USER MANUAL 24MT35S LG

1. Model Description

Part number 2nd, 3rd Suffix

Network Guide (Revision number)

MFL67883501 (1402-REV03)

2. Printing Specification

1. Trim size (Format)

182 mm x 257 mm (B5)

Uncoated, wood-free paper 80 g/㎡

Uncoated, wood-free paper 80 g/㎡

4. Bindery

5. Language

6. Number of pages

2. Printing colors

3. Stock (Paper)

“This part contains Eco-hazardous substances (Pb, Cd, Hg, Cr6+, PBB, PBDE, etc.) within LG standard level,

Details should be followed Eco-SCM management standard[LG(56)-A-2524]. Especially, Part should be followed and controlled the following specification. (1) Eco-hazardous substances test report should be submitted when Part certification test and First Mass Production. (2) Especially, Don’t use or contain lead(Pb) and cadmium(Cd) in ink. Printed in Kazakhstan LGEKR : Printed in Korea LGERS : Printed in Mexico LGEAZ

Printed in Brazil LGEMA : Printed in Poland LGESY : Printed in China LGEEG : Printed in Egypt LGEMX : Printed in Mexico LGETH : Printed in Thailand LGEIL

Printed in India LGEND : Printed in China LGEVN : Printed in Vietnam LGEIN

Printed in Indonesia LGERA : Printed in Russia LGEWR : Printed in Poland Printed in Algeria LGEAS :

4. Changes

Rev. Number Added 'Soft AP' word in OSD, because of Software update. Aug/13/2013 MK PARK EKMD800180 Delete the Magic Remote contents page. Feb/25/2013 HJ LEE EKMD200434 Added the sentence for common use MMM/DD/YYYY Signature ECO Number Change Contents Pagination sheet Part number

MFL67883501 Total pages

60 pages Front Back (ENG) P/No.

Blank Front Back (GER)

Blank Front Back (FRE)

Blank Front Back (ITA)

Blank Front Back (SPA)

Blank Front Back (RUS)

Blank SMART TV Quick Setup Guide Please read this manual carefully before operating your set and retain it for future reference. P/NO: MFL67883501 (1402-REV03) Printed in Korea

• Image shown may differ from your TV.
• Image shown on a PC or mobile phone may vary depending on the OS(Operating System). ENGLISH ENG Wireless Network Connection wireless router Wired Network Connection Internet connection Wired router

The device automatically tries to connect to the network available(wired network first). ENGLISH ENG Premium Apps are pre-installed on the TV. These may vary by country. Network Connection More Connecting to the network. Cancel More Settings

If you select Cancel or it fails to connect to the network, the network list available is displayed. Choose the network you want. Network Connection Settings

Choose the network you want. Network Connection Network Status If you want to connect your TV to a wireless router, select the network you want and enter the password. Soft AP Wi-Fi Direct Network Connection MiracastTM / Intel's WiDi My TV Name

Wireless : AAA Enter security key of network. Forgot your password? Contact your AP manufacturer.

Select the Start Connection. Network Connection Connect to your wired or wireless network. Enjoy various Smart TV features through network. To connect to a wireless network: To connect to a wired network: Requires a wireless router or access point. Connect a LAN cable to the back of TV.

The connected network is displayed. Select Complete to confirm the network connection. If you select the Other Network List, the network list available is displayed. Network Connection Start Connection Network is connected. Wireless:AAA Select [Other Network List] to connect to another network. Complete Other Network List

Troubleshooting Network Problems ENGLISH ENG

Check the router or consult your Internet service provider. Network Status More

Gateway DNS Internet When an ✔ appears TV and Gateway. 1 Unplug the power cord of the AP, cable modem and try to connect after 5 seconds. 2 Initialize(Reset) the AP or cable modem. 3 Contact internet companies or AP companies. More Settings

NETWORK Network Connection Network Status Soft AP Wi-Fi Direct MiracastTM / Intel's WiDi

Follow the instructions below that correlate to your network status. Check the TV or the router. Network Status

DNS Internet When an ✔ appears TV, Gateway and DNS. When an ✔ appears TV. DNS Internet 1 Check the connection status of TV, AP and cable modem. 2 Power off and power on TV, AP and cable modem. 3 If you are using a static IP, enter IP directly. 4 Contact internet companies or AP companies. Additional points to check when using a wireless connection 1 Check the password for the wireless connection in the router settings window. 2 Change the router SSID (network name) or the wireless channel. 1 Unplug the power cord of the AP, cable modem and try to connect after 5 seconds. 2 Initialize(Reset) the AP or cable modem. 3 Check that the MAC address of the TV/router is registered with your Internet service provider. (The MAC address displayed on the right pane of the network status window should be registered with your Internet service provider.) 4 Check the router manufacturer’s website to make sure your router has the latest firmware version installed.

SmartShare PC SW Installing & Setting programme on your PC.

Go to www.lg.com Then, select your region.

Select SUPPORT. Then, Search for your model.

Select Drivers & Software or SOFTWARE UPDATE. Then, select

You can run the programme when installation is complete. ENGLISH ENG Install the

NOTE yy DLNA service is only available if TV and other devices are connected via a single router. DLNA Connection to Smartphone

Check that Wi-Fi is enabled on your smartphone.

Install/run the app for sharing content on your smartphone (It's called SmartShare on LG phones).

Enable your smartphone to share content files with other devices.

Select the file type you want to play (movie, audio or photo).

Select a movie, music or photo file to play on the TV.

Add the selected file to the playlist.

Select a TV model name on which to play the files. (The TV model name is labelled on the rear side of the panel.)

Play the media file to view and enjoy it on your TV.

Updating the TV Firmware ENGLISH ENG SMART Settings

• SUPPORT → Software Update REC Uses Software Update to check and obtain the latest version. If not updated, certain functions may not work properly. It is also possible to check manually for available updates. Software Update Set it to On. If an update is available, a prompt will appear to perform the update. Automatic update mode If an update is available, the update automatically starts without prompting. Check Update Version Checks the latest update version installed. When a new update is available, the download process can be performed manually. NOTE yy When the update starts, a pop-up window is displayed to show the update status and then disappears within five seconds. yy The latest version can be obtained via the digital broadcast signal or an internet connection. yy Changing the programme while downloading the software via a digital broadcast signal interrupts the download process. Returning to the initial programme allows downloading to resume. yy If software is not updated, certain functions may not work properly. yy [For Finland/Sweden/Denmark/Norway models.] If the software update is performed via the broadcasting signal, you will be prompted to continue the update regardless of whether the Automatic update mode is enabled or not. Wi-Fi Direct Setting SMART Settings
• NETWORK → Wi-Fi Direct REC The Wi-Fi Direct function supports wireless connection technology. With SmartShareTM, you can share files or screens of devices connected to Wi-Fi Direct. Wi-Fi Direct

Wi-Fi Direct If Wi-Fi Direct is set to On, a list of available devices appears. To use Wi-Fi Direct, go to Settings → NETWORK and set Wi-Fi Direct( a ) to On.

When you are prompted to request connection, select Yes. Wi-Fi Direct is now connected to your TV. [TAAAA] Do you want to request a connection?

Automatically connect without asking Yes

• If you are not using Wi-Fi Direct to minimize the interference between Wi-Fi devices, it is recommended to set Wi-Fi Direct( a ) to Off. You can only use devices that support Wi-Fi Direct.

MiracastTM Setting MiracastTM / Intel's WiDi

MiracastTM is set to On on your TV or portable device. Go to the Network settings to set the MiracastTM.

When your portable device is detected, select the device.

For more information about how to connect the portable device, refer to the portable device manual. The device which is applied MiracastTM and intel's WiDi technology can be shown on the TV. MiracastTM / Intel's WiDi Device Name

Connection Connection TAAAA WiDi (Wireless Display) Setting WiDi represents Wireless Display. Intel’s WiDi (Wireless Display) technology enables easy and fast connection without wires or internet network for mirrored and dual monitor display on your TV. You can sit back and experience your favorite movies, videos, photos, online shows and more in full HD on your TV with great image clarity and sound. 1 Intel's WiDi is set to On. Connect your laptop to AP. (Without AP, it is possible to this function; it is recommended to connect to AP.) Your laptap runs the Intel WiDi( ) programme.

It detects LG Smart TVs available, which supports WiDi. In the list, select the TV you want and click Connect. Enter the PIN number( a ) shown on the screen into the input field( b ) on your laptop and then click Continue. NOTE yy When you connect the TV and laptop, you should set up TV mode for “Live TV” and “external input”. If not, your computer cannot detect LG Smart TV. [Intel's WiDi] Request connection Enter the following Security keys.

Remain: 92 second(s)

• When WiDi is connected, devices connected with Wi-Fi Direct are disconnected. Cancel TV Screen Notebook Screen The wireless environment may affect the screen display. If the connection is poor, the Intel WiDi connection may be lost.
• LG TV is not need to register.
• For more information on Intel WiDi, visit http://intel.com/go/widi.
• A list of Intel's WiDi devices does not appear on the TV screen. Please check the list on your laptop.

ENGLISH ENG MiracastTM allows a portable device to securely send video and sound to TV wirelessly.

Universal Control ENGLISH ENG To use the Universal Control function (for Magic Remote Control only) With the Magic Remote Control, you can easily control your set-top box, Blu-ray player, home theater system, and Sound Bar.

Check if the device is connected to the TV.

After pressing the ' ' button on the Magic Remote Control, select the device you want to control in the Change Device tab. The Screen Remote that can control the device appears. You can control external devices using the Screen Remote on the screen. (This may not work with the ' ' button for some models.) Time Machine II

: Change Device tab : Device control buttons : Expand the ScreenRemote : Exits the Screen Remote : Moves the position of the ScreenRemote to left or right

Control external devices using the navigation keys, wheel (OK), or BACK button on the Magic Remote Control. External Device Menu Please call LG Customer Service if you experience any problems. SMART TV Miracast™ / Intel's WiDi Mein TV-Name

MiracastTM / Intel's WiDi Wi-Fi Direct Miracast™ / Intel's WiDi MiracastTM / Intel's WiDi Activé Software Access Point Wi-Fi Direct MiracastTM / Intel's WiDi Nome TV

Stato rete Software Access Point Wi-Fi Direct MiracastTM / Intel's WiDi

MiracastTM / Intel's WiDi Nome dispositivo Acceso MiracastTM / Intel's WiDi MiracastTM / Intel's WiDi Название устройства

Connection Подключение
