Product Type	Ice Maker
Model	SF32010N
Brand	Swan
Input Voltage	220-240V
Frequency	50/60Hz
Ice Making Current	0.9A
Ice Harvest Current	1.4A
Refrigerant	R134a / 75g
Net Weight	12.3 kg
Control Panel	On/Off button, Ice size selection (Small, Medium, Large), Indicators for Power, No Water, Ice Full
Ice Making Time	Approx. 6 to 15 minutes per cycle
Water Reservoir Capacity	Not specified; fill to MAX level mark
Ice Basket Capacity	Not specified; automatically stops when full
Clearance Required	At least 10 cm on all sides for ventilation
Water Drain	Via drain cap at bottom of reservoir
Cleaning	Unplug, drain water, wipe interior with mild detergent, do not immerse
Warranty	2 years from date of purchase (UK and Ireland only)
Safety Certification	CE, EMC, LVD, RoHS, Food Contact compliant
Electrical Plug	BS 1363 plug, must be earthed
Usage Environment	Household and similar (e.g., offices, farm houses, hotels)

Frequently Asked Questions - SF32010N SWAN

How do I start making ice for the first time?

Remove packaging, clean the interior with lukewarm water, place the ice maker on a level surface with at least 10 cm clearance. Open the lid, remove the ice basket, and pour water into the tank up to the MAX level. Press the Power button to begin the ice making cycle.

How do I select the ice cube size?

Press the Select button (F) on the control panel to toggle between Small, Medium, and Large ice cube sizes. If room temperature is below 60°F (15°C), it is recommended to choose Small or Medium to prevent ice from sticking together.

How long does it take to make ice?

The ice making cycle typically lasts 6 to 15 minutes, depending on the selected ice size and ambient temperature. In very warm rooms, the time may vary.

What do the indicator lights mean?

Power indicator (D): lights when unit is on. No Water indicator (B): lights when water reservoir is empty; unit stops automatically. Ice Full indicator (C): lights when the ice basket is full; unit stops automatically.

How do I clean the ice maker?

Always unplug the unit first. Drain any remaining water using the drain cap. Remove the ice basket and wipe the inside of the tank with a soft cloth moistened with mild detergent. Rinse and dry thoroughly. Clean the exterior with a soft cloth. Never immerse the unit in water.

How often should I change the water?

Change the water in the reservoir every 24 hours to maintain hygiene. If the unit is not in use, drain all water from the tank.

Why did the ice maker stop making ice?

The unit may stop if the water reservoir is empty (No Water indicator on) or the ice basket is full (Ice Full indicator on). Fill water or remove ice as needed. Also, ensure the unit has been level and not overheated. Allow at least 3 minutes for the compressor to settle before restarting.

Can I use an extension cord?

It is not recommended. If necessary, use a heavy-duty extension cord rated for the appliance's power to avoid overheating. Do not place the cord where it can be pulled or tripped over.

What is the warranty period?

This product is guaranteed for 2 years from the date of original purchase. Defects due to faulty materials or workmanship must be returned to the place of purchase with proof of purchase. The warranty is valid in the UK and Ireland only.

Can children use this ice maker?

Children aged 8 years and above can use the appliance if supervised and instructed on safe use. Cleaning and maintenance should not be performed by children unless they are older than 8 and supervised. Keep the appliance and cord out of reach of children under 8 years.

USER MANUAL SF32010N SWAN

White square ice cream maker with open lid and control panel, no visible text or symbols on the device itself.

Ice Maker

IMPORTANT INFORMATION - RETAIN FOR FUTURE USE

When using any electrical appliance, basic safety precautions should always be followed including the following:

• Always ensure that the voltage on the rating label corresponds to the mains voltage in your home
• Incorrect operation and improper use can damage the appliance and cause injury to the user.
• This appliance can be used by children aged from 8 years and above if they have been given supervision or instruction concerning use of the appliance in a safe way and if they understand the hazards involved. Cleaning and user maintenance shall not be made by children unless they are older than B and supervised. Keep the appliance and its cord out of reach of children aged less than 8 years. Check the power cord and plug regularly for any damage. If the cord or the plug is damaged, it must be replaced by the manufacturer or qualified person in order to avoid an electrical hazard.
• Do not use the appliance if it has been dropped or damaged in any way. In case of damage, take the unit in for examination and/or repair by an authorised service agent.
  • Never immerse the unit in water or any other liquid for cleaning purposes.
• Remove the plug from the socket by gripping the plug. Do not pull on the cord to disconnect the appliance from the mains. Always unplug the unit when not in use, before cleaning or when adding or removing parts.
• The use of accessory attachments that are not recommended or supplied by the manufacturer may result in injuries, fire or electric shock.
• Do not let the cord hang over the edge of a table or counter. Ensure that the cord is not in a position where it can be pulled on inadvertently.
• Do not allow the cord to touch hot surfaces and do not place on or near a hot gas or electric burner or in a heated oven.
• Do not use the appliance on a gas or electric cooking top or over or near an open flame.
• Use of an extension cord with this appliance is not recommended. However, if it is necessary to use an extension lead, ensure that the lead is suited to the power consumption of the appliance to avoid overheating of extension cord, appliance or plug point. Do not place the extension cord in a position where it can be pulled

IMPORTANT INFORMATION - RETAIN FOR FUTURE USE

• Do not carry the appliance by the power cord.
- Do not leave the appliance unattended during use. Always unplug the unit when not in use or before cleaning.
- Always operate the appliance on a smooth, even, stable surface. Do not place the unit on a hot surface.
• Ensure that the unit is switched off after use.
- The manufacturer does not accept responsibility for any damage or injury caused by improper or incorrect use, or for repairs carried out by unauthorised personnel.
- In case of technical problems, switch off the product and do not attempt to repair it yourself. Return the appliance to an authorised service facility for examination, adjustment or repair. Always insist on the use of original spare parts. Failure to comply with the above mentions precautions and instructions, could affect the safe operation of this product.
- Your appliance must never be switched on through an external timer or any kind of separate remote control system
- NEVER IMMERSE THE UNIT IN WATER OR OTHER LIQUID. DO NOT RUN UNDER THE TAP
- This appliance is intended to be used in house hold and similar application such as: staff kitchen areas in shops, offices and other working environments; farm houses; by clients in hotels, motels and other residential type environments; bed and breakfast type environments.

TECHNICAL DATA

Description: Ice Maker

Model: SF3201ON

Input Voltage: 220-240V

Frequency: 50/60Hz

Ice Making Current: 0.9A

Ice Harvest Current: 1.4A

Refrigerant: R134a/75g

Net weight: 12.3kg

Vesicant: R141b/C, H,

FIRST USE

1. Remove the exterior and interior packaging. Check that ice basket and ice scoop is included. If any parts are missing, please contact our customer service.
2. Clean the interior with lukewarm water and a soft cloth. Take out the ice basket and clean it
3. Find a location for your ice maker that is protected from direct sunlight and other sources of heat (e.g: stove, furnace, radiator). Place the ice maker on a level surface. Make sure that there is at least 10cm of space between the book

HOW TO USE

1. Select the size of the ice cube by pressing the "Select" button (F). If the room temperature is lower than 60F, it is recommended to select the small or medium ice sign button in order to avoid ice sticking together.
2. Open the cover, remove the ice basket and pour water into tank. Keep water level below the water MAX level mark.
3. Press "Power" button on the control panel to begin the ice making cycle.
4. The ice making cycle lasts approx. 6 to 15 minutes, depending on the size of the ice cube selection and the ambient temperature. In a very warm room, ice-making time may vary a lot.
5. While the icemaker is on, verify water level periodically. If water pump can't inject water, the ice maker will stop automatically, and the "Add Water" indicator (B) will be on.
6. If tank needs refilling, press "Power" button, fill water up to the MAX water level mark and press "Power" button again to turn on the unit
7. Allow the refrigerant liquid inside the compressor at least 3 minutes to settle before restarting.
   B. The ice maker automatically stops working when the ice basket is full and the "Ice" indicator (C) will be on.
8. Change water in the water reservoir every 24 hours to ensure a reasonable hygiene level.
9. If unit isn't in use, drain all water left in the tank.

CLEANING

• Always unplug the ice maker before cleaning
- Drain the water from the tank using the drain plug after each use or the water will go stale
- Take out the ice basket and wipe the inside of the tank with a soft cloth moistened with a mild detergent solution.
• Dry with kitchen towel
• Clean the outside of the ice maker with a soft cloth
• Do not use abrasive or strong chemical cleaners
• NEVER IMMERSF THE UNIT IN WATER OR RUN I UNDER THE TAP

DOCUMENTATION

We Swan Products Ltd declare that this product conforms to the following product legislation in accordance with the following directive[s]:

2004/108/EEC The EMC Directive (the Electromagnetic Compatibility Directive).

2006/95EC. The LVD Directive (Low Voltage Directive).

2011-65 EU. The RoHS directive (Restriction of Hazardous Substances Directive)

EC 1935/2004 Food Contact

DISPOSAL OF UNIT

Appliances bearing the symbol shown here may not be disposed of in domestic rubbish. You are required to dispose of old electrical and electronic appliances like this separately. Please visit www.recyclemore.co.uk or www.recyclenow.co.uk for access to information about the recycling of electrical items. Please visit www.weeeinland.ie for access to information about the recycling of electrical items purchased in Ireland. The WEEE directive, introduced in

August 2006, states that all electrical items must be recycled, rather than taken to landfill. Please arrange to take this appliance to your local Civic Amenity site for recycling, once it has reached the end of its life.

WARRANTY

This product is guaranteed for 2 years from the date of original purchase. If any defect arises due to faulty materials of workmanship the faulty products must be returned to the place of purchase. Refunds or replacement is at the discretion of the store.

The following conditions apply:

• The product must be returned to the retailer with proof of purchase.
- The product must be installed and used in accordance with the instructions contained in this instruction guide.
• It must be used only for domestic purposes.
- It does not cover wear and tear, damage, misuse or consumable parts.
• Swan Products Ltd has limited liability for incidental or consequential loss or damage.
• This guarantee is valid in the UK and Fire Only.

BS PLUG

The wires in the mains lead are coloured in accordance with the following code:

BLUE NEUTRAL

BROWN LIVE

GREEN/YELLOW EARTH

As the colours of the wire in the mains lead of this appliance may not correspond with the colour markings identifying the terminals on your plug, proceed as follows:

The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or coloured black. The wire which is coloured BROWN must be connected to the terminal which is marked with the letter L or coloured red. The wire which is coloured GREEN/YELLOW must be connected to the terminal which is marked with the letter E or [earth symbol] and is coloured GREEN or GREEN/YELLOW.

WARNING: THIS APPLIANCE MUST BE EARTHED
