IPC-D180H - Surveillance Camera HiLook - Free user manual and instructions

Product Type	Surveillance Camera
Brand	HiLook
Model	IPC-D180H
Image Sensor	1/2.7" Progressive Scan CMOS
Resolution	2 MP (1920 × 1080)
Lens	2.8 mm fixed
Night Vision Distance	Up to 30 m (IR)
Power Supply	12 V DC ± 25%, PoE (802.3af)
Power Consumption	Max. 5 W
Protection Level	IP67 (weatherproof)
Dimensions (W × H × D)	186.6 × 93.3 × 93.3 mm
Weight	Approx. 620 g
Operating Temperature	-30 °C to +60 °C
Storage Temperature	-30 °C to +60 °C
Video Compression	H.265+, H.265, H.264+, H.264
Network Interface	1 RJ45 10M/100M self-adaptive Ethernet port
Local Storage	Supports microSD up to 256 GB (optional)
Security	Password protection, IP address filter
Supported Protocols	TCP/IP, UDP, HTTP, DHCP, DNS, NTP, etc.
Ingress Protection	IP67

Frequently Asked Questions - IPC-D180H HiLook

How do I reset the HiLook IPC-D180H camera to factory defaults?

Press and hold the reset button (located on the cable or near the lens) for about 10 seconds until the indicator light flashes. The camera will reboot with factory settings.

What app do I use to view the camera on my phone?

Use the Hik-Connect or iVMS-4500 app. Download from App Store or Google Play, then add the camera by scanning its QR code or entering the serial number.

Can I use this camera outdoors?

Yes, the camera has an IP67 rating, making it dust-tight and protected against heavy rain. It can operate in temperatures from -30°C to +60°C.

What power options are available?

The camera supports 12V DC power input and PoE (Power over Ethernet) via a PoE switch or injector (802.3af). PoE simplifies installation.

How far can the camera see at night?

The built-in IR LEDs provide night vision up to 30 meters in complete darkness, depending on the scene conditions.

Does the camera support audio?

This model does not include a built-in microphone or speaker; it is a video-only camera. For audio, consider a model with audio input/output.

How do I connect the camera to Wi-Fi?

The IPC-D180H is a wired Ethernet camera; it does not support Wi-Fi. Connect it directly to a router or switch using an Ethernet cable.

What is the maximum resolution and frame rate?

It records at 2 MP (1920x1080) resolution with a maximum frame rate of 30 fps for smooth video.

Can I store video on an SD card?

Yes, insert a microSD card (up to 256 GB) into the slot (if available) for local storage. Enable recording via the app or web interface.

How do I mount the camera?

Use the included mounting bracket and screws. Attach the bracket to a wall or ceiling, route the cable, and secure the camera. Adjust the angle as needed.

USER MANUAL IPC-D180H HiLook
