the silicon ring of the charging cable with 2pcs silicon ring

(included). Push the center of the charging dock, separate the silicon ring and replace it, then put them together.

and replace it, then put them together.

Note:

This magnetic charging cable works with Apple Watch Series 1/2/3/4/5/6/7/8/SE, Galaxy Watch Active 1/2, Galaxy Watch 3.

16 USB for Charging

This clock radio has two USB(Type A/ Type C) port at the back, which can provide up to 5V 2.1A to charge devices like smartphone, tablet etc. via a USB cable (not provided).

Note: Electrical energy drawn from the USB port may vary due to different charging cable condition, battery characteristic or power management system of your device being charged.

Diagram of a device with a speaker emitting sound waves, connected to a smartphone (no text or symbols visible)

17 4-Level DIMMER Control

Press the SNOONE / SLEEP / DIMMER Button while in Standby mode and select any of the four levels.

Press the LED button to turn the night LED ON(high/low level) or OFF when needed

19 Changing the Lithium Battery

The lithium backup battery needs replacement when the LOW BATTERY indicator flashes, otherwise, the time and alarm settings will be lost/reset after a power outage.

- Leave the AC adapter connected to your AC outlet to retain memory while the original battery is removed.

- Unscrew the battery cover from the cabinet with a small screwdriver and

insert a new battery with the same CR2032 or equivalent type into the slot the same way, observing the positive (+) polarity before putting the

slot the same way, observing the positive (+) polarity before putting the cover back into the slot. The LOW BATTERY indicator should then be Off

BE CAREFUL NOT TO LOSE THIS SMALL SCREW!

20 Care and Maintenance

Care Of Cabinets

If the cabinet becomes dusty, wipe it with a soft cloth. If the cabinet becomes

smudged or dirty, clean it with a soft, slightly dampened cloth. Never allow water or any liquid to get inside the cabinet. Never use any abrasive cleaners or cleaning pads as these will damage the finish of your radio.

Lithium Battery Precautions

- Dispose of the old battery properly. Do not leave it lying around where a young child or pet could play with or swallow it. If the battery is swallowed contact a physician immediately.

• The battery may explode if mistreated. Do not attempt to recharge it or

disassemble it. Do not dispose of the old battery in a fire.

21 IC Information

This device complies with Industry Canada Licence-exempt RSSs. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference, including interference that may

cause undesired operation of the device.

Emerson Radio Corp. warrants this product to be free from manufacturing defects in original material, including original parts, and workmanship under normal home use and conditions ("manufacturing defect") for a period of ninety (90) days from date of original purchase in, and if used in the United States. Should service be necessary under this warranty, Emerson will provide the following at our Return Repair Facility provided the manufacturing defect is verified along with the date of purchase:

* Repair service for ninety (90) days from date of original purchase at no charge for labor and parts.

To Receive Authorization to Return a Defective Item, please contact Emerson Customer Service at 1-800-898-9020 or at http://www.emersonradio.com/service/return-policy.Have your Model number, Serial Number and dated Proof of Purchase with you when you call.

In the event the product must be returned to Emerson:

* Pack the unit in a well-padded heavy corrugated box. Please insure the item is well padded to avoid damage while in transit back to our facility. If the item incurs damage, it will NOT be replaced and the consumer will be responsible for return freight costs to receive their same unit back.

* Enclose your check or money order payable to Emerson Radio in the amount of \$10 to cover return shipping and handling costs.

* Enclose a note with your name, address, phone number, Return Authorization number and brief reason for returning the unit.

* Enclose a copy of your proof of purchase (warranty service will not be provided without dated proof of purchase).

* Ship the unit prepaid via UPS or parcel post (SHIP INSURED and obtain a tracking number)

NOTE: This warranty does not cover:

(a) Damage to equipment not properly connected to the product.

(b) Cost incurred in the shipping of the product to and from Emerson's Return Facility.

(c) Damage or improper operation of unit caused by customer abuse, misuse, negligence or failure to follow operating instructions (including cleaning

negligence of failure to follow operating instructions) provided with the product.

(d) Ordinary adjustments to the product which can be performed by customer as outlined in the owner's manual.

(e) Signal reception problems caused by external antenna or cable systems. (f) Products not purchased in the United States

(g) Damage to product if used outside the United States.

THIS WARRANTY IS NON-TRANSFERABLE AND APPLIES ONLY TO THE ORIGINAL PURCHASER AND DOES NOT EXTEND TO SUBSEQUENT OWNERS OF THE PRODUCT. ANY APPLICABLE IMPLIED WARRANTIES, INCLUDING THE WARRANTY OF MERCHANTABILITY, ARE LIMITED IN DURATION TO A PERIOD OF THE WARRANTY OF BUSINESS. THIS WARRANTY IS AVAILABLE ONLY. THIS WARRANTY IS STATE OF ORIGINAL PURCHASE AT RETAIL AND NO WARRANTIES, WHETHER EXPRESSED OR IMPLIED, SHALL APPLY TO THE PRODUCT THEREAFTER. EMERSON MAKES NO WARRANTY AS TO THE FITNESS OF THE PRODUCT FOR ANY PARTICULAR PURPOSE OR USE. THE EXTENT OF EMERSON RADIO CORP'S LIABILITY UNDER THE PROCESSED BY THE INFORMATION AND ANY OTHER INFORMATION AND IN NO EVENT, SHALL EMERSON RADIO CORP'S LIABILITY EXCEED THE PURCHASE PRICE PAID BY THE PURCHASER OF THE PRODUCT. UNDER NO CIRCUMSTANCES SHALL EMERSON RADIO CORP. BE LIABLE FOR ANY LOSS, DIRECT, INDIRECT, INCIDENTAL, SPECIAL, OR CONSEQUENTIAL, DAMAGE ARISING WITHOUT ANY COMPRIMANCE. THIS WARRANTY IS VALID ONLY IN THE UNITED STATES OF AMERICA. THIS WARRANTY GIVES YOU SPECIFY LEGAL RIGHTS. HOWEVER, YOU MAY HAVE OTHER RIGHTS WHICH MAY VARY FROM STATE TO STATE. SOME STATES DO NOT ALLOW LIMITATIONS ON IMPLINED WARRANTIES OR EXCLUSION OF CONSEQUENTIAL DAMAGE, WITHOUT ANY OTHER WARRANTIES.

10-90-1402A The serial number can be found on the back cabinet. We suggest that you record the serial number of your unit in the space below for future reference

Model Number: CKSW5010

Serial Number:

▲WARNING

• INGESTION HAZARD: This product contains a button cell or coin battery

• DEATH or serious injury can occur if ingested.

• A swallowed button cell or coin battery can cause Internal Chemical Burns in as little as 3 hours.

- KEEP new and used batter

- Seek immediate medical attention if a battery is suspected to be

swallowed or inserted inside any part of the boby.

CALIFORNIA RESIDENTS ONLY-

WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov

Emerson Part No. CKSW5010-20240227-00

Printed in China
