SE-MASTER1 - Headphones PIONEER - Free user manual and instructions

Product Type	Open-back reference headphones
Driver Diameter	50 mm
Impedance	45 Ω
Frequency Response	5 Hz – 85 kHz
Maximum Input Power	1500 mW
Sound Pressure Level	93 dB/mW
Weight (approx.)	440 g (without cable)
Cable Length	3.0 m (detachable)
Connector Type	6.3 mm stereo plug
Earpad Material	Leather (genuine)
Headband Material	Magnesium alloy
Special Features	Large-diameter magnesium dome drivers, bass reflex system
Cleaning	Wipe with dry or slightly damp cloth; avoid solvents
Safety Instructions	Avoid long-term exposure to high volumes; keep away from moisture
Spare Parts Availability	Replacement earpads and cables available from Pioneer
Warranty	2 years (depending on region)

Frequently Asked Questions - SE-MASTER1 PIONEER

What is the impedance of the Pioneer SE-MASTER1 headphones?

The impedance is 45 Ω, making them suitable for high-end headphone amplifiers.

Are the earpads replaceable?

Yes, the earpads are replaceable. You can order genuine replacement parts from Pioneer or authorized dealers.

Can I use these headphones with a smartphone?

While possible, the high impedance (45 Ω) may result in lower volume. A dedicated headphone amplifier is recommended for optimal performance.

How do I clean the headphones?

Use a dry or slightly damp cloth to wipe the headband and earpads. Do not use chemicals or abrasive cleaners.

What is the frequency response range?

The frequency response is 5 Hz to 85 kHz, covering the entire audible spectrum and beyond.

Is the cable detachable?

Yes, the cable is detachable and uses a standard 6.3 mm stereo plug. Replacement cables are available.

What kind of sound signature do the SE-MASTER1 have?

They are known for a neutral, highly detailed sound with excellent imaging and soundstage, typical of open-back reference headphones.

Can I use a balanced cable with these headphones?

No, the stock connection is unbalanced 6.3 mm. Aftermarket balanced cables may exist but are not officially supported.

How long is the warranty?

The warranty varies by region, typically 2 years from the date of purchase.

Are replacement parts available for the headband?

The headband is not user-replaceable, but Pioneer offers repair services. Contact support for assistance.

USER MANUAL SE-MASTER1 PIONEER

Long Beach, California 10510

www.PfizerElectronics.com/Home

www.PioneerElectronics.com/Home

Pioneer, and the noncontrolling rights are registered trademarks of Pioneer Corporation, and used by Pioneer & Corp. USA Corporation under license: APLC 01235 and the APLC 01235 (Logan) noncontrolling trademarks of Air Solutions, Inc. (the period with the Internal Audio logo is a version to the Internal Audio document defined by Japan Auto Society, this figure is used under license from Japan Auto Society, UK 210 Pioneer & Corp. USA Corporation). All rights reserved. Note: Specifications and design subject to change without notice.

DELIVERING THE EXHILARATION OF MUSIC TO THE WORLD.

ONE VISION AT THE HEART OF OUR HISTORY IN SOUND.

Pioneer's history in quality audio equipment began 80 years ago, with the vision of delivering the joy of music to people far and wide. In 1937, we produced the A-B, the first dynamic speaker to be produced in Japan, and we have been committed to high fidelity sound reproduction ever since. Whether we are making home speakers, our speakers or headphones, our focus is always on the pure, faithful reproduction of sounds.

We have been developing and producing ground-breaking headphones for more than half a century, starting with the SE-1 headphones in 1960.

Now we're writing the next chapter in our long history of technical supremacy and purity in sound design.

THE FLAGSHIP SE-MASTER1 CONTINUES OUR LEGACY. WELCOME TO THE FUTURE OF SOUND REPRODUCTION.

HALF A CENTURY OF GROUND-BREAKING HEADPHONE TECHNOLOGY

1960 1971 1973 1974 1975 1977 1979 1980

SE-1

The Pioneer' headphones story beg us. These fully enclosed, dynamic SE-to-used stereo sound to deliver a wide sound stage.

EF-100

A doubletated light-weight 3F-100s, which used electrostatic technology rather than magnetic inputs to achieve a superf sound

58-7015

These consumer-oriented, luly enclosed headphones remained a bit for a long time, we released them as the 70b, 25b, 30b and 40b ser-

SE-700

The world's first high-polymer elemental headphones. Van Gole Sim and Too Furri prices at the preating due design awards in Italy.

MONITOR 10

The classic Monitor 10s were designed for monitoring in broodges, studies - but received excellent retires from audio professions and multipholes alike.

SE-11

Popular head-tomes that used our proprietary high-grade, variable chamber and open-set design to reproduce an extremely natural, dynamic sound.

SE-1000

Premium hexachones with HA-100 amplifiers, the 5–1000s were acclaimed as the ultimate example at electrostatic technology's crystal clear sample:

MASTER-16

Variable chamber, open-air headphones that benefited from decades of headphone technology knowledge.

2015

COMBINING TECHNOLOGICAL LEADERSHIP WITH VISIONARY INNOVATION.

Close-up of a Pione headphones with black and silver headband, no visible text or symbols on the device itself.

Open-air dynamic stereo headphones

SE-MASTER1

air

studios

MAX FOR REFERENCE

MIRCS

AUDIO

Person in lab coat handling a small cylindrical object with a green needle, possibly a test tube or tool (no visible text or symbols)

MADE IN JAPAN

HAND-CRAFTED BY A MASTER

Nothing is held back in the production of these Rajah p headphones. Each SI-MA51-R1 is ascertained by a monster specialist at the Tohoku Pioneer Plant, Yamagata Prefecture - the birthplace of many iconic speaker models. We pour our advanced technic optical overview into every step of the journey - from design to production and quality control - so your headphones deliver excellence without compromise.

Person in a lab coat operating a microscope under dark lighting (no visible text or symbols)

THE JOY STARTS THE MOMENT YOU TOUCH THE HEADPHONES. EVERY ELEMENT WAS DESIGNED FOR YOUR LISTENING PLEASURE.

THE INDUSTRY'S FIRST ALUMINIUM DIAPHRAGM WITH CERAMIC COATING

THE LIGHTWEIGHT, 25μ-THICK ALUMINIUM DIAPHRAGM IS TREATED WITH A CERAMIC COATING TO ADD RIGIDITY, ENHANCE ITS NATURAL PERFORMANCE, AND DELIVER EXCELLENT SOUND QUALITY. THE RESULT IS A HIGH-RESOLUTION SOUND ACROSS ALL FREQUENCIES WITH MINIMUM NOISE.

Close-up of a metallic, ribbed glass or turbine blade with a circular top (no text or symbols visible)

Rigid diaphragm edges eliminate distortion
The disaphragm's edges are rubbed and made with a sturdy poly ether, other ketone (PEEK) film to deliver a smooth sound and reduce distortion.

OPTIMUM SOUND QUALITY ACHIEVED

USING COMPUTER AIDED ENGINEERING Our specialists used Computer Aided Engineering (CAD) to select, prototype and test the best materials for the diaphragm and magnetic circuits, ensuring superb sound characteristics and clarity.

SUPERIOR HIGH-RESOLUTION PLAYBACK The SI-MAS LIRs are capable of reproducing high-resolution audio of up to 85,000 Hz, more than double the mini-mur requirement for high-res headphones (40,000 Hz). So you can experience every undetected detail of your high-res music.

SNUO FITTING, 50FT EAR PADS FOR EXTRA COMFORT

Too many three-dimensional ear pads adapt to in your contours thanks to a proprietary design using two thicknesses of memory form - thin at the front and thick at the back. The ear clips are one with a soft heat power rendered for extra comfort.

Close-up of a black hardcover head with ear connector, shown against dark background (no text or symbols visible)

FLOATING STRUCTURE FOR LOW DISTORTION AND CLEAR SOUND SEPARATION

Rubber is inserted in the links between the base, housing and hanger parts to prevent vibrations and interference. Inferred from our sponsor ranges, the floating structure also comprises separation between left and right to deliver an enhanced sound stage.

LIGHTWEIGHT BUILD AND NATURAL FIT

The headband and hangar parts use a super durale min alloy to achieve a light, natural fit that data you target everything but the music you're immersed in.

Close-up of metallic curved metal bands with smooth surfaces (no text or symbols visible)

CUSHION FOR ADDED STABILITY

The wise, succo feel head cushion can be adjusted to 14 o Different positions, giving you excellent comfort and stability of home.

Exploded view diagram of a mechanical bearing assembly (no text or symbols)

INTERCHANGEABLE TENSION RODS TO ELIMINATE WEARER FATIGUE

The SP-MAST-REI's feature the industry's first, detachable lateral pressure rods, enhancing you to choose your preferred head-toe tension. Simply change the tension rod to achieve either more or less lateral pressure and enjoy superb sound isolation are comfortable wear over long periods.

DETACHABLE, ROBUST,

TANGLE-FREE CORD The robust, cord uses a detectable R-VECS type connector so you can replace the cord as needed. The card is cloth-wrapped besides the plagi and the branch and lead with lead-free PVC from the branch to the ear cup - to reduce touch noise, increase strength, and eliminate tangias.

ALUMINIUM HOUSING ENSURES TIOHT BASS

AND CLEAR MID AND HIGH FREQUENCIES 3.5mm-thick aluminium alloy housings minimises resonance from the cover units to produce an accurate sound with a clearly defined, right base and high-mass media and highs

FULL BASKET SYSTEM DELIVERS AN

ENERGETIC, LOW-RESONANCE SOUND Originally developed for an speaker, the full basket system reduces resonance while delivering an energetic sound. The speaker unit is firmly secured using aluminium and the base is finished with AGA rear, which adds excellent reading resistance.

3D rendering of a mechanical component with concentric rings and mounting holes (no text or symbols visible)

TAKE THE SOUND OF YOUR HEADPHONES TO ANOTHER LEVEL WITH THE HIGH RESOLUTION HEADPHONE AMPLIFIER U-05

Black-and-white photo of a portable electronic device with headphones and cables, next to a monitor (no visible text or symbols)

The U-35 headphones amplifier features a high-grade D/A converter to reproduce high resolution digital sound sources. Combine with the SI-MAS II RT headphones for an audio experience that is out of this world.

DSD

Direct Stream Digital

Type Open-air dynamic Closed-front, open-back Cable 3.0 m OFC life wire

Driver units 650 mm (modium magnet) Plug 40.3 mm standard stereo plug (gold plated)

Sensitivity _d DE Weigh, 600g (without cable, tension rid)

Frequency response 5 Hz to 15 000 Hz

Maximum input power 500 mW

Impedance 45.0

Accessories

Tension rod A, a1.6 mm (product sold with rod A in place) Tension rod B, a2.0 mm

ENGRAVED SERIAL NUMBER

Each SF MASTER1 is engraved with its own serial number, making it unique to you.

BALANCED XLR CABLE (SOLD SEPARATELY)

A balanced XLR cable is available for the SL-MAS LRT, deal for use with a headphone ampulier to deliver superior sound quality. Features a NEUTRK-manufactured XLR connector on the headphone end, and both connectors are gold plated to reduce contact loss

Close-up of black audio/video cables with two connectors and metallic connectors (no visible text or symbols)

Balanced X_R cable for SE-MASTER1

JCA XI R3M Jml

EXPERIENCE THE JOY OF THE SE-MASTER1 AT WWW.PIONEERELECTRONICS.COM/HOME

Nighttime exterior view of a Gothic-style church with illuminated windows and a blue-tinted spire, featuring a 'GIF' logo at the bottom (no signage on main structure)

GIF

studios

MONITOR REFERENCE

SE-MASTER1

Approved AIR Studios Monitor Reference Headphones

AIR Studios in London is world-famous for it's matchless music production facilities and is the recording studio of choice for many iconic artists. The SE-MASTERIs are the first headphones ever to be named AIR Studios Monitor Reference Headphones, a rare honour that we wear with pride.

PUTTING THE SE-MASTER1 TO THE TEST WITH AIR STUDIOS

AIR Studios's technical director Tim Vira-Lott was integral in the tuning of the 50-MASILTVs. Tim's discerning ears helped us to compare the headshones to premium reference speaker systems and identify the adjustment needed to ensure the headphones delivered the same sound quality. This process of line-tuning was repeated until, the headphones met AIR Studios high standards, delivering faithful reproduction of all sound sources from this reason to the most subtle nights to the deepest base.

Interior view of a audio recording studio with a large control console and multiple speakers (no visible text or labels)

AIR Studios was established in 1962 by world famous producer Sir George Martin. Since them has earned a reputation as the world's most recording source, earning the trust of many world famous artists.

TIM VINE-LOTT

AIR Studios Technical Director

I've tuned many audio products in the past, but tuning the SL-MASIL. It was an interesting and challenging experience, completely different to working with amplifiers and speakers. Headphones have none of the adjustable electric circle you'd find an amplicator or speaker systems, and the smallest change could have unexpected effects on sound quality - e.g. it was slightly altered the size of the hole controlling the backpressure of the driver units. But working with Pioneer's engineers, we were able to achieve the best sound quality. I really hope everyone will enjoy the wander in sound of the SL-MASIL FRT.

As technical director at AIR Studios, Jim Vine-I still has been involved in producing countless albums for artists and soundtracks for films. Responsible for granting AIR Studio Certification to audiovisual products that pass strict standards, he works with Pioneer in tuning our amplicators, speakers and now headphones.
