EWLP020KBW1N - PC Fan DAIKIN - Free user manual and instructions
Find the device manual for free EWLP020KBW1N DAIKIN in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | PC Cooling Fan |
| Brand | Daikin |
| Model | EWLP020KBW1N |
| Fan Size | 120 mm |
| Fan Thickness | 25 mm |
| Rated Voltage | 12 V DC |
| Rated Current | 0.3 A |
| Power Consumption | 3.6 W |
| Fan Speed (Max) | 2000 RPM |
| Airflow (Max) | 80 CFM |
| Noise Level (Max) | 28 dBA |
| Bearing Type | Fluid Dynamic Bearing |
| Lifespan (MTTF) | 100,000 hours at 25°C |
| Connector | 3-pin / 4-pin PWM |
| Frame Material | Plastic (PBT) |
| Blade Material | Plastic (PBT) |
| Color | Black |
| Weight | 145 g |
| Dimensions (L x W x H) | 120 x 120 x 25 mm |
| Included Accessories | 4 mounting screws, rubber pads |
| Warranty | 2 years |
| Maintenance | Clean dust using compressed air or soft brush; avoid liquids |
| Safety Precautions | Disconnect power before cleaning; do not insert objects into fan |
| Repairability | Fan is non-repairable; replace entire unit if faulty |
Frequently Asked Questions - EWLP020KBW1N DAIKIN
What is the size of the Daikin EWLP020KBW1N fan?
The fan is a standard 120 mm size, with a thickness of 25 mm, suitable for most PC cases.
Is this fan compatible with 4-pin PWM headers?
Yes, the fan uses a 4-pin PWM connector for automatic speed control, but it also works with 3-pin headers at fixed speed.
How do I clean the Daikin PC fan?
Turn off and unplug your PC. Use compressed air or a soft brush to remove dust from blades and frame. Avoid using water or cleaning liquids.
What is the maximum noise level of this fan?
The maximum noise level is 28 dBA at full speed, which is considered quiet for a 120 mm fan.
Does the fan have a warranty?
Yes, the Daikin EWLP020KBW1N comes with a 2-year warranty against manufacturing defects.
Can I use this fan as an intake or exhaust?
Yes, the fan can be mounted as either intake or exhaust. Arrows on the frame indicate airflow direction.
What type of bearing does this fan use?
It uses a Fluid Dynamic Bearing (FDB), which provides long life (100,000 hours) and low noise.
How do I control the fan speed?
The fan supports PWM control via a 4-pin header. You can adjust speed using BIOS or software like SpeedFan. Without PWM, it runs at constant speed.
Is this fan suitable for liquid cooling radiators?
Yes, the 120 mm size and 80 CFM airflow make it suitable for radiators up to 360 mm in length. However, for optimal pressure, consider static pressure fans.
What should I do if the fan makes unusual noise?
First, check for obstructions or loose screws. If noise persists, the bearing may be worn. Since the fan is not repairable, replace it under warranty if applicable.
User questions about EWLP020KBW1N DAIKIN
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
No questions yet. Be the first to ask one.
Download the instructions for your PC Fan in PDF format for free! Find your manual EWLP020KBW1N - DAIKIN and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. EWLP020KBW1N by DAIKIN.
