MACS 180 - Air conditioner Meireles - Free user manual and instructions

Brand	Meireles
Model	MACS 180
Type	Split air conditioner (cooling and heating)
Cooling capacity	5.2 kW
Heating capacity	3.8 kW
SEER (Seasonal Energy Efficiency Ratio)	6.1
SCOP (Seasonal Coefficient of Performance)	4.0
Annual energy consumption (cooling)	298 kWh
Annual energy consumption (heating)	1330 kWh
Energy efficiency class (cooling)	A+++
Energy efficiency class (heating)	A+
Refrigerant type	R32
Power supply	230 V / 50 Hz
Noise level indoor unit	20 - 40 dB(A)
Noise level outdoor unit	50 - 60 dB(A)
Dimensions indoor unit (W x H x D)	800 x 300 x 200 mm
Dimensions outdoor unit (W x H x D)	800 x 600 x 300 mm
Weight indoor unit	10 kg
Weight outdoor unit	30 kg
Main functions	Cooling, Heating, Fan, Dehumidifier, Timer, Sleep mode
Maintenance	Clean air filters every 2-3 months
Safety features	Overheat protection, auto restart, refrigerant leak detection
Spare parts	Remote control, air filters, drainage hose
Manual	Downloadable PDF, 1 page, rated 9.0/10

Frequently Asked Questions - MACS 180 Meireles

How do I clean the air filters?

Turn off the unit and unplug it. Open the front panel, remove the filters, and wash them with warm water and mild detergent. Let them dry completely before reinstalling. Clean every 2-3 months for optimal performance.

What is the recommended temperature setting for cooling?

For energy efficiency, set the thermostat to 24-26°C (75-78°F). Each degree lower increases energy consumption by about 6-8%.

Can I use the air conditioner in winter?

Yes, the MACS 180 has a heating function. It can operate in ambient temperatures down to -10°C (14°F) for heating. Ensure proper drainage of condensate.

How do I reset the remote control?

Remove the batteries from the remote, wait 10 seconds, then reinsert them. If it still doesn't work, replace the batteries or check for obstacles between remote and unit.

What is the energy consumption of this model?

The annual cooling consumption is 298 kWh and heating consumption is 1330 kWh, based on standard usage. Actual consumption varies with climate and settings.

How do I install the unit?

Installation should be done by a qualified professional. It involves mounting the indoor and outdoor units, connecting refrigerant lines, and electrical wiring. Refer to the manual for detailed steps.

What should I do if water leaks from the indoor unit?

Check if the drainage hose is blocked or kinked. Clean the drain pan and ensure the unit is level. If the problem persists, contact a technician.

How loud is the air conditioner?

The indoor unit produces 20-40 dB(A) depending on fan speed, while the outdoor unit makes 50-60 dB(A). It is designed to be quiet for comfortable use.

Does the unit have a timer function?

Yes, you can set a timer to turn the unit on or off automatically. Use the remote control to program the timer up to 24 hours in advance.

Where can I find spare parts?

Spare parts such as remote controls, air filters, and drainage hoses are available from Meireles authorized dealers or online. Contact customer support for assistance.

USER MANUAL MACS 180 Meireles

European Union flag with twelve yellow stars arranged in a circle on a blue background (no text or symbols)

ENERG

енергия · ενεργεια

meireles

Model MACS 180

MAC 901 W INT×2

kW 5,2 SEER 6,1 kWh/annum 298

kW X 3,8 X SCOP X 4,0 X kWh/annum X 1330 X

Colorful abstract map-like shape with no text or symbols

ENERGIA·EHEPΓΙΑ·ENEPTEIA·ENERGIJA·ENERGY·ENERGIE·ENERGI

626/2011

62229967573
