| Product Type | Actuator / Switch |
| Dimensions (H x W x D) | 45 x 45 x 20 mm |
| Weight | 0.1 kg |
| Power Supply | 230V AC, 50/60Hz |
| Rated Current | 10 A |
| Main Functions | On/Off control, switching of loads |
| Mounting Type | Flush mounting in wall box |
| Connection Type | Screw terminals |
| Material | Thermoplastic, V0 rated |
| IP Rating | IP20 (indoor use only) |
| Operating Temperature | -10°C to +40°C |
| Storage Temperature | -20°C to +60°C |
| Certifications | CE, VDE |
| Care & Cleaning | Wipe with a dry cloth; do not use abrasive cleaners |
| Safety Instructions | Installation must be performed by a qualified electrician; disconnect power before servicing |
| Spare Parts Availability | Replacement modules and covers available from authorized dealers |
| Repairability | Modular design allows easy replacement of internal components |
| Compatibility | Compatible with standard 60mm wall boxes |
| Brand | JUNG |
| Model | MAA1021 |
Frequently Asked Questions - MAA1021 JUNG
What is the purpose of the JUNG MAA1021?
The JUNG MAA1021 is an actuator or switch designed for on/off control of electrical loads in residential or commercial installations.
What are the dimensions of the device?
The device has dimensions of 45 x 45 x 20 mm (H x W x D), suitable for flush mounting in standard wall boxes.
What power supply does it require?
The MAA1021 operates on 230V AC, 50/60Hz with a rated current of up to 10 A.
Is professional installation required?
Yes, for safety reasons, installation must be carried out by a qualified electrician following local regulations.
Can I use the MAA1021 outdoors?
No, the device has an IP20 rating, meaning it is only suitable for indoor use in dry environments.
Does it require a neutral wire?
Typical JUNG switches may require a neutral wire; please check the wiring diagram in the manual. Some models are designed for two-wire control.
What type of loads can it switch?
It can switch resistive and inductive loads up to 2300 W (10 A). For detailed load types, refer to the product datasheet.
How do I clean the device?
Clean the surface with a soft dry cloth. Avoid using water, solvents, or abrasive cleaners.
Are spare parts available for the MAA1021?
Yes, JUNG offers replacement modules and covers through authorized dealers. The modular design facilitates easy repair.
What certifications does it have?
The device is CE and VDE certified, ensuring compliance with European safety and performance standards.
