PCS3178L - Refrigerator Pelgrim - Free user manual and instructions

Product Type	Freestanding Refrigerator-Freezer
Total Net Capacity	260 L (189 L refrigerator + 71 L freezer)
Energy Efficiency Class	A+
Annual Energy Consumption	274 kWh/year
Noise Level	38 dB
Climate Class	SN-ST
Dimensions (H x W x D)	2010 x 1060 x 600 mm
Weight	70 kg
Voltage / Frequency	220-240 V / 50 Hz
Refrigerant	R600a
No Frost Technology	Yes
Reversible Door	Yes
Adjustable Shelves	Yes
Fridge Capacity	189 L
Freezer Capacity	71 L
Freezing Capacity	4 kg/24h
Storage Time during Power Failure	10 h
Defrosting	Automatic (No Frost)
Control Type	Electronic
Display	LED
Power Cord Length	1.5 m
Maintenance	Clean condenser coils and door seals regularly
Safety Features	Child lock (if applicable)
Spare Parts Availability	Via Pelgrim service centers

Frequently Asked Questions - PCS3178L Pelgrim

How do I set the temperature on my Pelgrim PCS3178L fridge?

Use the electronic control panel inside the fridge compartment. Press the temperature button to cycle through settings. Refer to the user manual for recommended temperatures.

Why is my fridge making unusual noises?

Occasional sounds like clicking, humming, or gurgling are normal due to refrigerant flow and compressor operation. If persistent loud noises occur, check if the fridge is level and not touching walls.

How much energy does the PCS3178L consume?

The annual energy consumption is 274 kWh/year, which corresponds to energy class A+.

Does the PCS3178L have a No Frost feature?

Yes, this model is equipped with No Frost technology, preventing ice build-up in the freezer and fridge compartments.

How do I defrost the freezer?

Since the freezer has No Frost, manual defrosting is not required. The system automatically defrosts during operation.

What is the total capacity of the PCS3178L?

The total net capacity is 260 liters, with 189 liters for the fridge and 71 liters for the freezer.

What are the dimensions of the fridge?

Dimensions are 2010 mm (height) x 1060 mm (width) x 600 mm (depth). Ensure sufficient clearance for door opening.

Can I reverse the door opening direction?

Yes, the door is reversible. Please consult the user manual for step-by-step instructions on how to change the hinge side.

How do I clean the fridge?

Unplug the appliance. Clean interior with a mild detergent and warm water. Avoid abrasive cleaners. Clean the condenser coils at the back annually for optimal performance.

Where can I find spare parts for my Pelgrim fridge?

Spare parts are available through Pelgrim service centers or authorized dealers. Use the model number PCS3178L when ordering.

USER MANUAL PCS3178L Pelgrim

European Union flag with twelve yellow stars on a blue background (no text or symbols)

ENERG

енергия · ενεργεια

Pelgrim 11

PCS3178L

ENERGIA · ЕНЕРГИЯ

ENEPΓEIA · ENERGIJA

ENERGY · ENERGIE · ENERGI

274

kWh/annum

189 L

71 L

38 dB

2010/1060
