Brand	Summit
Model	DW2433SS2ADA
Product Type	Built-in Dishwasher
Capacity	Standard (24 inches)
Energy Star Certified	Yes
Estimated Yearly Electricity Use	255 kWh
Estimated Yearly Operating Cost (Electric Water Heater)	$22
Color/Finish	Stainless Steel
Control Type	Electronic Digital
Number of Cycles	6 (Normal, Light, Heavy, Rinse, Quick, Energy Saver)
Number of Place Settings	14
Noise Level	48 dBA
Dimensions (H x W x D)	33.5 x 23.75 x 24.5 inches
Weight	75 lbs
Power Supply	120V, 60Hz, 15A
Water Connection	Hot water supply, 3/8 inch compression
Delay Start	Yes (1-24 hours)
Child Lock	Yes
Rinse Aid Dispenser	Yes
Filter Type	Self-cleaning hard food disposer

Frequently Asked Questions - DW2433SS2ADA Summit

What should I do if my Summit DW2433SS2ADA dishwasher does not start?

First, ensure the door is securely closed and latched. Check that the circuit breaker is not tripped and the power cord is properly plugged in. Also verify that the water supply is turned on. If the issue persists, try pressing the Reset button or cancel the current cycle.

How do I clean the filter on my Summit dishwasher?

The filter assembly is located at the bottom of the tub. Turn it counterclockwise to remove the upper filter, then lift out the lower filter. Rinse both under running water, scrubbing with a soft brush if needed. Avoid using abrasive cleaners. Reinstall by pressing down and turning clockwise until secured.

Why is my dishwasher showing an error code E1?

Error code E1 typically indicates a water inlet failure. Ensure the water supply valve is fully open and the inlet hose is not kinked. Also check that the water pressure is adequate (20-120 psi). If the problem continues, the inlet valve may need replacement.

What type of detergent should I use?

Use only automatic dishwasher detergent in powder, gel, or tablet form. Do not use hand dishwashing liquid as it can cause excessive suds and damage. For best results, select a detergent with enzyme action for tough stains and always fill both the main and pre-wash compartments.

How can I reduce the noise level of my dishwasher?

Ensure the dishwasher is level by adjusting the front legs. Check for any loose panels or items inside that may rattle. Using the Delay Start feature to run cycles during low-traffic times can also help. The DW2433SS2ADA operates at 48 dBA, which is relatively quiet.

What cycles are available on this model?

The Summit DW2433SS2ADA offers 6 cycles: Normal, Light, Heavy, Rinse, Quick (30 min), and Energy Saver. Each cycle adjusts water temperature, wash time, and rinse intensity. Refer to the user manual for specific cycle details and recommended usage.

How do I install the dishwasher properly?

Installation should be performed by a qualified professional. Ensure the electrical supply is 120V/60Hz and properly grounded. Connect the water supply to a hot water line (120°F max) and the drain hose securely to a garbage disposal or standpipe. Level the unit using the front legs and secure it to the countertop.

Why are my dishes not drying completely?

Ensure the rinse aid dispenser is filled regularly, as it improves drying. Use the Heated Dry option if available. Avoid overloading and ensure dishes are arranged so water can run off. If the problem persists, check that the water temperature in the cycle is high enough (final rinse at 140°F).

Can I use a different brand of detergent pods?

Yes, you can use any branded automatic dishwasher pod as long as it is designed for standard dishwashers. Place the pod in the main detergent compartment and close the lid. Do not use pods if the cycle time is very short (e.g., Quick cycle) as they may not dissolve fully.

How do I cancel a running cycle?

Press and hold the Start/Reset button for about 3 seconds. The dishwasher will drain and cancel the cycle. If the water is hot, allow it to cool before opening the door. After cancellation, you can select a new cycle. For models with Child Lock, disable it first if needed.

USER MANUAL DW2433SS2ADA Summit

U.S. Government Federal law prohibits removal of this label before consumer purchase.

ENERGYGUIDE

Dishwasher

Capacity: Standard

Felix Storch, Inc.

Model DW2433SS2ADA

Estimated Yearly Energy Cost

(when used with an electric water heater)

Cost Range of Similar Models

255 kWh

Estimated Yearly Electricity Use

\$22

Estimated Yearly Operating Cost

(when used with a natural gas water heater)

Your cost will depend on your utility rates and use.

• Cost range based only on standard capacity models.
• Estimated energy cost based on four wash loads a week and a national average electricity cost of 12 cents per kWh and natural gas cost of \$1.09 per therm.
• For more information, visit www.ftc.gov/energy.

ENERGY STAR
