USER MANUAL STR-BWC72 Stirling

Abstract black-and-white spiral pattern enclosed in a circle (no text or symbols)

STIRLING®

Black Stirling water tap shaker with red wine stopper and digital display (no text or symbols on device)

Single Wine Bottle Cooler

Model Number: STR-BWC72

INSTRUCTION MANUAL

Welcome

Congratulations on choosing to buy a STIRLING ^® product.

All products brought to you by STIRLING ^® are manufactured to the highest standards of performance and safety and, as part of our philosophy of customer service and satisfaction, are backed by our comprehensive warranty. We hope you will enjoy using your purchase for many years to come.

Contents

02 Welcome
04 Warranty Details
05 General Safety Instructions
07 Product Overview
08 Getting Started
09 Instructions
10 FAQs and Troubleshooting Guide
11 Other Useful Information
13 Repair and Refurbished Goods or Parts Notice

ALDI

STIRLING®

Single Wine Bottle Cooler

Warranty Details

REGISTER YOUR PURCHASE AT www.aldi.com.au/en/about-aldi/product-registration/ TO KEEP UP-TO-DATE WITH IMPORTANT PRODUCT INFORMATION

The product is guaranteed to be free from defects in workmanship and parts for a period of 12 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion. The benefits conferred by this warranty are in addition to all rights and remedies in respect of the product that the consumer has under the Competition and Consumer Act 2010 and similar state and territory laws.

Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and to compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.

1

YEAR WARRANTY

General Safety Instructions

IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE

Read this manual thoroughly before first use, even if you are familiar with this type of product. The safety precautions enclosed herein reduce the risk of fire, electric shock and injury when correctly adhered to. Keep the manual in a safe place for future reference, along with the completed warranty card, purchase receipt and carton. If applicable, pass these instructions on to the next owner of the appliance.

Always follow basic safety precautions and accident prevention measures when using an electrical appliance, including the following:

Electrical Safety and Cord Handling

• Voltage: The appliance must only be supplied at the correct voltage from a power source via the supplied power adaptor.
• Electrical circuit: Always plug the adaptor into a separate wall outlet socket. Use a safe socket with an earthed connection. To ensure you do not overload the circuit, do not operate another high-wattage product on the same circuit.
• Connection: To insert the adaptor, grasp it firmly and guide it into the outlet.
• WARNING! No extension cord: Do not use the wine cooler with a power board or extension cord, as these may overheat and create a fire risk.

- Protect the power cord:

• Do not operate the wine cooler with the cord coiled up; always fully unwind.
• Do not twist or kink the cord or let it touch heated surfaces.
• Do not put any stress on the cord where it connects to the product.
• Never carry the wine cooler by the cord.
• Arrange the cord away from any traffic areas so no one will trip over it.

• Do not run the cord under carpeting or cover it with rugs, runners, etc.

• Damaged cord: Check the power supply cord regularly for visible damage. If it is damaged, it must be replaced by the manufacturer or appropriately qualified personnel in order to avoid any hazards.

• Plug: It is normal for the plug to feel warm; however, a loose fit between the AC outlet and plug may cause overheating and distortion of the plug. Contact a qualified electrician to replace a loose outlet. This appliance is only to be used with the power supply unit provided.

- Winding the cord: If winding the power cord, avoid tight bends as this could damage the cord.

- After use: Switch off and unplug the appliance from the power outlet when it is not in use and before cleaning, servicing, moving or storing the appliance. To disconnect, switch it off and remove the adaptor from the outlet. Grip the adaptor, do not pull the cord.

- WARNING! Never unplug the unit by pulling the cord. Always grip the plug firmly and pull straight out from the power point.

- Protect from moisture: To protect against the risk of electric shock, do not immerse the unit, cord or plug in water or spray any other liquids on the appliance and parts. Do not connect or disconnect the electric plug with wet hands, while standing on a wet surface or while standing in water.

General Safety Instructions (Cont.)

Usage Conditions and Restrictions

• Domestic use only: This wine cooler is intended for household use only. It is NOT suitable for commercial, industrial or trade use.
• Intended use: The wine cooler is designed to maintain the ideal drinking temperature for pre-cooled bottles of wine, sparkling wine, and other beverages (soft drinks), ensuring long-term enjoyment. This only accommodates bottles with a maximum diameter of 90 mm.
• Usage restriction: The appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
• Children: Supervise children to ensure they do not play with the appliance. Close supervision is necessary when any appliance is used by or near children. Cleaning and user maintenance shall not be made by children unless they are older than 8 years and supervised.
• Liability: We accept no liability for any eventual damages or personal injury caused by misuse of the product and/or failure to follow these instructions.
• Misuse: Improper application or misuse may result in the risk of fire, electric shock and injury. We accept no responsibility for any eventual injury or damage caused by improper use or noncompliance with this manual.
  • Repair: Do not attempt to repair, disassemble or modify the product; there are no user derivicable parts inside. In case of damage, contact our after sales support centre.
• Unattended: Do not leave the wine cooler unattended when it is switched on. Disconnect it from the power supply when you are finished with it or when leaving the room.
• Disconnect: Unplug the wine cooler before cleaning or moving. Failure to do so can result in electric shock, injury or death. Do not connect or disconnect the plug when your hands are wet.
• Storage: When not in use, store your appliance and its instruction manual in a safe and dry place.
• Cleaning: This wine cooler must be cleaned regularly. Ensure the device is turned off and unplugged prior to cleaning. If dampness penetrates the cooler, this can damage the internal electronic components. Do not immerse.
• Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.
• WARNING: When positioning the appliance, ensure the supply cord is not trapped or damaged.
• WARNING: Do not locate multiple portable socket-outlets or portable power suppliers at the rear of the appliance.

Product Overview

Scope of Delivery

1 2 3 STIRLING °C F 888 V 9 °C/°F 45 7 8

Single Wine Bottle Cooler

1. Cooling Cavity
2. Wine Cooler
3. Control Panel
4. C°/F° Button
5. Increase Temperature Button
6. Display Screen
7. Decrease Temperature Button
8. Power Button
9. LED Indicator
10. Adaptor (not shown)

Documentation (not shown)

Quick Start Guide

Instruction Manual

Warranty Certificate

NOTE: Due to continued product improvement, images and illustrations in this manual may vary slightly from the product purchased. All images in this manual are for reference purposes only. Parts are not necessarily pictured to scale.

Getting Started

Before first use

• Unpack: This product has been packaged to protect it against transportation damage. Unpack the appliance and keep the original packaging materials in a safe place. It will help prevent any damage if the product needs to be transported in the future, and you can use it to store the appliance when it is not in use. In the event that the packaging is to be disposed of, please recycle it where possible.
  Plastic wrapping can be a suffocation hazard for babies and young children, so ensure all packaging materials are out of their reach. Dispose of any plastic wrapping safely.
• Documentation: Make sure you have read and understood all instructions and warnings in this manual. Refer to the Product Overview to familiarise yourself with the product and identify all parts. Pay particular attention to the safety instructions on the previous pages.
• Cord: Unwind the power supply cord to its full length and inspect the cord and plug for damage. Inspect all other parts of the appliance for visual damage. Do not use the appliance if anything appears to be damaged or not working properly. In case of damage, contact our after sales support centre using the details at the bottom of the page.
• Clean: Wipe the outside of the wine cooler with a damp cloth. Make sure there is no packaging material remaining.

Instructions

Preparation

In order to ensure the safe and trouble-free operation of the wine cooler, the setup location must fulfil the following prerequisites:

• The device must be set up on a firm, flat, horizontal surface with sufficient load-bearing capacity for the device.
• The device is not intended to be installed in a wall or a built-in cupboard.
• Do not operate the product near hot gas or hot stove.
• Choose the setup location in such a way that children cannot reach the device.
• Do not set up the device in a hot, wet or extremely damp environment or near flammable material.
• The electrical socket must be easily accessible so that the power lead can be disconnected easily, in the case of an emergency.

How to Use

Connect the adapter plug to the wine cooler, then insert the plug into a secure powerpoint.

On the control panel of the wine cooler, press the Power button to turn on.

You can set your desired temperature using the Increase Temperature and Decrease Temperature buttons on the control panel. The temperature range is from 5-18°C or 41-64°F.

Place a suitable bottle (90 mm or less in diameter) into the wine cooler. The device should now start to cool down.

The LED will remain flashing until the desired temperature is reached. From here it will remain constantly illuminated. If the temperature deviates by 3^ C or more the LED light will begin flashing again until the temperature is reached.

If you press and hold the °C/°F button the wine cooler's interior temperature will be displayed for a few seconds.

The cooling power of the device depends on various factors:

Ambient Temperature: The maximum achievable power depends, amongst other things, on the outside temperature. Rapid cooling is possible at a lower ambient temperature. If the ambient temperature is very high, cooling may need more time.

Note: Ambient temperature below 16^ C or above 32^ C will hinder the performance of the appliance

Bottle Starting Temperature: A pre-cooled bottle is immediately kept cool.

Bottles that arent pre-cooled need more time to reach the desired drinking temperature.

FAQS and Troubleshooting Guide

If you encounter any problems with your wine cooler, try the suggestions below to see if you can solve the problem before contacting our after sales support centre. You can solve common problems easily, saving you the time of a possible service call.

Problem Solution
The wine temperature control does not work.	The device may not be connected to power.
	The electrical circuit may be broken.
The wine or beverage is not sufficiently cooled.	The wine or beverage wasn’t chilled for long enough.
	The ambient temperature is too high.

Other Useful Information

Cleaning and Care

CAUTION!

• The wine cooler must be cleaned regularly
• Ensure the wine cooler is off and unplugged from the wall power outlet prior to cleaning.
• If dampness penetrates into the device. The electronic components may be damaged. Please ensure that no liquid can enter the interior of the device through the ventilation slots.
• Do not immerse the appliance into water or other liquids, and do not put it in the dishwasher.

To clean the wine cooler simply wipe the outside and inside body of the case with a damp cloth. Once cleaned, ensure that the appliance is dried thoroughly.

Do not use any aggressive or abrasive cleaning agents or solvents.

Do not scrape off stubborn dirt with hard items.

Storage

Ensure the wine cooler is clean and completely dry before storing.

Store your appliance and its instruction manual in a safe and dry place.

Service, Repair and Spare Parts

The product contains no user-servicable parts. Do not attempt to take it apart, repair or modify it.

Do not operate the product if it is damaged or working abnormally. Contact our after sales support centre if a service is required.

To do so, visit tempo.org/support or call 1300 112 534.

Other Useful Information (Cont.)

Technical Specifications

Product Single Wine Bottle Cooler
Model Number STR-BWC72
Rating 14.5 V 6.0 A	---
Adaptor Model Number GRT90-145600
Adaptor Input 100-240 V~ 50/60 Hz 2.5 A max
Adaptor Output 14.5 V 6.0 A 87.0 W	---
Temperature Range 5 - 18°C (41 - 64°F)
Climate Class T
Dimensions (approx.) (W) 142.5 x (D) 198 x (H) 271 mm
Weight (approx.) 1.27 kg (without adaptor)

Compliance

This appliance has been fully tested and meets all requirements as set out by standards AS/NZS 60335.1 and AS/NZS 60335.2.24.

The RCM Mark (Regulatory Compliance Mark) indicated that the product

complies with the relevant guidelines of the ACMA as well as corresponding government requirements for the safety of electrical devices.

This marking indicates only to use this wine cooler with the supplied adaptor GRT90-145600.

ASS II DOUBLE INSULATED APPLIANCE

This symbol indicates that the appliance has been designed in such a way that it does not require a safety connection to electrical earth (ground).

This marking indicates that the appliance is suitable for use in tropical climates under ambient temperatures of 18 °C to 43 °C .

Responsible Disposal

Packaging materials are recyclable. Please dispose of them responsibly for recycling.

At the end of its working life, do not throw this appliance out with your household waste. Electrical and electronic products contain substances that can have a detrimental effect on the environment and human health if disposed of inappropriately. Observe and local regulations regarding the disposal of electrical consumer goods and dispose of it appropriately or recycling. Contact your local authorities for advice on recycling facilities in your area. Or find recycling scheme services listed on Planet Ark's website at www.recyclingnearyou.com.au, or call Planet Ark on 1300 730 712.

ALDI

STIRLING®

Single Wine Bottle Cooler

Repair and Refurbished Goods or Parts Notice

Unfortunately, from time to time, faulty products are manufactured which need to be returned to the supplier for repair.

Please be aware that if your product is capable of retaining user-generated data (such as files stored on a computer hard drive, telephone numbers stored on a mobile telephone, songs stored on a portable media player, games saved on a games console or files stored on a USB memory stick) during the process of repair, some or all of your stored data may be lost. We recommend you save this data elsewhere prior to sending the product for repair.

You should also be aware that rather than repairing goods, we may replace them with refurbished goods of the same type or use refurbished parts in the repair process.

Please be assured though, refurbished parts or replacements are only used where they meet ALDI's stringent quality specifications.

If at any time you feel your repair is being handled unsatisfactorily, you may escalate your complaint. Please telephone us on 1300 112 534 or write to us at:

Tempo (Aust) Pty Ltd (ABN 70 106 100 252)

PO BOX 6097, North Sydney 2059, NSW Australia

Web Support: tempo.org/support

Tempo Help Desk: 1300 112 534 (Aust)

(Operating Hours: Mon-Sat 09:00 am to 06:00 pm AEST)

1 YEAR WARRANTY

This page has been left blank intentionally.

This page has been left blank intentionally.

Icon showing a person reading a book with an exclamation mark symbol (no text or numbers present)

Please read the manual

It will help you get the best out of your product.

Still have questions?St

Call after sales support 1300 112 534

Or visit www.tempo.org

Warranty Returns

Should you for any reason need to return this product for a warranty claim, make sure to include all accessories with the product.

Product Does Not Work?

If you encounter problems with this product, or if it fails to perform to your expectations, make sure to contact our After Sales Support Centre on 1300 112 534 for advice.

Instruction Manual Revision Index

Version No Issue Date Description

V1.0 5 April 2024 Original Release (2024)

V1.1 23 May 2024 Minor Update – page 12
