Captur (2017) - Car RENAULT - Free user manual and instructions
Find the device manual for free Captur (2017) RENAULT in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Compact SUV |
| Brand | Renault |
| Model | Captur (2017) |
| Category | Car |
| Length | Approximately 4.12 m (162.2 in) |
| Width | Approximately 1.78 m (70.1 in) without mirrors |
| Height | Approximately 1.57 m (61.8 in) |
| Wheelbase | Approximately 2.60 m (102.4 in) |
| Curb Weight | Ranges from 1,100 to 1,300 kg depending on engine |
| Fuel Type | Petrol (gasoline) or Diesel |
| Engine Options | 1.0 TCe, 1.2 TCe, 1.5 dCi, among others |
| Transmission | 5-speed manual, 6-speed manual, or 6-speed EDC automatic |
| Seating Capacity | 5 passengers |
| Trunk Capacity | Approximately 455 liters (16.1 cu ft) with rear seats up |
| Safety Features | ABS, ESP, front and side airbags, ISOFIX child seat anchors |
| Maintenance | Oil change every 20,000 km or annually; tire pressure check monthly |
| Cleaning | Wash with mild car shampoo; avoid abrasive materials on paint |
| Fuel Consumption (combined) | Varies from 4.0 L/100 km (diesel) to 5.5 L/100 km (petrol) |
| CO2 Emissions | From 105 g/km (diesel) to 130 g/km (petrol) approximately |
| Warranty | Standard manufacturer warranty; refer to manual for details |
Frequently Asked Questions - Captur (2017) RENAULT
How do I check the engine oil level?
Park on level ground, wait for engine to cool, pull out the dipstick, wipe it, reinsert, then check the oil level between the min and max marks. Add oil if needed and use the recommended grade (e.g., 5W-30).
What is the recommended tire pressure?
Recommended tire pressure is usually 2.2 bar (32 psi) for front and rear, but check the sticker on the driver's door frame for exact values. Adjust pressure when tires are cold.
How do I reset the service light?
Turn ignition on, press and hold the trip reset button until the service indicator flashes, then release. Consult the manual for exact steps as it may vary by model.
What type of fuel should I use?
For petrol engines, use unleaded gasoline with an octane rating of 95 RON minimum. For diesel engines, use diesel fuel complying with EN590 standard.
How do I pair my phone via Bluetooth?
Enable Bluetooth on your phone, go to car's audio system settings, select 'Add device', search for the car, and confirm the pairing code on both devices.
What is the towing capacity?
Braked towing capacity is up to 1,200 kg for some engines; unbraked is up to 650 kg. Always consult your manual for the exact value based on your engine.
How do I replace a bulb in the headlight?
Open the hood, locate the headlight cap, turn it counterclockwise, disconnect the wiring, and replace the bulb with the same type (e.g., H7). Do not touch the glass with bare hands.
What is the correct way to jump start the car?
Use jumper cables: attach red to dead battery positive and red to donor positive, black to donor negative, then black to an unpainted metal part on the dead car (not battery negative). Start donor, then dead car.
How often should I replace the timing belt?
Timing belt replacement interval is typically every 100,000 km or 6 years, whichever comes first. Check your manual for exact interval.
What is the child seat anchor type?
The car is equipped with ISOFIX anchors in the rear outer seats, as well as top tether anchors. Always follow the child seat manufacturer's instructions.
User questions about Captur (2017) RENAULT
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
No questions yet. Be the first to ask one.
Download the instructions for your Car in PDF format for free! Find your manual Captur (2017) - RENAULT and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. Captur (2017) by RENAULT.
USER MANUAL Captur (2017) RENAULT
Manual assistant
Powered by Anthropic
Waiting for your message
Product information
Brand : RENAULT
Model : Captur (2017)
Category : Car
