USER MANUAL KF01114 Q-Connect

Client's name: SHANGHAI NNW NEW MATERIALS

TECHNOLOGY CO., LTD.

Client's address: ROOM 106, NO 33 LE SHAN RD, XUHUI

DISTRICT, SHANGHAI

SGS Ref No.: SHHG1105012664SD

Product Name: HIGHLIGHTER INK - DYE(CLB)

End Uses: TO WRITE

Composition/Ingredient: SEE SECTION 3 COMPOSITION/ INFORMATION

ON INGREDIENTS ON THE NEXT PAGE

Job Receiving Date: May 27, 2011

Preparation Period: May 27–June 3, 2011

Service Requested

Safety Data Sheet for the Product

SUMMARY

The contents and format of this MSDS/SDS are in accordance with REGULATION (EC) No 1272/2008, REGULATION (EC) No 1907/2006, EU Commission Directive 1999/45/EC, 67/548/EEC.

**********************************************************************

Signed for and on behalf of

SGS-CSTC Chemical Laboratory

Lindy Liu

Lindy Liu

Lab Manager

This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms e-document.htm. Attention is drawn to the limitation of liability information and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company's findings at the time of its intervention only but within the limits of Client's instructions, if any. The Company's sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested.

SIGARENTS Standards Technical Services (Shanghai) Co., Ltd. Testing Ceremony, Secretary:

3 ^rd Building, No.889 Yishan Road Xuhui District, Shanghai China 200233 中国·上海·徐汇区宜山路889号3号楼 邮编: 200233

1E&E (86-21) 61402553 1E&E (86-21)64953679 HL: (86-21) 61402594 HL: (86-21)54500353

www.cn.sgs.com e [e-mail]

Safety data sheet

Regulation(EC) No. 1907/2006, 1272/2008

Printing date 08.06.2011 Revision: 08.06.2011

1 Identification of the substance/mixture and of the company/undertaking

Product identifier

• Trade name: Highlighter ink-dye(CLB)

· Article number: Data not available

- Registration number: Data not available

- Relevant identified uses of the substance or mixture and uses advised against

· Application of the substance/ the preparation: to write

· Details of the supplier of the safety data sheet

Manufacturer/Supplier:

Shanghai NNW New Materials Technology Co., Ltd.

Room 106, No 33 LE Shan Rd, XuHui District, Shanghai

Tel: [phone]

Fax:[phone]

· Only Representative / other EU contact point European Union Member State contact not available.

· Further information obtainable from: Shanghai NNW New Materials Technology Co., Ltd.

· Emergency telephone number: 021-64476065-610

· Email: [e-mail]

• Reference number: SHHG1105012664SD; SHAHG1107903505

2 Hazards identification

· Classification of the substance or mixture

· Classification according to Regulation (EC) No 1272/2008

The product is not classified according to the CLP regulation.

· Classification according to Directive 67/548/EEC or Directive 1999/45/EC Not applicable.

- Label elements

· Labelling according to Regulation (EC) No 1272/2008 Not applicable

· Hazard pictograms Not applicable

· Signal word Not applicable

· Hazard-determining components of labelling: Not applicable

· Hazard statements Not applicable

· Precautionary statements Not applicable

· Other hazards Not applicable

· Results of PBT and vPvB assessment

· PBT: Not applicable

- vPvB: Not applicable

3 Composition/information on ingredients

· Chemical characterization: Mixtures

· Description: Mixture: consisting of the following components.

· Dangerous components:

CAS: 56-81-5EINECS: 200-289-5

glycerol 10,0%

· Non-dangerous component:

CAS: 2650-18-2EINECS: 220-168-0	diammonio(ethyl)[4-[[4-[ethyl(3-sulphonatobenzyl)amino] phenyl] (2-sulphonatophenyl)methylene] cyclohexa-2,5-dien-1-ylidensulphonatobenzyl)ammonium	1,0%
CAS: 7732-18-5EINECS: 231-791-2	water 89,0%

(Contd. on page 2)

EU

Safety data sheet

Regulation(EC) No. 1907/2006, 1272/2008

Printing date 08.06.2011 Revision: 08.06.2011

Trade name: Highlighter ink-dye(CLB)

(Contd. of page 1)

·Remark:

diammonio(ethyl)[4-[4-[ethyl(3-sulphonatobenzyl)amino]phenylmethylene]

cyclohexa-2,5-dien-1-ylidene](3-sulphonatobenzyl)ammonium (CAS No. 2650-18-2)

synonym: Acid blue 9

4 First aid measures

• Description of first aid measures

· After inhalation: Supply fresh air; consult doctor in case of complaints.

· After skin contact: Wash with water and soap and rinse thoroughly.

· After eye contact: Rinse opened eye for several minutes under running water.

· After swallowing:

Rinse mouth with water.

If symptoms persist consult doctor.

· Information for doctor:

· Most important symptoms and effects, both acute and delayed No further relevant information available.

- Indication of any immediate medical attention and special treatment needed

No further relevant information available.

5 Firefighting measures

- Extinguishing media

- Suitable extinguishing agents: Use fire extinguishing methods suitable to surrounding conditions.

· Special hazards arising from the substance or mixture No further relevant information available.

· Advice for firefighters

· Protective equipment:

Mouth respiratory protective device.

Wear fully protective suit.

6 Accidental release measures

· Personal precautions, protective equipment and emergency procedures

Ensure adequate ventilation

Avoid breathing vapors, mist or gas.

· Environmental precautions: Do not allow to enter sewers/ surface or ground water.

· Methods and material for containment and cleaning up:

Absorb with liquid-binding material (sand, diatomite, acid binders, universal binders, sawdust).

· Reference to other sections

See Section 7 for information on safe handling.

See Section 8 for information on personal protection equipment.

See Section 13 for disposal information.

7 Handling and storage

· Handling:

· Precautions for safe handling

Ensure good ventilation/exhaustion at the workplace.

Prevent formation of aerosols.

· Information about fire - and explosion protection: Normal measures for preventive fire protection.

· Conditions for safe storage, including any incompatibilities

- Requirements to be met by storerooms and receptacles: Store in a cool location.

· Information about storage in one common storage facility: Store away from foodstuffs.

· Further information about storage conditions:

Keep container tightly closed in a dry and well-ventilated place.

(Contd. on page 3)

Safety data sheet

Regulation(EC) No. 1907/2006, 1272/2008

Printing date 08.06.2011 Revision: 08.06.2011

Trade name: Highlighter ink-dye(CLB)

- Specific end use(s) No further relevant information available.

(Contd. of page 2)

8 Exposure controls/personal protection

· Additional information about design of technical facilities: No further data; see item 7.
- Control parameters

· Ingredients with limit values that require monitoring at the workplace:

56-81-5 glycerol

MAK (Germany)	50E mg/m3vgl.Abschn.Xc
WEL (Great Britain)	10 mg/m3
VME (France)	10 mg/m3

· DNELs: Data not available
· PNECs: Data not available
· Additional information: The lists valid during the making were used as basis.
· Exposure controls
- Based on composition shown in Section 3, the following measures are suggested for occupational safety measure:
· Personal protective equipment:
· General protective and hygienic measures:

The usual precautionary measures are to be adhered to when handling chemicals.

· Respiratory protection: Suitable respiratory protective device recommended.
· Protection of hands:

Protective gloves

The glove material has to be impermeable and resistant to the product/ the substance/ the preparation.

Due to missing tests no recommendation to the glove material can be given for the product/the preparation/the chemical mixture.

Selection of the glove material on consideration of the penetration times, rates of diffusion and the degradation

· Material of gloves:

The selection of the suitable gloves does not only depend on the material, but also on further marks of quality and varies from manufacturer to manufacturer. As the product is a preparation of several substances, the resistance of the glove material can not be calculated in advance and has therefore to be checked prior to the application.

· Penetration time of glove material:
The exact break through time has to be found out by the manufacturer of the protective gloves and has to be observed.
· Eye protection:

Tightly sealed goggles

9 Physical and chemical properties

· Information on basic physical and chemical properties
· General Information
· Appearance:

Form:

Colour:

Liquid

Blue

(Contd. on page 4)

Safety data sheet

Regulation(EC) No. 1907/2006, 1272/2008

Printing date 08.06.2011 Revision: 08.06.2011

Trade name: Highlighter ink-dye(CLB)

· Odour:	Odourless
· Odour threshold:	Data not available.
· pH-value:	Data not available.
· Change in conditionMelting point/Melting range:Boiling point/Boiling range:Freezing point:	Data not available.Data not available
· Flash point:	Data not available
· Flammability (solid, gaseous):auto-Ignition temperature:	Data not availableData not available
· Decomposition temperature:	Date not available.
· Self-igniting:	Product is not selfigniting.
· Danger of explosion:	Product does not present an explosion hazard.
· Explosion limits:Lower:Upper:Oxidizing properties	Data not available.Data not available.Data not available.
· Vapour pressure:	Data not available.
· Density:	Data not available.
· Relative densityVapour density	Data not available.Data not available.
· Evaporation rate	Data not available.
· Solubility in / Miscibility with water:	Data not available
· Partition coefficient (n-octanol/water):	Data not available.
· Viscosity:Dynamic:Kinematic:Other information	Data not available.Data not available.No further relevant information available.

10 Stability and reactivity

• Reactivity No decomposition if used according to specification.
  · Chemical stability Stable under recommended storage conditions.
  · Possibility of hazardous reactions No dangerous reactions known.
• Conditions to avoid No further relevant information available.
  · Incompatible materials: No further relevant information available.
  · Hazardous decomposition products: No dangerous decomposition products known.

11 Toxicological information

· Information on toxicological effects
· Acute toxicity:
· LD/LC50 values relevant for classification:

56-81-5 glycerol

Oral	LD50	4090 mg/kg (mouse)
		12600 mg/kg (rat)

(Contd. on page 5)

EU

Safety data sheet

Regulation(EC) No. 1907/2006, 1272/2008

Printing date 08.06.2011 Revision: 08.06.2011

Trade name: Highlighter ink-dye(CLB)

		27000 mg/kg (rabbit)
7732-18-5 water
Oral	LD50	90000 mg/kg (rat)

· Primary irritant effect:
· on the skin: Irritating effect possible.
· on the eye: Irritating effect possible.
· Sensitization: Sensitization possible.
· Toxicokinetics, metabolism and distribution No further relevant information availabe.
- Acute effects (acute toxicity, irritation and corrosivity) No further relevant information available.
- Repeated dose toxicity No further relevant information available.
· CMR effects (carcinogenicity, mutagenicity and toxicity for reproduction)
No further relevant information availabe.

12 Ecological information

· Toxicity
· Acquatic toxicity: No further relevant information available.
· Persistence and degradability No further relevant information available.
· Behaviour in environmental systems:
· Bioaccumulative potential No further relevant information available.
- Mobility in soil No further relevant information available.
· Additional ecological information:
· General notes:
Water hazard class 1 (German Regulation) (Self-assessment): slightly hazardous for water Do not allow undiluted product or large quantities of it to reach ground water, water course or sewage system.
· Results of PBT and vPvB assessment
· PBT: Not applicable.
· vPvB: Not applicable.
· Other adverse effects No further relevant information available.

13 Disposal considerations

· Waste treatment methods
- Recommendation Smaller quantities can be disposed of with household waste.
· Uncleaned packaging:
· Recommendation: Disposal must be made according to official regulations.

14 Transport information

· Land transport ADR/RID (cross-border)
· ADR/RID class:
· Danger code (Kemler): -
- UN-Number:
· Packaging group:
· Hazard label:
· UN proper shipping name:
- Limited quantities (LQ) -
- Transport category
· Tunnel restriction code -

· Maritime transport IMDG:

· IMDG Class:

· UN Number: -

(Contd. on page 6)

EU

Safety data sheet

Regulation(EC) No. 1907/2006, 1272/2008

Printing date 08.06.2011 Revision: 08.06.2011

Trade name: Highlighter ink-dye(CLB)

(Contd. of page 5)

·Label	-
·Packaging group:	-
·EMS Number:	-
·Marine pollutant:	No
·Proper shipping name:	-
·Air transport ICAO-TI and IATA-DGR:
·ICAO/IATA Class:	-
·UN/ID Number:	-
·Label	-
·Packaging group:	-
·Proper shipping name:	-

· UN "Model Regulation":
· Special precautions for user Not applicable.
- Transport in bulk according to Annex II of MARPOL73/78 and the IBC Code Not applicable.

15 Regulatory information

· Safety, health and environmental regulations/legislation specific for the substance or mixture
· Sara

· Section 355 (extremely hazardous substances):

None of the ingredients is listed.

· Section 313 (Specific toxic chemical listings):

None of the ingredients is listed.

· TSCA (Toxic Substances Control Act):

All ingredients are listed.

- Proposition 65

· Chemicals known to cause cancer:

None of the ingredients is listed.

· Chemicals known to cause reproductive toxicity for females:

None of the ingredients is listed.

· Chemicals known to cause reproductive toxicity for males:

None of the ingredients is listed.

· Chemicals known to cause developmental toxicity:

None of the ingredients is listed.

. Cancerogenity categories

· EPA (Environmental Protection Agency)

None of the ingredients is listed.

· IARC (International Agency for Research on Cancer)

None of the ingredients is listed.

· NTP (National Toxicology Program)

None of the ingredients is listed.

· TLV (Threshold Limit Value established by ACGIH)

None of the ingredients is listed.

· MAK (German Maximum Workplace Concentration)

None of the ingredients is listed.

· NIOSH-Ca (National Institute for Occupational Safety and Health)

None of the ingredients is listed.

(Contd. on page 7)

Safety data sheet

Regulation(EC) No. 1907/2006, 1272/2008

Printing date 08.06.2011 Revision: 08.06.2011

Trade name: Highlighter ink-dye(CLB)

(Contd. of page 6)

· OSHA-Ca (Occupational Safety & Health Administration)

None of the ingredients is listed.

· National regulations:

· Waterhazard class: Water hazard class 1 (Self-assessment): slightly hazardous for water.

· Other regulations, limitations and prohibitive regulations

· Candidate List of Substances of very high concern (SVHC) according to ECHA (15/12/2010)

None of the ingredients is listed.

· REACH Regulation Annex XVII Restriction(22/6/2009)

None of the ingredients is listed.

· REACH Regulation Annex XIV Authorization List(17/2/2011)

None of the ingredients is listed.

· Chemical safety assessment: A Chemical Safety Assessment has not been carried out.

16 Other information

.**************************

The contents and format of this MSDS/SDS are in accordance with REGULATION (EC) No 1272/2008, REGULATION (EC) No 1907/2006 and EU Commission Directive 1999/45/EC, 67/548/EEC.

DISCLAIMER OF LIABILITY

The information in this MSDS/SDS was obtained from sources which we believe are reliable. However, the information is provided without any warranty, express or implied, regarding its correctness. The conditions or methods of handling, storage, use or disposal of the product are beyond our control and may be beyond our knowledge. For this and other reasons, we do not assume responsibility and expressly disclaim liability for loss, damage or expense arising out of or in any way connected with the handling, storage, use or disposal of the product. This MSDS/SDS was prepared and is to be used only for this product. If the product is used as a component in another product, this MSDS/SDS information may not be applicable.

Abbreviations and acronyms:

ADR: Accord européen sur le transport des marchandises dangereuses par Route (European Agreement concerning the International Carriage of Dangerous Goods by Road) RID: Règlement international concernant le transport des marchandises dangereuses par chemin de fer (Regulations Concerning the International Transport of Dangerous Goods by Rail) IMDG: International Maritime Code for Dangerous Goods IATA: International Air Transport Association IATA-DGR: Dangerous Goods Regulations by the "International Air Transport Association" (IATA) ICAO: International Civil Aviation Organization ICAO-TI: Technical Instructions by the "International Civil Aviation Organization" (ICAO) GHS: Globally Harmonized System of Classification and Labelling of Chemicals ACGIH: American Conference of Governmental Industrial Hygienists DNEL: Derived No-Effect Level (REACH) PNEC: Predicted No-Effect Concentration (REACH) LC50: Lethal concentration, 50 percent LD50: Lethal dose, 50 percent

.**************************

End of document
