MID72C - Tablet MPMAN - Free user manual and instructions

Product Type	Tablet
Brand	Mpman
Model	MID72C
Display Size	7 inches
Display Resolution	1024 x 600 pixels
Processor	Quad-core 1.2 GHz
RAM	1 GB
Internal Storage	8 GB
Operating System	Android 4.2 (Jelly Bean)
Battery Capacity	3000 mAh
Dimensions (W x H x D)	190 x 110 x 10 mm
Weight	320 g
Connectivity	Wi-Fi 802.11 b/g/n, Bluetooth 4.0
Ports	Micro USB, 3.5 mm headphone jack, microSD slot (up to 32 GB)
Camera	Rear 2 MP, Front 0.3 MP
Speakers	Built-in mono speaker
Power Supply	5V/1A via Micro USB
Battery Life	Up to 4 hours of video playback
Maintenance	Clean with a soft, dry cloth. Do not use liquids or abrasive cleaners.
Safety	Do not expose to water or extreme temperatures. Keep away from children under 3 years.
Spare Parts & Repairability	Battery and screen replacement available through authorized service centers. Not user-serviceable.

Frequently Asked Questions - MID72C MPMAN

How do I turn on the Mpman MID72C tablet?

Press and hold the Power button located on the top edge for 3-5 seconds until the screen lights up.

How do I perform a factory reset on the MID72C?

Go to Settings > Backup & Reset > Factory Data Reset. Confirm to erase all data. Alternatively, boot into recovery mode by holding Volume Up + Power during startup.

How do I connect the tablet to Wi-Fi?

Open Settings > Wi-Fi, enable it, select your network, enter the password, and tap Connect.

What is the maximum microSD card size supported?

The tablet supports microSD cards up to 32 GB.

How do I take a screenshot?

Press and hold the Power button and Volume Down button simultaneously for 2 seconds. The screenshot will be saved in the Gallery.

Why is my tablet not charging?

Ensure the charger is plugged into a working outlet. Try a different micro-USB cable. If still not charging, the battery or charging port may be faulty.

Can I update the Android version on the MID72C?

Software updates are no longer provided by Mpman. The tablet runs Android 4.2, and unofficial custom ROMs are not recommended.

How do I clean the touchscreen?

Use a soft, lint-free cloth slightly dampened with water. Do not spray liquid directly on the screen and avoid abrasive materials.

What should I do if the tablet freezes?

Press and hold the Power button for 10 seconds to force a shutdown. Then turn it back on. If it persists, consider a factory reset.

Is the battery replaceable?

The battery is built-in and not user-replaceable. For replacement, contact a professional service center.

USER MANUAL MID72C MPMAN

User Manual
EN

This manual contains important safety precautions and information of correct use. Please be sure to read this manual carefully before use so as to avoid any accidents

Do not place the product in hot, wet or dusty environment, especially in summer, do not leave the product inside a car with all windows closed.
Avoid dropping, impacting or shaking the product violently, otherwise it may cause damages or malfunctions.
Select a proper volume to avoid ear problem when using earphones.
Do not cross the road or drive vehicles, using headphones to avoid traffic accidents.
Be sure to use the provided chargers and accessories in the package.
Be sure to charge the product when the following situations take place,
- The battery icon shows lower or empty.

- System automatically shut down and it turns off soon after restart. - Operation keys do not respond properly. - The device shows 📋 on the top right corner.

specification

Hardware
Software

Andriod 4.0 ICS

Google browser

Wi-Fi connection

e-Book function (all e-book formats supported by application)

1080p HD file playback

VoIP phone function with Wi-Fi connection

Possible to view/edit MS office files by application

Video: AVI, RM/ RMVB, FLV, MPG4 – 1, MPEG – 2 etc.

Audio: MP3, WMA, AAC, WAV etc.

Photo: JPEG, BMP, GIF, PNG, TIFF

7.0" High Definition TFT LCD Touch Screen (800x480 pixel)

Capacitive multi-touch (5 touch) point function

CPU: ARM cortex A8 processor

RAM : DDR3 512MB (3D accelerator possible for 3D games)

Wi-Fi (IEEE802.11 b/g/n) for internet connection

USB host for OTG function

G-sensor

Micro SD card slot recognizing up to 32GB

Built-in speaker & Built-in MIC

5V DC power adapter

Compatible with keyboard, mouse

Name

Important Notice

- If the device is freezing or stuck, press the reset button(a small hole) or long press power button for 7 seconds. - When the performance is slow after using some applications, it is recommended to close running application in setting menu.

Caution

- For charging, be sure to use the power adapter(DC5V) that is provided in the package, otherwise, the device may be damaged and does not work. - The device is equipped with high performance processor. It may heat in case of using long or while charging.

1. Power On/Off

Long press power button to turn on/off the device. It may take a minute to boot the device. Short press power button to turn on/off the screen.(Standby mode. Refer to 3. below)

After turning on the device, desktop displays with shortcut icons and arrow panel at the right side

Unlock the screen

Short press the power button to turn on/off the screen (standby mode on/off). After standby mode off, slide the lock icon in order to unlock the screen.

On the desktop, press menu button and select system settings.

Press System Settings

1.Wireless & networks

1. Sound


Wi-Fi – Press Wi-Fi to turn on/off
Wi-Fi settings - Press Wi-Fi settings, then the device
will automatically search the available Wi-Fi signals.
Select the network you want to connect with.

Set up each setting as you like.

Check device memory and microSD card status. Unmount SD card – Unmount the SD card for safe removal.
Set up each setting as you like.

6. Apps

Manage downloaded or running applications.

Downloaded
All installed application are listing.

5. Battery

Check battery usage status.

Running services
Press Uninstall to uninstall the selected application. View and control currently running services.

7. Account & sync

Create your account. After connecting Wi-Fi network, the e-mailing system synchronizes your account with the device. Emails are automatically downloaded into the device.

8. Location services

Google's location service - Let apps use data from sources such as WiFi and mobile networks to determine your approximate location

9. Security

Screen lock – Protect your device from unauthorized use by creating a personal screen unlock pattern. Make passwords visible – Show password as you type. Unknown sources - If you want to allow installation of non-Market Applications, Press Unknown sources and presses OK.

Install from SD card – Install encrypted certificates from SD card.

10. Language & input

Language – Choose your preferable language.

Keyboard & input method – Change keyboard & keyboard settings.

On Language & input settings, if you need other languages besides English on keyboard, press the relevant keyboard and enter the chosen Keyboard settings, select Keyboards, press the language you need.

11. Date & time

Set date & time and format

12. Developer options

Set options for application development

13. About tablet

See status, legal information, ETC

How to connect/disconnect the device with/from the computer

On main desktop, connect the device with the PC,

touch right side of the status bar on the bottom of desktop

Press “USB connected”, select “Turn on USB storage”. The device is recognized at Explorer of the computer. Now you can use it as an external storage.
After finishing your work, Press "Turn off USB storage" to unmount it.

How to install Applications(.apk file) into the device

Method 1.

1. Connect the device with internet. See above [1.Wireless & networks] in order to connect internet.

2. Follow the instruction on the screen for installation.

Method 2.

1. With your computer, search application file(.apk) that you want to install into the device.

2. Download the file(.apk) into your computer.

3. Connect the device with your computer.

See above [How to connect/disconnect the device with/from the computer.]

1. Copy and paste .apk file into the device and disconnect it from your computer.

2. Run "File browser" and find .apk file that was copied into the device.

3. Press the file to install and follow the instruction on the screen.

Note

You may only download adult applications if you are at least 18 years of age, or at least the age of majority in the jurisdiction where you reside or from which you download adult applications. If you do not meet these requirements, then you do not have permission to download adult applications. In case of any problems including legal issues from the breach by end-user's own decision, the manufacturer shall not be responsible.

How to make desktop icons

Press the upper right side icon of desktop, the pop-up displays.

Widgets

Press Widgets and press your desired icon to put it on the desktop.

Wallpaper

Long press the desktop, press Wallpapers and select one of categories of wallpaper. Select one you desire and press Set wallpaper.

Shortcuts

Long press your desired APK icon and put it on the desktop.

Change Input Method

If your device was installed with other more input method, long press setting icon of keyboard, and the pop-up displays.

Select the installed keyboard, then the keyboard will appear with your desired language you installed.

Specification

OS		Android 4.0 ICS
CPU		ARM cortex A8 processor
SDRAM		DDR3 512MB (3D accelerator possible for 4D games)
Display		7" TFT 800*480 Capacitive touch panel
Multi-touch screen		Yes : 5 point multi-touch
Built-in flash memory		2 / 4 / 8 / 16GB
IO PORTS	Audio port	3.5ø earphones
	USB port	1 x 5pin mini USB port (support USB host and OTG)
	DC port	5V, 2A
	Micro SD	Micro SD card
	OTG port	Same with USB port
	Button	Power, VOL-, VOL+, reset, 3 android function key
Speaker		1.5W, Frequency response : 20Hz – 20k Hz, N/S : >85%
G-sensor		Yes
Camera		0.3M pixel (front)
Wi-Fi		802.11b/g/n
Power		Adaptor 5V -2A
Battery		3.7V Li-Polymer
Dimension		118 x 196 x 10.3mm
Charging time	by charger	approx. 3~4hours

For more information please check our website

www.mpmaneurope.com
