| Brand | Westinghouse |
| Model | WHSC08KS |
| Product Type | Slow Cooker |
| Capacity | Approximately 4.5 liters |
| Power | 200-300 W (estimated) |
| Voltage | 220-240 V AC |
| Dimensions (approx.) | 30 x 30 x 30 cm |
| Weight (approx.) | 3.5 kg |
| Inner Pot Material | Ceramic |
| Lid Material | Tempered glass |
| Control Type | Rotary dial |
| Cooking Settings | Low, High, Warm |
| Safety Features | Auto shut-off when dial turned to Off; cool-touch handles; caution against steam burns |
| Cleaning | Hand wash ceramic pot and glass lid with mild detergent; wipe main body with damp cloth |
| Dishwasher Safe | Not recommended (pot and lid hand wash only) |
| Warranty | 1 year limited |
| Special Features | Ceramic pot suitable for wood, nylon, plastic utensils; residual heat after use |
Frequently Asked Questions - WHSC08KS WESTINGHOUSE
User questions about WHSC08KS WESTINGHOUSE
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
Download the instructions for your Slow cooker in PDF format for free! Find your manual WHSC08KS - WESTINGHOUSE and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. WHSC08KS by WESTINGHOUSE.
USER MANUAL WHSC08KS WESTINGHOUSE
Product:
WHSC08KS
Safety Information
Important Safety Instructions....1-3
Electrical Requirements....3
Setup & Operation
Installation Guide....3
Parts & Features......4
Operation....5
Cooking Guide....6
Cleaning & Care....7
Support & Warranty
Troubleshooting....8
Peace of Mind Guarantee....10
Warranty....11-13
Important Safety Instructions
- Read all instructions carefully before using this appliance.
- Always turn the power off at the power outlet before you insert or remove the power plug. Remove by grasping the plug and do not pull on the cord.
DANGER
Immediate hazards which WILL result in severe personal injury or death.
-
DANGER: Do not operate the appliance if:
-
the power cord or plug is split, melted or damaged;
- the appliance has malfunctioned;
- the appliance has been damaged in any manner.
If any of the above incidents occur, return your appliance to the nearest authorised service center for examination, repair or adjustment.
-
DANGER: Do not attempt to disassemble, adjust or repair the appliance yourself.
-
DANGER: Do not under any circumstances immerse the power cord, mains plug or appliance body in water or any other liquid.
WARNING
Hazards or unsafe practices which COULD result in severe personal injury or death.
- WARNING: Do not touch the outer surfaces whilst the appliance is in operation. Use handles and knobs only as some surfaces may become warm whilst the appliance is in use.
- WARNING: If the power cord is damaged, it must be replaced by the manufacturer, its service agent or a similarly qualified person in order to avoid a hazard.
- WARNING: Do not cover the appliance whilst in operation as the air vents must be kept clear.
- WARNING: Ensure the appliance and it's accessories are cleaned regularly and according to the cleaning & care instructions within this user manual.
- WARNING: Do not attempt to operate the appliance with the inner pot not inserted.
- WARNING: Exercise caution when removing the glass lid from the appliance whilst it is in operation or shortly after. Steam from foods being cooked will be released when lifting the lid and could potentially cause burns or personal injury.
- WARNING: Incorrect operation and improper use may damage the appliance or parts thereof, and cause severe personal injury.
- WARNING: Do not move the appliance whilst food is present in the inner pot as hot liquids may leak out whilst moving. Instead, carefully move the inner pot individually using oven mitts.
- WARNING: Combustible materials such as paper, curtains, tablecloths, kitchen towels etc. should not be placed near the appliance whilst in operation or after.
- WARNING: Do not place the appliance against a wall or against another appliance. Leave at least 10cm free space on the back and sides and 10cm free space above the appliance.
- WARNING: Always ensure your hands are dry before handling the power cord plug or switching on the power outlet.
- WARNING: Always use oven mitts when handling the inner pot during or shortly after use.
Important Safety Instructions
CAUTION
Hazards or unsafe practices which COULD result in minor personal injury.
-
CAUTION: Close supervision is necessary when this appliance is used near children.
-
CAUTION: Keep the appliance and its power cord out of reach of children.
-
CAUTION: Wait for the appliance to cool before moving. Carry only by the handles.
-
CAUTION: Do not attempt to operate the appliance without any foods present in the inner pot, as this will cause damage to the inner pot and appliance.
-
CAUTION: Allow 30 minutes to cool down after cooking before storing or cleaning.
-
CAUTION: The appliance should not be left unattended whilst in use.
-
CAUTION: If using this appliance on a stone bench top, place a suitable chopping board or heat proof mat underneath the appliance before operating.
-
CAUTION: Do not overfill the inner pot as it may over-boil or spill-over.
-
This appliance is not intended to be operated by means of an external timer or separate remote-control system.
-
Do not permit the power cord or plug to touch hot objects or allow the power cord to lay across the appliance.
-
This appliance is deemed for use indoors only.
-
Children should not play with the appliance.
-
Always use this appliance with a power outlet of the voltage (A.C. only) marked on the rating label of the appliance.
-
Do not use the appliance for any purpose other than its intended use.
-
Do not place your appliance on or near a hot gas flame, electric element, heated oven or any hot surface.
-
Do not place the appliance on top of any other appliance.
-
Do not allow the power cord to hang over the edge of a table or bench top.
-
Keep liquids away from the insides of the appliance.
-
Do not place anything on top of the appliance.
-
Ensure the appliance is placed on a horizontal, even and stable surface.
-
This appliance is not intended for use by persons (including children) with reduced physical, sensory or metal capabilities or lack of experience and knowledge unless they have been given supervision or instruction concerning use of the appliance in a safe way by the person responsible for their safety, and understand the hazards involved.
-
This appliance is intended to be used in private households and not in applications such as:
-
staff kitchen areas, offices and other working environments;
- farm houses;
- by guests in hotels, motels and other residential type environments;
- bed and breakfast type environments;
- commercial environments.
Important Safety Instructions
- The inner pot of this appliance is suitable for use with wood, nylon and plastic utensils. Do not use any other types of utensils as they may scratch the inner pot's coating. Scratching of the inner pot coating surface is not covered by the warranty.
- The heating element of this appliance is subject to residual heat after use.
- Do not place the inner pot directly onto a stove-top or into the oven. It is a ceramic pot designed for use with this appliance only.
Electrical Requirements
Do not attempt to modify the power cord or plug in any way.
If the power cord is too short, do not use an extension cord. Have a qualified electrician or serviceman install an outlet near the appliance.
Westinghouse recommends the use of a residual current device (RCD) with a tripping current that does not exceed 30mA in the electrical circuit supplying power to all appliances
Neither Westinghouse nor the retailer can accept any liability for damage to the product or personal injury as a result of a failure to observe the electrical connection procedures or instructions within this manual.
Installation Guide
- Carefully remove the appliance from the box.
- Remove any packaging around the appliance and power cord. Do not remove any warning labels.
- Clean the appliance and it's accessories, following the Cleaning & Care instructions within this manual.
- Ensure to read the Operation instructions within this manual before your first use, and always follow these instructions when operating the appliance.
Parts & Features
- Lid Handle.
- Tempered Glass Lid.
- Ceramic Inner Pot.
- Main Body.
- Handles.
- Control Dial.
A. High
Select this setting for faster cooking times on higher temperatures.
B. Low
Recommended as slower cooking times helps to further tenderise food.
C. Warm
The appliance will keep the food warm and ready for serving.
Operation
Before your first use, ensure to clean the Ceramic Inner Pot and Tempered Glass Lid as per the Cleaning & Care instructions on page 7.
- With the appliance unplugged from the power outlet, insert the Ceramic Inner Pot into the Main Body.
- Insert the power cord plug into the power outlet and switch the power outlet on.
- Carefully add your ingredients into the Ceramic Inner Pot.
- Place the Tempered Glass Lid on top of the Ceramic Inner Pot.
- Turn the Control Dial to the desired cooking setting.
-
Once your cooking has completed, switch the Control Dial to "OFF". Carefully remove the Tempered Glass Lid by tilting the lid so that the side furthest away from you raises first.
-
Enjoy!
DANGER: Do not under any circumstances immerse the power cord, mains plug or appliance body in water or any other liquid.
WARNING: Do not touch the outer surfaces whilst the appliance is in operation. Use handles and knobs only as some surfaces may become warm whilst the appliance is in use.
WARNING: Do not cover the appliance whilst in operation as the air vents must be kept clear.
WARNING: Do not attempt to operate the appliance with the inner pot not inserted.
WARNING: Exercise caution when removing the glass lid from the appliance whilst it is in operation or shortly after. Steam from foods being cooked will be released when lifting the lid and could potentially cause burns or personal injury.
WARNING: Do not move the appliance whilst food is present in the inner pot as hot liquids may leak out whilst moving. Instead, carefully move the inner pot individually using oven mitts.
WARNING: Always use oven mitts when handling the inner pot during or shortly after use.
CAUTION: Do not overfill the inner pot as it may over-boil or spill-over.
Cooking Guide
The below table is guide for various different food types which are commonly cooked in slow cookers. As no two ingredients are the same, please use only as a guide and adjust based on your ingredients and preferences.
| FOOD TYPE COOKING SETTING TIME | ||
| Roasts / Large cuts of meat Low | 5 - 8 Hours | |
| Stews / Casseroles High 4 - 5 Hours | ||
| Soups High 4 - 5 Hours | ||
| Fish High 2 - 4 Hours | ||
| Chicken Breast / Thighs High 3 - 5 Hours | ||
| Desserts High 1 - 2 Hours | ||
Cleaning & Care
Ceramic Inner Pot & Tempered Glass Lid
- Allow the Ceramic Inner Pot and Tempered Glass Lid to cool completely before cleaning, as exposing them to water whilst hot will cause cracking and/or damage.
- Once cooled, fill the Ceramic Inner Pot with warm water and a small amount of mild detergent. Allow it to soak for 10 minutes to assist in the removal of tough baked on particles. Submerge the Tempered Glass Lid in a similar solution for 10 minutes also.
- After soaking, the pot and lid can be scrubbed with a non-abrasive cloth or plastic bristle brush. Ensure to run warm water over the pot and/or lid whilst scrubbing to ensure they are not dry whilst scrubbing.
- Ensure the pot and lid are dried thoroughly after cleaning and place them back into the Main Body.
Main Body
- Allow the Main Body to cool completely before cleaning. Ensure the appliance is unplugged from the power outlet before continuing.
- The outer surfaces of the Main Body can be wiped with a damp, non-abrasive cloth. Ensure to keep liquid away from the insides of the appliance.
- For stubborn particles on the outside of the Main Body, a mild detergent can be applied to the damp, non-abrasive cloth to aid in it's removal.
- Ensure the outer surfaces are dried thoroughly before re-inserting the dried inner pot and lid.
- Store the complete appliance in a dry place away from steam and humidity where possible.
DANGER: Do not under any circumstances immerse the power cord, mains plug or appliance body in water or any other liquid.
WARNING: Ensure the appliance and it's accessories are cleaned regularly and according to the cleaning & care instructions within this user manual.
WARNING: Always ensure your hands are dry before handling the power cord plug or switching on the power outlet.
CAUTION: Allow 30 minutes to cool down after cooking before storing or cleaning.
Troubleshooting
Before calling for service, if the appliance fails to operate:
- Check that the appliance is plugged in correctly and securely. If it is not, remove the plug from the power outlet, wait 10 seconds and then plug it back in correctly and securely.
- Inspect your home's circuit breakers to see if any have blown or tripped. If these seem to be working correctly, test another appliance in the same power outlet to ensure the power outlet is working correctly. If appropriate, test the appliance in another power outlet within your house.
- Ensure that you have read and followed all instructions within this manual, including but not limited to the instructions within the following segments of this manual:
»Important Safety Instructions;
»Electrical Requirements;
»Installation Guide;
»Operation;
»Cleaning & Care.
- Review the below Troubleshooting chart and attempt to remedy the issue if appropriate/applicable in your situation.
TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY
| Food is not heating sufficiently. | Lid is not placed on the pot. | Ensure the lid is placed on the pot whenever cooking, as this traps the heat inside the pot whilst cooking. |
| Higher cooking setting is required. | Try cooking at a higher cooking setting if appropriate for the food being cooked. | |
| Uneven cooking of the ingredients in one meal. | The ingredients are of varying size. | Ensure all ingredients are of the same size for even cooking throughout the meal. |
| Meat is not browning in the slow cooker. | Most slow cookers do not reach temperatures suitable for searing. | Quickly sear the meat in a frypan first before cooking in the slow cooker. |
If none of the above solves the problem, DO NOT try to adjust or repair the appliance yourself.
Should you be unable to contact your place of purchase for assistance or resolution, call our customer service centre at:
Australia:
1300 883 109 / Mon-Fri 8:00am - 4:00pm WST
New Zealand:
0508 776 546 / Mon-Fri 8:30am - 4:30pm NZDT
Westinghouse
Visit our website for FAQ's, helpful tips & hints or to leave a review.
Peace of Mind Guarantee
Our Westinghouse small appliances are backed by a 12 month guarantee as part of our dedication to provide quality products for our customers. This means that if you purchase a Westinghouse small appliance which has a manufacturer defect/fault, or does not meet the seller's specifications as a result of a defect/fault, then the seller will either repair or replace the unit, or refund the purchase price of the unit at their own discretion (refer to clause 4 of the Limited Warranty).
This does not apply to products which have been misused/abused, poorly maintained or serviced, damaged due to negligent handling, accidentally damaged or normal wear and tear. Ensure to follow all instructions within this instruction manual, including the Cleaning & Care section for correct maintenance. (See page 7)
Your warranty does not cover the following:
- Damage caused by power surges, voltage supply issues, power dips or usage of the incorrect voltage.
- Damage caused by service or modification of the unit which are not performed by authorised service centres or personnel.
- Damage caused by the use of accessories, attachments, consumables, parts or devices which are not produced for the product by Westinghouse and it's licensees.
- Damage caused by exposure of the product to abnormally corrosive conditions.
- Damage caused by incorrect or improper operation and/or installation.
- Damage caused by a failure to follow additional instructions.
- Products which have had the serial number and/or rating label removed.
- Usage of the product which are outside of the intended applications (refer to page 1-2).
- Freight costs incurred during a claim, consumables, loss, damage or accessories which require periodic replacement by nature (filters, seals etc.).
How to claim under this warranty:
- Carefully check the operating instructions, user manual and the terms of this warranty;
- Have the model and serial number of the appliance available;
- Have the proof of purchase (e.g. receipt) available;
- Return the unit to place of purchase;
- If unable to return to the place of purchase, call our service centre on 1300 883 109.
If your warranty claim is accepted, the product may be replaced with a similar or refurbished unit or repaired using refurbished parts. If your warranty claim is not accepted, the seller will inform you and provide any further options which are available in your situation. If the product is to be repaired or shipped as a result of this, you will be responsible for the cost of repair and/or any freight charges incurred.
To register your product, view the most up-to-date user manuals and FAQ's, visit the product page by scanning the QR code on your product's cord label.
Limited Warranty
- Nothing in this Warranty affects the Consumer's rights under the Australian Consumer Law. The benefits to the Consumer under this Warranty are in addition to the rights and remedies of the buyer under any Consumer Guarantees. The Australian Consumer Law requires that we confirm that:
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
- Subject to Clause 1, the Seller warrants that Westinghouse branded products will be free of manufacturing defects and will perform to the Seller's specifications subject to the following clauses.
- The benefit of this Warranty extends only to the owner of the property in which the Products manufactured or supplied by the Seller are installed and used by the owner for the duration of the Warranty Period under standard domestic applications.
- The Warranty commences on the date of the purchase of the product and continues for the benefit of the Owner for the Warranty Period. If within the Warranty Period a manufacturing defect is discovered in the Product, or the Product fails to perform to the Seller's specifications as a result of some defect in material or workmanship in the Product, then the Seller will at its own discretion:
a. Repair or replace the Product at the cost of the Seller. Goods repaired or replaced under this Warranty will be warranted for the remaining period of the Warranty. Products presented for repair may be replaced by refurbished products of the same type rather than being repaired. Refurbished parts may be used to repair the products.
b. Refund the purchase price paid by the consumer.
- The Warranty does not apply to Product that :
a. Has failed due to excessive wear and tear beyond what is considered to be reasonable.
b. Has been misused or neglected.
c. Has been damaged accidentally or by acts of God including fire and flooding.
d. Has been used or operated contrary to operating or maintenance instructions.
e. Has been damaged by the Consumer or a third party authorised to act for the consumer in transit from the Sellers store to the Consumer.
f. Has been modified, altered or tampered with by unauthorized persons.
g. Damage caused by insects or vermin and claims based on the presence of insects or vermin.
h. Has been used in commercial situations or applications.
Limited Warranty
It also excludes breakables such as glass and ceramic items, consumable items such as those that require periodic replacement as part of the ordinary use, lack of care or maintenance of the product or as directed by the instruction booklet, minor cosmetic issues (including, without limitation, paint and coatings) and normal wear and tear, and does not cover the cost of claiming under the warranty or transporting the goods to and from the place of purchase.
-
In order to make a claim under the Warranty, the Owner must, where possible return the goods to the Seller's store at the Owner's cost. Proof of purchase must be supplied in all cases.
-
The seller will examine any returned Products and if the Seller determines that there is an apparent defect through no fault of the Owner, the Seller will:
a. Make note of the Owner's contact details including the Owner's telephone number which the owner can be contacted during business hours, postal address and e-mail address.
b. Make note of the defects reported by the Owner.
c. Take back the defective goods from the owner and determine within a reasonable time through dialogue with the Seller whether the goods are defective.
d. Advise the owner within a reasonable time frame whether it accepts or rejects the Product claim.
e. If the Seller accepts the return of the Product, the Seller must arrange to have
i. The Product repaired or,
ii. Replace the damaged or faulty Product or,
iii. Refund the purchase price.
Note that repairs or replacements may be done with refurbished items or parts, or replaced with a similar item.
- The Seller will not accept any returned Product which has not been returned strictly in accordance with this Warranty.
Limited Warranty
9. For the purpose of this Warranty:
a. Australian Consumer Law means the law as set out in Schedule 2 of the Competition and Consumer Act 2010 (Cth).
b. Consumer means the Purchaser of goods from the seller.
c. Consumer means a Consumer as that term is set out in section 3 of the Australian Consumer Law.
d. Consumer Guarantees means the guarantees under the Australian Consumer Law.
e. Implied terms means any guarantees, conditions, warranties or other terms implied by any Australian Commonwealth, State or Territory laws, (excluding the Australian Consumer Law) or the law of any other jurisdiction.
f. Owner has the meaning set out in clause 3.
g. Warranty means this warranty.
h. Product means the Product/s bought by the Owner from the Seller that fall under this warranty.
i. Warranty Period means:
i. In relation to Cast Iron Cookware: 3 Year Limited Warranty
ii. In relation to Non-Stick Cookware: 3 Year Limited Warranty
iii. In relation to Cooking Utensils: 3 Year Limited Warranty
iv. In relation to Knives/Knife Block Sets: 3 Year Limited Warranty
v. In relation to Stainless Steel Cookware: 10 Year Limited Warranty
vi. In relation to Chopping boards: 1 Year Limited Warranty
vii. In relation to Small Appliances: 1 Year Limited Warranty
1300 883 109
13 Merino Entrance, Cockburn Central 6164, WA
and Westinghouse are trademarks of Westinghouse Electric Corporation.
Used under license by RVM Australia Pty Ltd.
- User Manual
- Contents
- Safety Information
- Setup & Operation
- Support & Warranty
- Important Safety Instructions
- DANGER
- WARNING
- CAUTION
- Electrical Requirements
- Installation Guide
- Parts & Features
- Operation
- Cooking Guide
- Cleaning & Care
- Ceramic Inner Pot & Tempered Glass Lid
- Main Body
- Troubleshooting
- Australia:
- New Zealand:
- Westinghouse
- Peace of Mind Guarantee
- How to claim under this warranty:
- Limited Warranty
- For the purpose of this Warranty:
Brand : WESTINGHOUSE
Model : WHSC08KS
Category : Slow cooker
