| Product Type | Standard pneumatic cylinder |
| Brand | Festo |
| Model | EPCC-BS-60-125-5P-A |
| Bore Diameter | 60 mm |
| Stroke Length | 125 mm |
| Operating Medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| Operating Pressure | 1.5 ... 10 bar |
| Piston Rod Diameter | 16 mm |
| Cushioning | Pneumatic cushioning, adjustable on both sides |
| Position Sensing | For proximity sensors (on request) |
| Ambient Temperature | -20 ... +80 °C |
| Weight | Approx. 1.8 kg |
| Mounting Type | With accessories (foot, flange, clevis) |
| Materials | Aluminum barrel, stainless steel piston rod, NBR seals |
| Maintenance | Check seals and lubrication every 6 months; clean with mild detergent |
| Safety Precautions | Do not exceed max pressure; use lockout/tagout during servicing |
| Spare Parts | Seal kit, piston rod, cushioning screws |
| Repairability | Replaceable seals and rod; serviceable by qualified personnel |
| Standards | ISO 6431 (bore), VDMA 24562 |
Frequently Asked Questions - EPCC-BS-60-125-5P-A Festo
What is the operating pressure range for the Festo EPCC-BS-60-125-5P-A?
The recommended operating pressure is between 1.5 and 10 bar. Never exceed the maximum pressure to avoid damage.
Can this cylinder be used with non-lubricated air?
Yes, the cylinder can operate with non-lubricated air, but using filtered, lubricated air extends seal life and reduces wear.
How do I adjust the cushioning on the cylinder?
Use the adjusting screws on both end caps. Turn clockwise to increase cushioning (softer stop) and counterclockwise to decrease.
What type of sensors can be used for position sensing?
Use Festo proximity sensors (e.g., SME/SMT series) designed for T-slot cylinders. Install them in the slot on the barrel.
Is the piston rod corrosion-resistant?
Yes, the piston rod is made of stainless steel and hard-chrome plated for high corrosion resistance in harsh environments.
What maintenance is required for this cylinder?
Inspect seals and rod surface every 6 months. Clean the exterior with a mild detergent. Lubricate if necessary using Festo oil.
Can I mount the cylinder in any orientation?
Yes, the cylinder can be mounted horizontally, vertically, or at an angle. Ensure proper drainage of condensate for vertical mounting.
What is the maximum force output at 6 bar?
The theoretical force is approximately 1696 N (thrust) and 1583 N (retract) based on a 60 mm bore and 16 mm rod at 6 bar.
How do I replace the seals?
Refer to the service manual. Remove the cylinder from service, disassemble end caps, remove old seals, and install new ones from the seal kit. Torque to spec.
What is the warranty period for Festo cylinders?
Festo standard warranty is 24 months from the date of delivery for manufacturing defects under normal operating conditions.
