GVS128 - Splitter Gembird - Free user manual and instructions

Product Type	VGA Splitter
Model	GVS128
Input Connection	1 x VGA (HD-15) Male
Output Connections	2 x VGA (HD-15) Female
Supported Resolutions	Up to 1920x1080 @ 60Hz
Bandwidth	250 MHz
Power Supply	Passive (no external power required)
Material	Plastic housing with metal connectors
Dimensions (approx.)	90 x 55 x 22 mm
Weight (approx.)	70 g
Cable Length (input)	15 cm integrated cable
Compatibility	VGA sources and displays (PC, projector, monitor)
Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 60°C
Humidity	0% to 80% (non-condensing)
Maintenance	Clean with a soft, dry cloth
Safety Precautions	Avoid liquid contact, do not disassemble, keep away from heat
Spare Parts	Not applicable (non-serviceable)
Warranty	2 years (depending on region)

Frequently Asked Questions - GVS128 Gembird

How do I connect the Gembird GVS128 splitter?

Connect the integrated VGA cable to your source (e.g., computer). Then connect up to two VGA monitors or projectors to the output ports. No external power is needed.

What is the maximum resolution supported?

The GVS128 supports resolutions up to 1920x1080 @ 60Hz. Higher resolutions may cause signal degradation.

Does the splitter require an external power source?

No, the GVS128 is a passive splitter and draws power from the VGA source. No external power adapter is needed.

Can I use the splitter with HDMI devices?

No, this splitter is specifically for VGA (analog) signals. For HDMI, you would need a different model.

Why are the displays showing a weak or distorted signal?

Check that all cable connections are secure. The total cable length from source to displays should not exceed 5 meters for optimal quality. Also, ensure the source output resolution is supported.

Can I connect two different display types?

Yes, both outputs can be connected to different displays (e.g., a monitor and a projector) as long as they accept VGA input.

How do I clean the splitter?

Use a soft, dry cloth to wipe the housing. Do not use liquids or abrasive cleaners. Keep the connectors free of dust.

Does the splitter support audio transmission?

Standard VGA cables do not carry audio. The GVS128 only transmits video signals. Use separate audio cables if needed.

What should I do if one output stops working?

First, swap the cables to isolate the issue. If the problem follows the cable, replace that cable. If it remains on the same port, the splitter may be defective. Contact Gembird support.

Is the splitter compatible with Mac or Linux?

Yes, the GVS128 works with any device that has a VGA output, regardless of operating system. No drivers are required.

USER MANUAL GVS128 Gembird

USER MANUAL

HANDBUCH

HANDLEIDING

MANUEL DESCRIPTIF

Features

• Video Splitter is a VGA/SVGA splitting device which sends video signal of one PC to 2 monitors (GVS122), 4 monitors (GVS124), 8 monitors (GVS128)
• Its built-in 200 MHz bandwidth amplifier not only increases the transmission distance to about 75 meters but also improves quality of the video signal

Specifications

• Power adapter: 9 VDC 500 mA
• Input Connectors: 1 HD DB15 Female
• Output Connectors: 2 HD DB15 Female
• Resolution: up to 2048x1536
• Maximum transmission distance: up to 250 feet (75 meters)
- Amplified signals:
- Analogue: Red, Green, Blue video signals
- TTL: Vertical and Horizontal synchronization signals
- Case: Metal

All brands and logos are registered trademarks of their respective owners

All brands and logos are registered trademarks of their respective owners

This product is tested and complies with the essential requirements of the laws of member states concerning LVD(2006/95/EC), EMC(2004/108/EC). The CE declaration can be found under www.gembird.eu

Simple line drawing of a hand washing a cup with water droplets falling (no text or symbols)

Simple line drawing of a hand using a tool to cut a screwdriver into a screwdriver (no text or symbols)

Simple line drawing of a box with a hand holding a flag and a diagonal line crossing it (no text or symbols)

Waste disposal:

Do not deposit this equipment with the household waste. Improper disposal can harm both the environment and human health. For Information about waste collection facilities for used electrical and electronic devices, please contact your city council or an authorized company for the disposal of electrical and electronic equipment.

All brands and logos are registered trademarks of their respective owners
