Yukon 6 - Tent Wood's - Free user manual and instructions

Product Type	Tent
Brand	Wood's
Model	Yukon 6
Capacity	6 persons
Floor Size	20' x 10' (6.1 m x 3 m)
Center Height	6' 4" (1.93 m)
Weight	29 lb (13.2 kg)
Pole Material	Aluminum
Pole Count	8
Rainfly	Included
Gear Loft	Included
Stakes	20 aluminum V pegs
Water Repellency	Water-repellent, not waterproof; seam seal recommended
Flame Resistance	Meets CPAI-84, not fireproof
Cleaning	Brush off dirt; for stains, spray water and lightly wipe; do not machine wash or dry
Storage	Must be clean and dry before storage; store off concrete floor
Warranty	7-day replacement for defects; 2-year limited replacement parts
Assembly	Two adults recommended; detailed step-by-step instructions included
Safety Warning	Do not use fuel-burning devices inside; keep flame sources away
Replacement Parts	Available; contact 1-855-966-3785
Country of Origin	Not specified in manual

Frequently Asked Questions - Yukon 6 Wood's

How many people does the Wood's Yukon 6 tent accommodate?

The Yukon 6 is designed to sleep up to 6 persons comfortably.

What are the dimensions and weight of this tent?

The floor size is 20' x 10' (6.1m x 3m), center height 6'4" (1.93m), and weight is 29 lb (13.2 kg).

Is the tent waterproof?

The tent is water-repellent but not fully waterproof. During heavy rain, some leakage may occur. It is recommended to apply seam sealer to inside seams for better weather resistance.

How do I prevent condensation inside the tent?

Condensation occurs when warm moist air meets cooler tent walls. To reduce it, vent doors and windows, avoid touching the walls, and store wet clothing outside. A battery-powered fan can help.

Can I use a stove or heater inside the tent?

No, never use fuel-burning devices such as stoves, lanterns, or heaters inside the tent. They produce carbon monoxide and consume oxygen, leading to risk of asphyxiation or death.

What is the warranty on this tent?

There is a 7-day replacement warranty for defects found upon purchase, and a 2-year limited warranty on replacement parts for material or workmanship defects. Normal wear, misuse, and weather damage are not covered.

How do I clean and store the tent?

Allow dirt to dry, then brush off. For stains, spray with water and lightly wipe. Do not machine wash or dry. Always ensure the tent is completely dry before storing, and store it off concrete to prevent mildew.

What should I do if the zipper separates?

Zippers are self-repairing. Move the slider to the beginning of the zipper tape and rework the zipper to fix separation.

How do I repair a tear in the fabric?

For small tears, use a self-adhesive patch kit. For larger tears, consult a canvas or awning repair shop.

How long does assembly take and do I need tools?

Assembly typically takes 15-30 minutes with two adults. You will need a hammer or mallet for stakes, but all poles and hardware are included. The manual provides step-by-step instructions.

USER MANUAL Yukon 6 Wood's

DANGER!

Stoves, lanterns, candles, grills, heaters and other fuel-burning devices produce carbon monoxide and will consume the available oxygen in a tent. Use of such devices in a tent may cause asphyxiation, carbon monoxide poisoning, and death or serious and permanent injuries. For this reason:

- DO NOT use fuel-burning devices inside or near this product. - Your failure to follow this warning may cause death or serious and permanent injury to you or others.

WARNING!

- KEEP ALL FLAME AND HEAT SOURCES AWAY FROM THIS

FABRIC. This product is made with flame-resistant fabric, which meets CPAI-84 specifications. IT IS NOT FIREPROOF! The fabric will burn if left in continuous contact with any flame source. The application of any foreign substance to the fabric may render the flame-resistant properties ineffective. - Anchor properly at all times and carefully consider campsite choice. Be aware of possible falling rocks or tree limbs, lightning strikes, flash floods, strong winds and other hazards which may cause harm to this product or its occupants. - Have a minimum of two adults for assembly. During assembly poles are under tension. If not held firmly in place during assembly, poles could break or flip up, possibly causing serious injury. - Safety glasses may be worn throughout the assembly process as an additional precaution. - Exercise care when using electric devices in and near tents.

CLEANING:

Allow dirt to dry on the fabric after a rainfall before lightly sweeping it off with a brush. For tougher stains, spray the area with water and lightly wipe it off with a few strokes. Do not use washer or dryer. DO NOT SCRUB THE FABRIC. ALWAYS MAKE SURE IT IS COMPLETELY DRY BEFORE REPACKING.

CTC 7-DAY REPLACEMENT WARRANTY

Unpack and inspect all contents for defects in workmanship and materials within 7 days of purchase. If any defects are found, return the product to the place of purchase, along with the proof of purchase, and it will be replaced free of charge.

2-YEAR REPLACEMENT PARTS LIMITED WARRANTY

This product carries a replacement parts warranty against defects in materials and workmanship for a period of 24 months from date of purchase. At its discretion, the manufacturer may provide replacement parts. Original purchaser will be required to provide proof of purchase. The consumer will be responsible for shipping costs incurred outside of the U.S. or Canada.

Warranties DO NOT cover normal wear and tear, misuse, abuse, inclement weather conditions (i.e. wind, rain, hail, lightning, tornadoes or hurricanes) or other acts of God, mildew and rotting, damage or fading caused by prolonged exposure to UV rays. This warranty gives you specific legal rights. You may also have other rights which vary depending on locale. Under no circumstances shall the manufacturer be liable for any incidental or consequential damages.

The tent is water-repellent. It is not waterproof. During heavy or continuous rain, some leakage may occur. Avoid contact between objects and the inside of the tent, as this may result in leakage at points of contact. In the event of seam leakage, apply a seam-sealer compound.

Although our products are manufactured according to rigorous specifications, periods of wind or rain may loosen the stakes and cause the frame to sink into the ground. This will weaken the structure's overall rigidity. Puddles may also form on the roof if the unit has not been assembled tightly. If pooling should occur, it is advisable to drain the fly to avoid possible damage to frame and fabric. Adjustment of guy lines may be necessary. In case of inclement weather, remove valuables and seek appropriate shelter. Intended for recreational use only.

For your tent, screen house or canopy DO NOT...

• Pitch near an open fire.
• Use candles or open flames of any kind inside or near it.
• Leave children unattended inside.
• Use fuel-burning, oxygen-consuming devices (heaters, lanterns, cooking stoves or other flame sources) inside.
• Refuel lamps, heaters or stoves inside.
• Smoke inside.
• Store flammable liquids inside.
• Use water-repellent compounds other than those recommended for use on outdoor equipment.
• Spray with insecticide.
• Store on concrete floor

For your tent, screen house or canopy DO...

• Always extinguish campfire before sleeping or leaving the area.
• Exercise care when using electricity and lighting.
• Make certain it is properly ventilated in all weather conditions. In extreme weather conditions, snow could obstruct airflow and cause asphyxiation. Clear frequently.
• Anchor securely to provide additional security in changing climatic conditions. Snow pegs, skis and/or heavy rocks may be necessary to supplement stakes and guy lines.
• Take down and store properly after camping.

For service call:

1-855-Woods 85

1-855-966-3785

CAMPERS' TIPS

The key to an enjoyable camping experience is planning and preparation.

Before you go ...

Research the area where you intend to camp. Prepare for any possible weather condition. Be aware of hazards and emergency protocol. Know the rules and regulations.

Check out your equipment before your trip. Be sure your cook stove, lanterns, flashlights, air mattress, etc., are in good working order. Erect your tent to become familiar with setup. Once you've assembled your tent in a dry, well-ventilated area, apply seam-sealing compound to the stitching of the inside seams following manufacturer's directions. Allow to dry thoroughly before storage. Reapply annually.

Checklists are great planning tools. Here are some areas to consider.

Camp setup: Tent, chairs, table, ground cloth, entrance mat, tarp, poles, rope, stakes, bungee cords, duct tape, zip ties, hammer/tools, bedding.

Kitchen setup, food and beverages: Plan for transport, preparation, storage and disposal. Remember to pack fire-starting devices in waterproof containers, and bring pots, dishes, utensils, can opener, heavy-duty garbage bags and biodegradable soap. Store your food in lockers or out of sight in vehicles.

Clothing: Be prepared for all your activities. Include a hat, sunglasses and quality socks. Dress in layers.

Hygiene: Personal toiletries, rubber gloves, basic first aid items. Don't forget your medications.

Miscellaneous: Extra batteries, sewing kit, clothespins, dust pan/brush and insect-repellant.

Be considerate of others, humans and wildlife. Remember to clean up and dispose of waste properly. "Leave no trace behind."

ASSEMBLY INSTRUCTIONS

IMPORTANT NOTES:

* Assemble your tent before camping to become familiar with the assembly. * Two people are recommended for setup. * Select a clean, level area for the campsite, free of debris and sharp objects, away from a natural watercourse. * Use of a ground cloth is recommended to prolong the life of the tent floor and provide additional insulation and moisture protection. * To prevent damage to the zippers, unzip the doors and windows of the tent prior to disassembly, allowing air to move freely. * Seam seal the inside stitched seams of the tent. This will improve weather resistance. Available in sporting goods departments. Discolouration may occur if applied to outside seams.

Step 1: Verify package contents □ Tent:1 each

□ Rainfly: 1 each

□ Aluminum Poles : 8 each

(A) Main 2 each (Green) (B) Roof 2 each (Orange)

(C) Front & Rear Fly 2 each (Green)

(D) Side Leg 2each (Orange)

□ Gear loft w/TP : 1 each □ Tent Stakes: 20 each

Step 2: Assemble poles 1) Assemble the aluminum poles by inserting the tapered ends into the adjacent sections. Eight aluminum poles are provided: 2 each (A) Main (Green)

2 each (B) Roof poles (Orange)

2 each (C) Front & Rear Fly (Green)

2 each (D) Side Leg (Orange)

Step 3: Spread out tent, insert poles

1) Spread out the tent flat, floor side down. 2) Insert the roof poles (A, green) and poles (B, orange) through the sleeves. 3) The poles will cross at the centre of the roof.

Step 4: Raise the tent

1) With a person holding each end of a main pole (A), flex the pole into an arch. Carefully place the bottom of the leg poles into the pin at tent corners. 2) Repeat for the second main pole. 3) Adjust pole position so the perimeter of the tent is taut.

Step 5: Secure side leg pole

1) Using the illustration below as a guide. Place the side leg poles (D) in the centre of the attached mold. With the capped end in the attached mold place the bottom of the pole onto the squeeze pin at the stake loop. 2) Repeat for other side leg pole. 3) Place the roof poles (B) into the mold.

Step 6: Secure the tent

1) Stake down the tent. 2) Hammer the stakes into the ground at a 45-degree angle using a hammer or mallet. 3) Attach the plastic hangers to the poles.

Step 7: Secure fly pole

1) Insert the fly pole (C) through the fly pole sleeve located at the top over the front & rear door. 2) Place pole ends onto the grommets located at the stake loop.

1) Attach hooks and buckles along the edge of the fly to o-rings and buckles along the perimeter of the tent. 2) Close the front panel position and stake into place at the front fly corners. The fly front panel can be rolled up and fastened at the fly pole.

Step 9: Secure guy lines

1) Secure using all guy lines and stakes. The tent must be secured for proper function.

Note: Interior accessories can be attached to the loops inside the tent.

Step 10: Disassembly Step 11: Packing the tent

1) To take down the tent, disassemble in reverse order of assembly. 2) Remove accessories. 3) Remove and fold fly. 4) Be sure to leave doors and windows unzipped to avoid zipper damage. 5) Remove stakes with hammers or stake puller. DO NOT pull on tent. 6) Carefully disengage poles from fast feet. Carefully push pole away from you through the hanger to minimize risk of damage to tent or poles. 7) Keep stakes in bags provided.

Step 8: Fasten the fly

1) Spread tent flat, distribute evenly. 2) Fold into quarters not to exceed the length of pole bag.

3) Lay pole bag at opposite end from door. Tightly roll bag, skin and fly forcing air through unzipped door.

4) Secure with ties and place in carry bag with stakes and accessories. 5) Tent must be clean and dry before storage. Store off concrete floor.

Be certain campfires are extinguished. Dispose of trash appropriately.

SPECIFICATIONS: 6 persons
Floor	size:	20' x 10' (6.1x3)
Centre	height:	6'4"
Weight:		29 lb

REPLACEMENT PARTS

KEY NO.	MODEL NO. CTC162010(076-5519-8)		QTY. REQ.
	DESCRIPTION	PART NO.
A	Aluminum pole - Main (Green) HAP13-167+	288+167pb	2
B	Aluminum pole - Roof (Orange)	HAP13-286a,c	2
C	Aluminum pole - Front & Rear (Green)	HAP13-185+108+185pb	2
D	Aluminum pole - Side Leg (Orange)	HAP16-150c	2
	Rain Fly	HTFCTC162010	1
	Gear loft w/TP	HGL1210w/TP	1
	Aluminum V peg	HAS-7	20

TROUBLESHOOTING GUIDE
PROBLEM	SOLUTION
CONDENSATION	Condensation occurs when warm moist air inside tent comes in contact with cooler outside air. Avoid touching walls to reduce contact leakage. Venting doors and windows will reduce condensation. Store wet clothing outside of tent. A battery powered fan may be helpful. Not applicable to screen houses.
SEAM LEAKAGE	Apply a generous amount of seam sealer on inside seams. Seam sealer may be purchased at any local sporting goods store.
MILDEW	To avoid mildew, store tent/screen house ONLY when thoroughly dry. However, if mildew occurs, use a soft bristle brush or sponge with mild dishwashing soap or Fels Naptha soap to clean. Let dry thoroughly, and a tent approved water repellent compound may be applied.
REPAIRING A TEAR	For small tears, use a self-adhesive patch kit. We recommend a canvas or awning repair shop for larger tears.
FAULTY ZIPPER	Zippers are self-repairing. If the zipper separates, you can move the slider to the beginning of the zipper tape and rework the zipper.
FADING FABRIC	Do not leave up in direct sunlight longer than necessary. If left in sunlight for prolonged periods of time, fabric will fade and weaken.
FLOOR CONDENSATION	A ground cloth under the floor helps prolong its life, provides additional insulation and moisture protection. The cloth should be smaller than the floor to prevent rain from running under the tent. Not applicable to screen houses.
USE OF STAKES	Stakes should be installed at a 45° angle using a hammer or mallet. Stake loops should be kept taut without over-stretching fabric or webbing. This could cause tears or leakage. To remove safely, use a hammer or stake puller. Do not remove by pulling on the fabric.
