Product Type	Pipe freeze protection heating cable kit with thermostat
Brand	Fantini Cosmi
Model	K10CKIT (available in lengths: 3m, 6m, 9m, 14m)
Cable Diameter	9 mm
Power Supply	230V - 50Hz
Constant Power Output	~10 W/m
Thermostat Setting	ON at +5°C / OFF at +15°C
Maximum Ambient Temperature (Powered)	65°C
Minimum Installation Temperature	-5°C
Protection Rating	IPX7
Compliance	2014/35/EU; EN60335-1; CE marked
Cable Composition	Thermoplastic with earth braiding and outer sheath
Plug Type	Schuko plug (Type F)
Minimum Storage Temperature	-20 to -25°C
Accessories	K50 fixing tape (metal pipes), K50AL fixing tape (plastic pipes), KFAN warning labels
Recommended Insulation Thickness	20-40 mm depending on pipe size
Application	Prevents freezing of pipes, valves, taps, water meters, tanks

Frequently Asked Questions - K10CKIT Fantini Cosmi

What is the Fantini Cosmi K10CKIT?

It is a pipe freeze protection heating cable kit with an integrated contact thermostat, designed to prevent damage from low temperatures on pipes, valves, and small tanks.

How does the thermostat work?

The thermostat automatically switches the cable ON when the temperature drops below +5°C and OFF when it rises above +15°C.

How do I install the heating cable?

Simply unroll the cable along the pipe, secure it with the appropriate fixing tape (K50 for metal pipes, K50AL for plastic pipes), and plug it into a 230V socket. The cable must be as long as the pipe; for large pipes, spiral it without overlapping. Apply insulation over the cable for best results.

Can the cable be cut to length?

No, the cable is factory-terminated and must not be cut or shortened. It is available in fixed lengths (3 m, 6 m, 9 m, 14 m). Choose the correct length for your installation.

What is the power consumption?

The cable delivers approximately 10 watts per meter. A 3 m cable consumes about 30 W, a 6 m cable 60 W, etc., when the thermostat is active.

Is the cable safe for plastic pipes?

Yes, but you must use the K50AL fixing tape specifically designed for plastic pipes, which has an aluminum film to reflect heat. Additionally, ensure the cable does not overlap itself.

What is the maximum temperature the cable can withstand?

When powered, the cable can withstand ambient temperatures up to 65°C. When not powered, it can withstand the same 65°C. Storage temperature range is -20 to -25°C.

Does the cable require any maintenance?

The heating cable is generally maintenance-free. Periodically check the insulation and fixing tape for damage, and ensure the thermostat is working correctly before each winter season.

What protection rating does it have?

The cable has an IPX7 rating, meaning it is protected against temporary immersion in water. However, the plug and thermostat should be kept dry.

What accessories are available?

Accessories include K50 fiberglass fixing tape for metal pipes (roll 55 m, width 19 mm), K50AL aluminum-coated fixing tape for plastic pipes (roll 50 m, width 50 mm), and KFAN warning labels to indicate the presence of the heating cable (yellow, apply every 5 m on the insulation).

USER MANUAL K10CKIT Fantini Cosmi

■ Kit consisting of a heating cable complete with a contact thermostat and power cable with Schuko plug
■ Constant power delivered \~10 W/m
■ Avoid possible damage caused by low temperatures on pipes, valves, taps, water meters, water troughs, vessels and small tanks

Blue electric shock absorber with attached plug (no text or symbols visible)

CODE Cable length	Minimum installation room temperature	Maximum room temperature powered	Maximum room temperature not powered
K10C3KIT 3 m -5 °C 65 °C 65 °C
K10C6KIT 6 m -5 °C 65 °C 65 °C
K10C9KIT 9 m -5 °C 65 °C 65 °C
K10C14KIT 14 m -5 °C 65 °C 65 °C

HOMOLOGATION AND STANDARDS

■ Compliant with Directive 2014/35/EU;
■ Complying with Standard EN60335-1;

CE

OPERATION

■ The cable is ready for use;
■ The cable is actuated when the contact temperature drops below +5°C and automatically goes off when the temperature exceeds +15°C;
■ IT consists of a resistance wound in a spiral on two conductors and in contact with these at junction points at constant intervals (the energy to heat the resistance is drawn at the splicing points).

INSTALLATION

■ The cable is ready for use: it has a Schuko plug to connect directly to the mains and a thermostat (+5°C to +15°C);
■ Thanks to the electric socket and the thermostat, installation is simple, safe and fast;
- Secure the pipe with the relevant fixing tape: code K50 for steel pipes or code K50AL for plastic pipes;
■ The cable must be as long as the piping;
In the case of large pipes, the spiral cable may need to be wound so as to ensure adequate heat, taking care not to overlap it at any point;
■ It is advisable to apply an insulating coating over the heating cable for a correct installation.

Medical equipment setup including a metallic faucet and blue gas outlet tube (no text or symbols visible)

INSULATION THICKNESS
Pipe size	1/2	3/4	1	1 1/4	1 1/2
Nominal width mm	15	20	25	32	40
Insulation thickness mm	20	20	20	30	40

ELECTRICAL FEATURES

Power supply 230V-50Hz

Constant power delivered \~10W/m

GENERAL FEATURES

Cable composition Thermoplastic material with a mechanical protection and earth braiding and an external protective sheath
Cable diameter 9 mm
Cable length K10C3KIT 3 m	K10C6KIT 6 mK10C9KIT 9 mK10C14KIT 14 m
Maximum room temperature powered 65 °C
Minimum installation room temperature -5 °C
Thermostat temperature scale ON +5°C / OFF +15°C
Minimum storage room temperature -20 ÷ -25°C
Protection rating IPX7

ACCESSORIES

K50

FIBERGLASS FIXING TAPE FOR METAL PIPES

■ It does not shrink and preserves its qualities over time;
■ Suitable for temperatures between -30 and +150°C;
■ Roll length 55 m, width 19 mm.

K50AL

FIXING TAPE FOR PLASTIC PIPES

■ It reflects the heat as it is coated with an aluminium film;
■ Suitable for temperatures between -20 and +130°C;
■ Roll length 50 m, width 50 mm.

KFAN

LABELS FOR THE PRESENCE OF A HEATING CABLE

■ Indicate the presence of the heating cable under the insulating coating;
■ To be applied on the coating at intervals of about 5 m; yellow.
