LTO1207-030C - Washing machine Exquisit - Free user manual and instructions

Product Type	Washing Machine
Brand	Exquisit
Model	LTO1207-030C
Energy Class	A (61 kWh/year)
Capacity	7.5 kg
Water Consumption	46 L per cycle
Noise Level (Wash/Spin)	80 dB
Program Duration (Eco 40-60)	3 hours 31 minutes
Dimensions (H x W x D)	85 x 60 x 50 cm
Installation Type	Freestanding
Loading Type	Front Load
Spin Speed	1200 rpm
Number of Programs	15
Quick Wash	Yes (15 min)
Child Lock	Yes
Delay Start	Up to 24 hours
Self-Cleaning	Drum clean program
Noise Level (Spin)	80 dB
Power Supply	220-240 V, 50 Hz
Weight	Approx. 65 kg

Frequently Asked Questions - LTO1207-030C Exquisit

How do I clean the detergent drawer?

Remove the drawer by pressing the release lever, rinse under warm water, and wipe with a soft cloth. Reinsert fully.

What should I do if the machine doesn't start?

Check that the door is closed properly, the water supply is on, and the child lock feature is not activated. Also ensure the program selector is set correctly.

How often should I clean the pump filter?

Clean the pump filter every 2-3 months to prevent blockages. Turn off the machine, unplug it, and open the filter cover at the bottom front to remove debris.

Why is the washing machine vibrating excessively?

Ensure the machine is level on the floor and that transport bolts have been removed. Also check for unbalanced loads; redistribute clothes evenly.

Can I use liquid detergent in the dispenser?

Yes, but pour liquid detergent into the correct compartment (usually marked with "II") and use the provided liquid detergent insert to avoid overdosing.

What does the error code 'E10' mean?

Error E10 indicates a water inlet issue. Check that the tap is fully open and the inlet hose is not kinked. Clean the inlet filter if necessary.

How do I perform a drum cleaning cycle?

Run the 'Drum Clean' program (if available) with an empty machine, using a special cleaner or a cup of white vinegar. This removes odors and bacteria.

What is the maximum spin speed?

The maximum spin speed is 1200 rpm for most cotton programs. Adjust using the spin speed selector.

How can I reduce energy consumption?

Use the Eco 40-60 program for normally soiled cotton loads, wash at lower temperatures (20-30°C) when possible, and run full loads to maximize efficiency.

Where can I find spare parts?

Spare parts are available from authorized dealers or online spare parts shops. Always quote the model number LTO1207-030C for compatibility.

USER MANUAL LTO1207-030C Exquisit

exquisit

LTO1207-030C weiss

61kWh

7,5kg

3:3146L

A B CDEFG

ABCD
