Product Type	Microwave Oven
Model	SMW 1617BK
Brand	SENCOR
Capacity	20 Liters
Power Output	700 W
Power Input	1050 W
Voltage	230 V ~ 50 Hz
Dimensions (W x H x D)	451 x 262 x 352 mm
Net Weight	11.0 kg
Cavity Interior Dimensions	306 x 206 x 304 mm
Control Type	Digital with LED Display
Number of Power Levels	10
Timer	Up to 99 minutes 99 seconds
Defrost Function	Yes, by weight or time
Auto Cook Menus	6 preset menus
Child Lock	Yes
Turntable Diameter	245 mm
Door Opening	Side opening
Interior Light	Yes
Material	Stainless steel / Plastic
Colour	Black
Warranty	2 years

Frequently Asked Questions - SMW 1617BK SENCOR

How do I set the cooking time on my SENCOR SMW 1617BK microwave?

Press the Time/Weight button, then turn the dial to set the desired cooking time (up to 99 min 99 sec). Press Start to begin.

Can I use metal containers in the microwave?

No. Metal can cause sparks and damage the unit. Only use microwave-safe glass, ceramic, or plastic containers. Refer to the manual for safe materials.

How do I clean the microwave interior?

Unplug the microwave. Wipe the interior with a damp cloth and mild soap. Do not use abrasive cleaners. For odors, place a bowl of water with lemon juice and heat for 2 minutes.

Why does my microwave not heat food evenly?

Ensure the turntable is rotating freely. Stir or rotate food halfway through cooking. Overloading or improper container shape can also cause uneven heating.

How do I use the defrost function?

Press the Defrost button. Enter the weight of the food using the dial. The microwave will automatically set time and power. Turn food over when prompted.

What does the child lock feature do and how to activate it?

Child lock prevents accidental operation. To activate, press and hold Stop/Clear for 3 seconds until a beep sounds. Repeat to deactivate.

Can I use the microwave without the turntable?

No. The turntable ensures even cooking. If broken, order a replacement (part number: SMW1617BK-TT) from SENCOR service.

What is the maximum power consumption of this microwave?

The input power is 1050 W. The microwave output is 700 W. Ensure the outlet is rated for at least 10 A.

How do I set the clock on the microwave?

Press and hold Clock for 3 seconds. Turn the dial to set the hour, press Clock again, turn to set minutes. Press Clock to confirm.

Where can I find spare parts for my SENCOR SMW 1617BK?

Contact SENCOR authorized service centers or visit the official website. Common parts like the turntable, fuse, and door latch are available.

USER MANUAL SMW 1617BK SENCOR

Black Siemens 500 microwave oven with control knobs and front panel (no visible text or symbols)
