Product Type	Wine Cabinet (Built-in)
Brand	Gaggenau
Model	RW222260
Capacity	48 bottles (standard 0.75L)
Energy Class	A (annual consumption 151 kWh)
Annual Energy Consumption	151 kWh/year
Noise Level	35 dB
Temperature Range	5°C to 20°C
Climate Class	SN-ST (10°C to 38°C)
Dimensions (H x W x D)	860 x 595 x 575 mm
Weight	Approx. 50 kg
Power Supply	220-240 V, 50/60 Hz
Refrigerant	R600a
Display Type	LED digital display
Lighting	Interior LED, dimmable
Door	Tempered UV-protected glass, reversible hinge
Shelves	5 wooden shelves, pull-out
Temperature Zones	Dual zone (upper and lower)
Humidity Control	Passive humidity system
Vibration Dampening	Compressor on vibration dampeners
Security Lock	Yes, key lock
Maintenance	Clean with soft cloth and mild detergent; do not use abrasive cleaners
Spare Parts Availability	Original parts via Gaggenau service

Frequently Asked Questions - RW222260 GAGGENAU

How do I set the temperature on my Gaggenau RW222260 wine cabinet?

To set the temperature, press the SET button on the control panel. Use the + and - buttons to adjust the desired temperature. The upper zone can be set between 5°C and 12°C, the lower zone between 10°C and 20°C.

How many bottles can the RW222260 store?

The RW222260 has a capacity of 48 standard Bordeaux bottles (0.75L) when using the pull-out wooden shelves. Smaller or larger bottles may reduce capacity.

Is the RW222260 a built-in or freestanding model?

The RW222260 is designed for built-in installation under a counter. It fits into a standard 860 mm high niche with proper ventilation. Freestanding use is also possible with adequate clearance.

How should I clean the wine cabinet?

Clean the interior and exterior with a soft, damp cloth and mild detergent. Avoid abrasive cleaners or scouring pads. The glass door can be cleaned with a glass cleaner. Always unplug the unit before cleaning.

What is the noise level of the RW222260?

The RW222260 operates at a noise level of only 35 dB, which is very quiet, similar to a whisper. This makes it suitable for living areas or bedrooms.

Does the RW222260 have UV protection?

Yes, the door is made of tempered glass with UV protection. This helps prevent wine from spoiling due to harmful ultraviolet light.

Can I reverse the door hinge on the RW222260?

Yes, the door hinge is reversible. You can change the opening direction from left to right or vice versa. Refer to the manual for step-by-step instructions on hinge reversal.

What is the energy consumption of the RW222260?

The annual energy consumption is 151 kWh per year, which corresponds to energy class A on the EU energy label. Actual consumption depends on usage and ambient temperature.

Does the RW222260 have a lock?

Yes, the RW222260 is equipped with a key lock to secure your wine collection. The key is included with the appliance.

How do I defrost the RW222260?

The RW222260 features automatic defrosting (frost-free). No manual defrosting is required. If frost builds up, it is usually due to frequent door openings; check the door seal.

USER MANUAL RW222260 GAGGENAU

Blue background with a circle of twelve yellow stars, representing the European Union flag (no text or symbols beyond the stars)

ENERG

енергия · ενεργεια

RW222260

GAGGENAU

ENERGIA · ЕНЕРГИЯ · ЕНЕРГЕІА ENERGIJA · ENERGY · ENERGIE ENERGI

151,00

kWh/annum

x48

35 dB
