| Product Type | 6.5-inch loudspeaker driver |
| Brand | Eminence |
| Model | ALPHA6A |
| Driver Size | 6.5" (165 mm) |
| Impedance | 8 ohms |
| Power Handling (RMS) | 125 W |
| Peak Power Handling | 250 W |
| Sensitivity | 96 dB @ 1 W / 1 m |
| Frequency Range | 72 Hz - 7 kHz |
| Magnet Type | Ferrite |
| Cone Material | Paper |
| Voice Coil Diameter | 1.5" (38 mm) |
| Overall Diameter | 6.6" (168 mm) |
| Cutout Diameter | 5.7" (145 mm) |
| Mounting Depth | 3.2" (81 mm) |
| Net Weight | 2.8 lb (1.27 kg) |
| Terminal Type | Push terminals |
| Recommended Application | PA, musical instrument amplifiers or replacement speaker |
| Cleaning Instructions | Use a soft dry cloth; avoid liquids and strong airflow |
| Safety Notes | Disconnect amplifier before wiring; keep away from moisture |
| Serviceability | Recone kits and replacement parts available from Eminence partners |
Frequently Asked Questions - ALPHA6A Eminence
What is the power handling of the Eminence ALPHA6A?
The ALPHA6A handles up to 125 watts RMS and 250 watts peak, making it suitable for guitar amplifiers and small PA cabinets.
What is the impedance of the ALPHA6A?
It has an 8-ohm impedance, so it works with most tube and solid-state amplifiers. Always check your amplifier's minimum load rating.
What frequency range does the ALPHA6A cover?
The speaker reproduces 72 Hz to 7 kHz efficiently, which makes it ideal for mid-bass and vocal projection in tuned or open-back enclosures.
How do I clean and maintain the speaker?
Use a soft dry cloth to remove dust from the cone and frame. Do not use water, solvents or compressed air, and keep the speaker away from magnets and moisture.
Can the ALPHA6A be used in a sealed enclosure?
Yes, the ALPHA6A works in sealed and ported boxes. A sealed cabinet gives tight bass, while a ported cabinet extends the low-frequency response.
How do I wire two 8-ohm ALPHA6A speakers?
For two 8-ohm speakers, wire them in parallel for a 4-ohm load or in series for a 16-ohm load, depending on your amplifier.
What amplifier power is recommended for this driver?
Use an amplifier delivering between 60 W and 200 W RMS per speaker. Avoid sustained clipping, as this can damage the voice coil.
Does the ALPHA6A require break-in?
Yes, expect about 10 to 20 hours of moderate playback to loosen the surround and achieve full low-frequency performance.
What mounting hardware is included with the ALPHA6A?
The speaker is supplied with mounting screws and a protective gasket. Use the cutout dimensions shown on the product page for a proper fit.
Is the ALPHA6A repairable?
Yes, the driver is serviceable. Recone kits, replacement dust caps and gaskets are available from Eminence dealers, and the frame can be reused.
