| Product Type | Multi-Service Access Router |
| Brand | Allied Telesis |
| Model | AR410 |
| Dimensions (W x D x H) | 200 x 140 x 40 mm |
| Weight | 0.5 kg |
| Power Supply | 12V DC, 1A |
| Power Consumption | 12W (max) |
| WAN Interface | VDSL2/ADSL2+ |
| LAN Interfaces | 4 x Gigabit Ethernet |
| USB Port | 1 x USB 2.0 |
| Wireless | 802.11b/g/n (optional) |
| VPN Support | IPsec, PPTP, L2TP |
| Firewall | Stateful packet inspection (SPI) |
| QoS | Traffic shaping and priority |
| Management | Web GUI, CLI, SNMP |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -20°C to 70°C |
| Humidity | 5% to 90% non-condensing |
| Certifications | CE, FCC |
| Maintenance | Clean with dry cloth; no liquids |
| Safety | Do not disassemble; use only supplied adapter |
| Spare Parts | Power adapter, mounting brackets |
| Reparability | Professional repair only; no user-serviceable parts |
Frequently Asked Questions - AR410 Allied Telesis
How do I reset the Allied Telesis AR410 to factory defaults?
Press and hold the Reset button on the back panel for 10 seconds until the LEDs flash. Release and the router will reboot with factory settings.
What is the default IP address and login for the AR410?
The default IP address is 192.168.1.1. Username: admin, Password: admin (or blank, check label).
Can I use the AR410 as a wireless router?
The AR410 supports an optional 802.11b/g/n module. If installed, you can enable it via the web interface under Wireless settings.
How to configure a VPN on the AR410?
Go to VPN > IPsec or PPTP in the web GUI. Enter your server details and authentication. Apply settings and connect.
What type of DSL connection does the AR410 support?
It supports VDSL2 and ADSL2+ with automatic detection. Check your line and ensure correct encapsulation (e.g., PPPoE).
How to update firmware on the AR410?
Download the latest firmware from Allied Telesis support. In the web GUI, go to Administration > Firmware Upgrade, select the file, and upload.
The AR410 is not getting an IP from my ISP. What should I do?
Check WAN cable connection. Verify ISP settings: use PPPoE if required, enter username/password. Clone MAC address if needed. Restart modem/router.
How to set up QoS on the AR410?
Navigate to QoS in the web GUI. Define traffic classes and priorities. Apply rules to limit bandwidth or prioritize VoIP/gaming.
Can I use the USB port on the AR410?
Yes, the USB port can be used for USB storage sharing (FTP/SMB) or connecting a 3G/4G modem as backup WAN.
How to configure VLANs on the AR410?
Under Switch or VLAN settings, create VLAN IDs and assign ports. Use 802.1Q tagging for trunk links.
