KPI6022B - Cooker Kluge - Free user manual and instructions
Find the device manual for free KPI6022B Kluge in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Induction Hob |
| Brand | Kluge |
| Model | KPI6022B |
| EAN | 8588008219379 |
| Dimensions (L x W x H) | 590 x 520 x 58 mm |
| Cutout Dimensions (L x W) | 565 x 495 mm |
| Number of Cooking Zones | 4 |
| Power Supply | 220-240 V, 50/60 Hz |
| Total Power | 7.2 kW |
| Control Type | Touch Control |
| Power Levels | 9 |
| Boost Function | Yes |
| Child Lock | Yes |
| Automatic Shutdown | Yes |
| Residual Heat Indicator | Yes |
| Hob Surface Material | Ceramic Glass |
| Cleaning | Wipe with damp cloth, use glass ceramic cleaner |
| Installation Type | Built-in |
| Warranty | 2 years |
Frequently Asked Questions - KPI6022B Kluge
What type of cookware is compatible with the Kluge KPI6022B induction hob?
Only cookware with a magnetic base (iron, steel, or induction-ready stainless steel) is compatible. To check, use a magnet if it sticks, it works.
How do I clean the hob surface?
Allow the hob to cool completely. Wipe with a damp cloth and mild detergent. For stubborn stains, use a glass ceramic cleaner and a soft sponge. Avoid abrasive pads.
What is the total power consumption of the KPI6022B?
The total power is 7.2 kW. Ensure your electrical installation can support this load (typically a 32A circuit).
Does the hob have a child lock?
Yes, the KPI6022B is equipped with a child lock function. Refer to the manual to activate and deactivate it.
What are the cutout dimensions required for installation?
The required cutout dimensions are 565 mm (L) x 495 mm (W). The hob itself is 590x520 mm.
Can I use a wok on this induction hob?
Yes, but you need a flat-bottomed induction-compatible wok. Round-bottom woks will not work properly.
What does the residual heat indicator mean?
A red indicator light shows that the cooking zone is still hot even after being turned off. Do not touch until it disappears.
The hob shows an error code. What should I do?
Common error codes: E0 (no cookware), E2 (overheating), E3 (voltage issue). Consult the manual for specific codes. If persistent, contact customer support.
Is the hob self-cleaning?
No, the hob requires manual cleaning. However, the smooth ceramic surface makes it easy to wipe clean.
How long is the warranty period?
The Kluge KPI6022B comes with a standard 2-year warranty. Keep your purchase receipt.
User questions about KPI6022B Kluge
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
No questions yet. Be the first to ask one.
Download the instructions for your Cooker in PDF format for free! Find your manual KPI6022B - Kluge and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. KPI6022B by Kluge.
USER MANUAL KPI6022B Kluge
KPI6022B
Three identical cooking pots with crossed-out X marks, placed on a flat surface (no text or symbols)natural_image
Four identical cooking pots with crossed-out X marks, shown in sequence (no text or symbols)natural_image
Two cooking pots with crossed arrows indicating opposing pressure directions (no text or symbols)natural_image
Line drawing of a cooking pot on a stand (no text or symbols)natural_image
Two identical gray circular objects with cross marks connected by lines, enclosed in a dashed square frame (no text or symbols)
| 590 | 520 | 58 | 54 | 565 | 495 | 50 Min. |
Three identical cooking pots with crossed X marks on their bases, no text or symbols presentnatural_image
Four identical cooking pots with crossed-out X marks, shown in sequence (no text or symbols)Nádoby zdvíhajte – neposúvajte ich po skle, aby sa nepoškriabalo.
Line drawing of a cooking pot on a stand (no text or symbols)| L(mm) | W(mm) | H(mm) | D(mm) | A(mm) | B(mm) | X(mm) |
| 590 | 520 | 58 | 54 | 565 | 495 | 50 Min. |
| A (mm) | B (mm) | C (mm) | D | E |
| 760 | 50 min | 20 min | Prívod vzduchu | Výstup vzduchu 5 mm |
Pred inštaláciou dosky skontrolujte, že:
Diagram of a steam machine with cooling unit and two control panels, no text or symbols presentgarnek żelazny
Three identical cooking pots with crossed-out X marks, no text or symbols presentnatural_image
Two cooking pots with crossed arrows indicating opposing pressure, one with a cross symbol and the other with bidirectional arrows (no text or labels)natural_image
Line drawing of a cooking pot on a stand (no text or symbols)| L(mm) | W(mm) | H(mm) | D(mm) | A(mm) | B(mm) | X(mm) |
| 590 | 520 | 58 | 54 | 565 | 495 | 50 Min. |
