Product Type	Eurorack Bass Drum Module
Model	BD909
Brand	Tiptop Audio
Module Width	8 HP
Depth	30 mm (with power cable)
Power Consumption	+12V: 40 mA, -12V: 20 mA
Inputs	Trigger In (1/8" jack), Accent In (1/8" jack)
Outputs	Audio Out (1/8" jack), Accent Out (1/8" jack)
Controls	Level, Tune, Decay, Attack, Pitch Envelope, Tone
Sound Engine	Analog synthesis with discrete components
Main Features	Classic 909 bass drum sound, voltage-controlled parameters, trigger and accent inputs
Construction	3U Eurorack, aluminum front panel, PCB mounted pots and jacks
Weight	Approx. 100 g
Operating Temperature	0°C to 50°C
Power Supply Requirements	Standard Eurorack power bus board with +12V and -12V
Included Accessories	Power cable, mounting screws
Cleaning Instructions	Wipe with a dry or slightly damp cloth; avoid solvents
Safety Warnings	Do not expose to moisture or extreme temperatures; disconnect power before removing from case
Spare Parts Availability	Contact Tiptop Audio or authorized dealers for replacement parts
Repairability	Designed for repair; schematics available on request

Frequently Asked Questions - BD909 Tiptop Audio

What is the BD909 module?

The BD909 is a Eurorack module by Tiptop Audio that reproduces the classic bass drum sound of the Roland TR-909, using analog circuitry with discrete components.

What power does the BD909 require?

It requires +12V at 40 mA and -12V at 20 mA from a standard Eurorack power supply. Do not reverse the power cable.

How many HP wide is the BD909?

The module is 8 HP wide.

What are the main controls on the BD909?

Controls include Level, Tune, Decay, Attack, Pitch Envelope, and Tone. These allow shaping the bass drum sound.

What inputs and outputs does the BD909 have?

It has Trigger In, Accent In, Audio Out, and Accent Out. All are 1/8" mono jacks.

Can the BD909 be used with other modules?

Yes, it is designed to be triggered by other modules (e.g., sequencers, drum pattern generators) and can be mixed with other audio outputs.

How do I clean the BD909?

Use a soft, dry cloth. If needed, slightly dampen with water. Do not use alcohol or solvents.

Is the BD909 repairable?

Yes, it is designed for repair. Tiptop Audio provides schematics upon request and spare parts are available through dealers.

What is the weight of the BD909?

Approximately 100 grams.

Where can I find the user manual for the BD909?

The manual is available for free download from the Tiptop Audio website or from notice-facile.com.

USER MANUAL BD909 Tiptop Audio

The BD909 is a recreation of Roland's TR-909 analog bass drum sound generator adapted for modular synthesizer use. The front panel contains all of the controls found on the original TR-909 drum machine, allowing you full control over the sound's volume levels to mix with other drums and accent levels, decay tune and the envelope attack and decay segments. In addition to those original controls we have also added new controls, further enhancing this legendary sound generator.

Let's get started.

To start using the BD909, just plug a gate signal into the GATE input, plug the BD OUT to your sound system, set the LEVEL half way, set the Overload knob to min, set the ACCENT to halfway.

Tuning explained.

The BD909 contain three tuning control knobs plus a VC tune with attenuator knob for scaling the control signal. This wide range of tune shaping enhances the original circuit, turning it into a real analog bass drum laboratory. The OSC TUNE knob is there to let you offset the starting and ending frequency of the bass drum sound. The Tune Decay is the original tune knob found in the 909 machine but with a slightly extended range. The Tune Attack is a new control which not only adds variation to the sound, it also affects the Tune Decay knob, therefore creating many more sweet spots than found on the original. The combination of these three knobs are the main synthesis tools of the BD909.

Overload explained.

The BD909 is based on a triangle VCO and a sine wave shaper that filters the triangle harmonics and producing a wave which sounds more like a sine wave. The overload knob and CV input form a control circuit that was added to the waveshaper, letting you overload the waveshaper circuit, therefore adding more odd harmonics to the wave shape. In low doses this means more punch, and as you keep overloading, the sounds get distorted up to total destruction.

Dynamics and Gain.

Accent and Levels:

Dynamic Accent and Level control of any drum sound in the mix is a big part of making a beat sound right. Dynamic Accent provides emphasis on a particular note through loudness. In analog circuits like the BD909, the accent pulse physically "hits" the internal envelope circuit harder and provides not only a louder sound but also slightly more attack (much like if you were to hit a real bass drum harder with a drum stick.)

While the original 909 has one global accent knob for setting accents levels for all of its sounds, the BD909 (and all other drum modules in this series) offers an independent accent level control. This feature adds to richer dynamics than what was possible with the original machine.

Accent Explained:

The accent input can be driven by either a gate/trigger or CV signal.

While the accent input is not in use, the incoming gate input is routed (normalized) to both the accent input and the gate input. This serves for two purposes:

1. To allow you to reach the hottest drum sound possible even when there is no accent input signal connected.
2. It makes the ACCENT knob act as a fine control of the output gain level. This is very useful in situations where the level knob range is too coarse for setting precise levels in a mix with other drum sounds.

Connecting a gate or CV signal into the accent input will break the internal routing mentioned above and will allow for independent control over accent regardless of the incoming gate signal. In this case as long as there is no accent signal present, the drum sound will be set to the minimum accent level set internally, and once the accent input gets hit by a gate or CV signal, the drum sound will get louder in proportion to the accent level set by the accent knob. In short: the higher the knob setting, the larger the difference will be in gain levels between the accented notes and the un-accented notes. Using CV allows for even greater variations.

The sound of the BD909.

The BD909 really shines when it is played alongside a nice big bass line. Most of the energy of the BD909 is centered in the mid range of the sonic spectrum, the result being that there is headroom for deep low bass lines to fill up the lower end without “fighting” the bass drum in the mix. This quality of the BD909 makes it a real joy to work and mix with. Try mixing two Z3000’s set to 30-50HZ into the Z2040 with a snappy envelope from the Z4000 to the Z2040 FM IN. Set the Z2040 frequency very low so it creates a bass line and mix that with the BD909; you get a great-feeling groove that is full of energy.
