USER MANUAL VariCook Duo Klarstein

Dear Customer, Congratulations on purchasing this equipment. Please read this manual carefully and take care of the following hints to avoid damages. Any failure caused by ignoring the items and cautions mentioned in the instruction manual is not covered by our warranty and any liability. Scan the QR code to get access to the latest user manual and other information about the product. CONTENT Product description11 operation11 Care and Cleaning12 Product Data Sheet13 Disposal Considerations14 Manufacturer & Importer (UK)14 TECHNICAL DATA Item number 10032124, 10032125 Power supply 220-240 V ~ 50-60 Hz Power 3000 W Plate diameter 200 mm + 165 mm10

SAFETY INSTRUCTIONS CATION Risk of burns! The surface of the appliance becomes very hot during use and remains hot for a long time even after cooking. Do not touch it. Use only the controls.

• The installation and connection of the new appliance must only be carried out by quali ed personal.

• Repairs to the appliance are only to be carried out by approved service persons. Repairs carried out by inexperienced persons may cause injury or serious malfunctioning. If your appliance needs repairing, please contact your local Service Centre.

• If your appliance malfunctions or fractures: switch off all cooking zones, and contact Service Center. If the surface is cracked, switch off the appliance to avoid the possibility of electric shock. Do not re-use your hob until the glass surface has been changed. If the supply cord is damaged, it must be replaced by its service agent or similarly quali ed persons in order to avoid a hazard.

• This appliance is not intended for use by young children or in rm persons unless they have been adequately supervised by a responsible person to ensure that they can use the appliance safely. Young children should be supervised to ensure that they do not play with the appliance. Accessible parts may become hot during use. Young children should be kept away. Safety During Use

• This appliance may only be used for normal cooking and frying in the kitchen.

• Do not use the hob to heat the room.

• Take care when plugging in electric appliances near the hob. Connection leads must not come into contact with the hot surface.

• Overheated fats and oils catch re quickly. You should supervise cooking when preparing foods in fat or oil.

• Switch off the cooking zones after use.

• Always keep the control panels clean and dry.

• Never place combustible items on the hob.

• You must not keep any combustible items aerosol cans in a drawer located under the hob. Safety When Cleaning

• Always switch off the appliance before cleaning.

• For safety reasons do not clean the appliance with a steam jet or high pressure cleaner.

• Clean the hob in accordance with the maintenance and cleaning instructions in this manual.

• Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can scratch the surface, which may result in shattering of the glass.11

PRODUCT DESCRIPTION 1 Large Infrared cooker 2 Small Infrared cooker 3 Small Power Knob 4 Small Power Indicator 5 Large Power Indicator 6 Large Power Knob OPERATION 1 lace the unit on a stable,heat-resistant.away from other heat source. 2 Extend the entire supply cable.make sure it is not in contact with any heat source. Insert the plug into mains outlet. 3 Put a pot onto a burner and set the required temperature suing the control the teat (0-MAX).The higher the number,the higher the burner temperature. The heating indicator will be illuminated (see picture).Once it turns off,the plate has reached the preset temperature. 4 As soon as the food starts to boil,turn down the control knob so that ti will keep the food simmering. Note: No preheating is neecessary to cook as the burners are fast-heating. Never leave the burners on without a pot on then (Except for the very rst operation). 5 Make sure to set the temperature control knob to “0” when cooking is completed. 6 Disconnect the cooktop from the power supply. Note: To maxumim operating time can not over one hour. Only use at and stable pots and pans on this appliance. Always unplug the cord form the wall socket before cleaning. Never immerse the appliance, cord or plug in water or other liquids.12

• Always unplug the hotplate and allow it to cool before cleaning.

• The surface may be cleaned using a nylon pad and a mild liquid soap solution.

• Never use harsh abrasives, caustic cleansers on the continuous-clean surface.

• The hotplate rack, door ,and the top and bottom of the hotplate must be cleaned by hand. How to avoid damage to the appliance

• Do not use the cooking area as a worktop or storage space.

• Please be careful the edges when moving pots and pans around.

• Do not have the cooking zones on with empty pans, or with no pots or pans on them.

• Ceramic glass is very tough, and impervious to sharp temperature changes, but is not unbreakable. It can be damaged if particularly hard or sharp objects fall on to it.

• Be very cautious if using pots made of cast iron, or other pots with rough edges or burrs. Moving these can cause scratches on glass.

• If sugar or a misture containing sugar falls onto a hot cooking zone and melts, remove immediately, while still hot. If left to cool down, it may damage the surface when removed.

• Keep objects or materials liable to melt away from the ceramic glass surface, for example, plastic utensils, aluminum foil, or cooking wraps. If any other materials or foodstuffs have melted on the ceramic glass surface, these should also be cleaned away immediately.13

Symbol Value Unit Model identication 10032124, 10032125 Type of hob Freestanding Number of cooking zones and/or areas

Heating technology (induction cooking zones and cooking areas, radiant cooking zones, solid plates) Infrared hob For circular cooking zones or area: diameter of useful surface area per electric heated cooking zone, rounded to the nearest 5 mm Ø 21.0 / 24.0 cm For non-circular cooking zones or areas: length and width of useful surface area per electric heated cooking zone or area, rounded to the nearest 5 mm

Energy consumption per cooking zone or area calculated per kg

Electric Cooking Hob 185 / 184 Wh/kg Energy consumption for the hob calculated per kg

Electric Cooking Hob

DISPOSAL CONSIDERATIONS If there is a legal regulation for the disposal of electrical and electronic devices in your country, this symbol on the product or on the packaging indicates that this product must not be disposed of with household waste. Instead, it must be taken to a collection point for the recycling of electrical and electronic equipment. By disposing of it in accordance with the rules, you are protecting the environment and the health of your fellow human beings from negative consequences. For information about the recycling and disposal of this product, please contact your local authority or your household waste disposal service. MANUFACTURER & IMPORTER (UK) Manufacturer: Chal-Tec GmbH, Wallstrasse 16, 10179 Berlin, Germany. Importer for Great Britain: Chal-Tec UK limited Unit 6 Riverside Business Centre Brighton Road Shoreham-by-Sea BN43 6RE United Kingdom15
