USER MANUAL SJ-T440R SHARP

Tuesday, November 13, 2007

• Free standing type

SJ-CT440R SJ-CT480R Tuesday, November 13, 2007

Page 3 Monday, November 26, 2007

9:50 AM Thank you very much for buying this SHARP product. Before using your SHARP refrigerator, please read this operation manual to ensure that you gain the maximum benefit from it.

Do not install the refrigerator in a damp or wet location as this may cause damage to the insulation and a leak. Condensation may also build on the outer cabinet and cause rust.

• The figure shows the minimum required space for installing the refrigerator. It differs from the space in the measurement condition of the amount of power consumption.

• It is possible to use the refrigerator with a less amount of power consumption by keeping greater space. • If using the refrigerator in the space below dimension of the figure, it may cause the temperatures in the unit to rise, loud noise, and failure. 90 mm or more 60 mm or more

Do not touch the compressor unit or its peripheral parts, as they become extremely hot during operation and the metal edges may cause injury.

Do not touch foods or metal containers in the freezer compartment with your wet hands. This may cause frostbite. Do not use an extension cord or adapter plug. Do not place bottled and canned drinks in the freezer as they may crack when frozen. Make sure that the power cord has not been damaged during installation or moving. If the power plug or cord is loose, do not insert the power plug. There is a risk of electric shock or fire. Disconnect from the mains electricity supply by removing the mains plug from the electricity supply socket. Do not remove by pulling the mains lead. This may cause electric shock or fire. Should the flexible supply cord be damaged, it must be replaced by service agent approved by SHARP as a special cord is required. In case of gas leak, ventilate the area by opening a window, etc. Do not touch the refrigerator or the power outlet. Do not place objects containing liquid or unsteady objects on top of refrigerator. This refrigerator is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the refrigerator by a person responsible for their safety. Young children should be supervised to ensure that they do not play with the refrigerator.

adequate ventilation space around the

1 Keep refrigerator.

the two front adjustable feet, ensure that the

2 Using refrigerator is positioned firmly and level on the floor. the 2 screws of the cabinet lower part, and 3 Remove use these to fit the foot covers. (supplied inside the refrigerator compartment)

This refrigerator contains flammable refrigerant (R600a: isobutane) and insulation blowing gas (cyclopentane).

Observe the following rules to prevent ignition and explosion. • The refrigeration system behind and inside the refrigerator contains refrigerant. Do not allow any sharp objects to come into contact with the refrigeration system. • Do not use mechanical devices or other means to accelerate the defrosting process. (This refrigerator has adopted automatic defrosting system.) • Do not use electric appliances inside the refrigerator. • Use only the specified lamp for the refrigerator compartment. • Do not block the openings on the circumference of the refrigerator. • If the refrigeration system should get punctured, do not touch the wall outlet and do not use open flames. Open the window and air out the room. Then ask a service agent approved by SHARP for servicing. • This refrigerator should be disposed appropriately. Take the refrigerator to a recycling plant for flammable refrigerant and insulation blowing gases. ■ Highly volatile and flammable materials such as ether, petrol, propane gas, adhesive agents and pure alcohol etc. are liable to explode. Do not store these materials in the refrigerator. ■ Dust deposited on the power plug may cause fire. Wipe it off carefully. ■ Do not attempt to change or modify this refrigerator. This may result in fire, electric shock or injury. ■ Ensure that the refrigerator presents no danger to children while being stored for disposal. (e.g. remove the magnetic door seals to prevent child entrapment.) ■

INSTALLATION NL PL H Adjustable foot

• Position your refrigerator so that the plug is accessible. • Keep your refrigerator out of direct sunlight. • Do not place next to heat generating appliance. • Do not place directly on the ground.

CZ SK Provide suitable stand.

• Using the casters, it is possible to move back and forth. • Carry the refrigerator by holding the handles located on the rear and bottom.

LT LV EST SLO UA Before using your refrigerator

Clean the inside parts with a cloth soaked in warm water. If soapy water is used, wipe it off thoroughly with water.

Page 4 Monday, December 10, 2007

11:36 AM DESCRIPTION

13. Adjustable feet & cover

(SJ-T440R, SJ-T480R)

SJ-CT440R, SJ-CT480R

19 4. Fresh case & door 20 5. Refrigerator light SJ-T440R, SJ-CT440R 6. Freezer temp. control knob 21 7. Refrigerator temp. control 20. Utility pocket (large) 22 knob (Only for SJ-T480R, SJ-CT480R) • Do not replace the right and left 8. Refrigerator shelf (2 pcs.) 16 position of the utility pocket and 9. Hybrid cooling panel the utility pocket (large). 14 (Aluminum panel) SJ-T480R (Only for SJ-T440R, SJ-T480R) 21. Bottle pocket for storing frozen food only. 10. Fruit and vegetable shelf 22. Tube stand (Only for SJ-T440R, SJ-T480R) 11. Fruit and vegetable crisper 19

Controlling temperature

Hints when making ice

Adjustable by turning each knob.

not over fill the Ice cube trays; otherwise the ice

1 Do cubes will be joined together when frozen. SJ-T480R 2 SJ-T440R, Lever When the ice cubes are made,

Hybrid cooling panel (Aluminum panel)

turn the lever clockwise to empty the ice into the Ice cube box.

SJ-CT440R, SJ-CT480R When the ice cubes are made, hold the Ice cube tray upside down whilst twisting either end in opposite directions, allowing the ice cubes to drop out.

The panel is cooled from the rear, thus indirectly cooling the refrigerator compartment. In this way, food is refrigerated gently, without exposing it to cold air flow.

NOTE Deodorizing unit

Deodorizing catalyst is installed on the routes of cold air.

No operation and cleaning are required.

To prevent damage to the Ice cube box, do not make ice in the Ice cube box or pour oil into it.

Prevents bottles etc. from falling.

Stick-type food products can also be stored inside.

INDICATOR OF TEMPERATURE This refrigerator is provided with a indicator of temperature in the refrigerator compartment to allow you to control the average temperature in the coldest zone.

The symbol indicates the coldest zone in the refrigerator compartment.

(The door pocket positioned at the same height isn’t the coldest zone.)

Checking the temperature in the coldest zone

You can carry out regular checks to ensure the temperature in the coldest zone is correct and, if necessary, adjust the refrigerator temp. control as indicated in the chapter “Controlling Temperature”. To maintain a correct temperature inside the appliance, check that the indicator of temperature is always BLUE. If the indicator of temperature turns WHITE, the temperature is too high; in this case, increase the refrigerator temp. control setting and wait for 6 hours before checking the indicator of temperature again.

BLUE Correct setting

WHITE Temperature too high, adjust the refrigerator temp. control.

• The internal temperature of the refrigerator depends on various factors such as the ambient temperature of the room, the amount of food stored and the frequency of door opening.

• When fresh food has been introduced or the door has been left open for some time, it is normal for the indicator of temperature to turn WHITE.

Page 5 Monday, November 26, 2007

9:50 AM STORING FOOD Refrigeration reduces the rate of food spoilage.

To maximize the shelf life of perishable food products, ensure that the food is the freshest possible quality. The following is a general guide to help promote longer food storage. • Ensure all cooked food is wrapped securely or placed in an airtight container. • To minimize moisture loss, fruit and vegetables should be loosely enclosed in a plastic material e.g. wrap, bags (do not seal) and place in the fruit and vegetable crisper. • Eggs should be stored in the Egg holder. • Evenly place the food on the shelves to allow the cooling air to circulate efficiently. • Hot foods should be cooled before storing. Storing hot foods increases the temperature in the unit and increases the risk of food spoilage. • Do not block the outlet and inlet of the cool air circulating circuit with foods or containers; otherwise the foods will not be evenly cooled throughout the refrigerator. • Keep the door securely closed.

• Quality of foods should be fresh. • Freeze small quantities of food at a time to freeze them quickly. • Food should be properly stored or covered and the air should be removed to seal tightly. • Evenly place the food in the freezer. • Label bags or containers to keep an inventory of freezing food.

GB E I F P GR D NL CARE AND CLEANING WARNING

Unplug the refrigerator first to prevent electric shock.

Do not splash water directly on the outer cabinet or the interior. This may lead to rusting and deterioration of the electrical insulation.

IMPORTANT To prevent cracking on inside surfaces and plastic components, follow these tips.

• Wipe any food oils adhered to plastic components. • Some household chemicals may cause damage, so use only diluted washing-up liquid (soapy water). • If undiluted detergent is used or soapy water is not wiped off thoroughly, cracking of plastic parts can result.

Remove the shelves and pockets from the cabinet and door. Wash them in warm soapy dishwashing water; rinse in clean water and dry. (Only fruit and vegetable shelf is not removable.)

the inside with a cloth soaked in warm soapy

2 Clean dishwashing water. Then, use cold water to wipe off soapy water.

3 Wipe the exterior with a soft cloth each time it is soiled. the Magnetic door seal with a toothbrush and

4 Clean warm soapy dishwashing water.

• To prevent damage to your refrigerator, do not use heavy

duty cleansers or solvents (lacquer, paint, polishing powder, benzine, boiled water, etc.).

• If the power supply is disconnected, please wait for at least 5 minutes before re-connecting power. • The glass shelves weigh approximately 2 kg each. Hold firmly when removing from the cabinet or carrying. • Do not drop objects inside the refrigerator or strike the inner wall. This may cause the inner surface to crack.

Defrosting is fully automatic due to a unique energy saving system.

H RO CZ SK LT When the compartment light is blown

Contact the service agent approved by SHARP to request a replacement compartment light. The compartment light is not to be removed other than by qualified service personnel.

LV EST Switching off your refrigerator

If you switch your refrigerator off when you are going away for an extended period, remove all food, clean the interior thoroughly. Remove the power cord plug from the power socket and leave all doors open.

Page 6 Monday, November 26, 2007

9:50 AM WHAT TO DO BEFORE YOU CALL FOR SERVICE Before you call for service, check the following points.

The outside of a cabinet is hot when touched.

It is normal. The hot pipe is in the cabinet in order to prevent dew generation.

When there is refrigerator noise.

It is normal for the refrigerator to produce the following sounds.

• Loud noise produced by the compressor when operation starts --- Sound becomes quieter after a while. • Loud noise produced once a day by the compressor --- Operating sound produced immediately after automatic defrost operation. • Sound of flowing fluid (gurgling sound, fizzing sound) --- Sound of refrigerant flowing in pipes (sound may become louder from time to time). • Cracking or crunching sound, squeaking sound --- Sound produced by expansion and contraction of inner walls and internal parts during cooling.

Frosting or dew generation occurs inside or outside the refrigerator.

This may occur in one of the following cases. Use a wet cloth for wiping frost and a dry cloth for wiping dew.

• When the ambient humidity is high. • When the door is frequently opened and closed. • When foods containing plenty of moisture are stored. (Wrapping is required.)

The foods in the refrigerator compartment freeze.

• Is the refrigerator operated for a long time with temp. control set at MAX?

• Low ambient temperature may cause placed foods to freeze even if refrigerator temp. control is set to MIN.

It smells in the compartment.

• Wrapping is required for the foods with strong smell.

• Deodorizing unit cannot remove all of smell.

IF YOU STILL REQUIRE SERVICE Refer to your nearest service agent approved by SHARP.

Information on Disposal for Users (private households)

1. In the European Union Attention: If you want to dispose of this equipment, please do not use the ordinary dust bin! Used electrical and electronic equipment must be treated separately and in accordance with legislation that requires proper treatment, recovery and recycling of used electrical and electronic equipment. Following the implementation by member states private households within the EU states may return their used electrical and electronic equipment to designated collection facilities free of charge*. In some countries* your local retailer may also take back your old product free of charge if you purchase a similar new one. *) Please contact your local authority for further details. Attention: If your used electrical or electronic equipment has batteries or accumulators, please dispose of Your product is marked these separately beforehand according to local requirements. with this symbol. By disposing of this product correctly you will help ensure that the waste undergoes the It means that used necessary treatment, recovery and recycling and thus prevent potential negative effects on the electrical and electronic environment and human health which could otherwise arise due to inappropriate waste handling. products should not be 2. In other Countries outside the EU mixed with general household waste. If you wish to discard this product, please contact your local authorities and ask for the correct There is a separate method of disposal. collection system for For Switzerland: Used electrical or electronic equipment can be returned free of charge to the these products. dealer, even if you don't purchase a new product. Further collection facilities are listed on the homepage of www.swico.ch or www.sens.ch.

Page 7 Monday, November 26, 2007

2:41 PM Page 8 Monday, December 10, 2007

11:51 AM DESCRIPCION

SJ-CT440R, SJ-CT480R Page 9 Monday, November 26, 2007

2:41 PM Monday, November 26, 2007

2:41 PM Monday, December 10, 2007

11:28 AM Monday, December 10, 2007

11:28 AM DESCRIZIONE

SJ-CT440R, SJ-CT480R

SJ-T440R, SJ-CT440R Monday, November 26, 2007

10:58 AM Monday, November 26, 2007

10:58 AM Monday, November 26, 2007

10:41 AM Monday, December 10, 2007

11:26 AM DESCRIPTION

(SJ-T440R, SJ-T480R)

SJ-CT440R, SJ-CT480R

SJ-T480R Monday, November 26, 2007

10:41 AM Monday, November 26, 2007

10:41 AM Monday, December 10, 2007

11:24 AM Monday, December 10, 2007

SJ-CT440R, SJ-CT480R Monday, November 26, 2007

11:08 AM Monday, November 26, 2007

11:08 AM Monday, November 26, 2007

11:13 AM Monday, December 10, 2007

SJ-T440R, SJ-CT440R Monday, November 26, 2007

11:13 AM Monday, November 26, 2007

11:13 AM Monday, November 26, 2007

11:01 AM Monday, December 10, 2007

(SJ-T440R, SJ-T480R)

SJ-CT440R, SJ-CT480R

SJ-T440R, SJ-CT440R Monday, November 26, 2007

11:01 AM Monday, November 26, 2007

11:01 AM Monday, November 26, 2007

10:37 AM Monday, December 10, 2007

11:39 AM BESCHRIJVING

(SJ-T440R, SJ-T480R)

SJ-CT440R, SJ-CT480R

SJ-T440R, SJ-CT440R Monday, November 26, 2007

10:37 AM ONDERHOUD EN SCHOONMAKEN WAARSCHUWING

Monday, November 26, 2007

10:37 AM Tuesday, December 18, 2007

1:13 PM Thursday, December 6, 2007

SJ-CT440R, SJ-CT480R

SJ-T480R SJ-T440R, SJ-CT440R Monday, November 26, 2007

11:58 AM Monday, November 26, 2007

11:58 AM Monday, November 26, 2007

11:56 AM Monday, December 10, 2007

(SJ-T440R, SJ-T480R)

Jégkockakészítő tálca

SJ-CT440R, SJ-CT480R

SJ-T440R, SJ-CT440R Monday, November 26, 2007

11:56 AM Monday, November 26, 2007

11:56 AM Monday, November 26, 2007

11:51 AM Thursday, December 6, 2007

4:15 PM SJ-CT440R, SJ-CT480R

(SJ-T440R, SJ-T480R)

Monday, November 26, 2007

11:51 AM Monday, November 26, 2007

11:51 AM Monday, November 26, 2007

11:47 AM INSTALACE BEZPEČNOSTNÍ POKYNY

Thursday, December 6, 2007

(SJ-T440R, SJ-T480R)

SJ-CT440R, SJ-CT480R

SJ-T440R, SJ-CT440R SJ-CT480R)

Monday, November 26, 2007

11:47 AM Monday, November 26, 2007

11:47 AM Monday, November 26, 2007

11:42 AM Thursday, December 6, 2007

(SJ-T440R, SJ-T480R)

SJ-CT440R, SJ-CT480R Monday, November 26, 2007

11:42 AM Monday, November 26, 2007

11:42 AM Monday, November 26, 2007

2:17 PM Monday, December 10, 2007

SJ-CT440R, SJ-CT480R

(Tik SJ-T440R, SJ-T480R)

Temperatūros reguliavimas

Monday, November 26, 2007

2:17 PM Monday, November 26, 2007

2:17 PM Thursday, December 6, 2007

5:08 PM Thursday, December 6, 2007

(SJ-T440R, SJ-T480R)

SJ-CT440R, SJ-CT480R Monday, November 26, 2007

11:37 AM Monday, November 26, 2007

11:37 AM Monday, November 26, 2007

11:33 AM Tuesday, December 18, 2007

SJ-CT440R, SJ-CT480R

SJ-T440R, SJ-CT440R Monday, November 26, 2007

11:33 AM Monday, November 26, 2007

11:33 AM Monday, November 26, 2007

11:29 AM Monday, December 10, 2007

(SJ-T440R, SJ-T480R)

SJ-CT440R, SJ-CT480R

SJ-T440R, SJ-CT440R Monday, November 26, 2007

11:29 AM Monday, November 26, 2007

11:29 AM Monday, November 26, 2007

11:24 AM Thursday, December 6, 2007

SJ-CT440R, SJ-CT480R

SJ-T440R, SJ-CT440R Monday, November 26, 2007

11:24 AM Monday, November 26, 2007

11:24 AM Monday, November 26, 2007

12:04 PM Monday, December 10, 2007

(SJ-T440R, SJ-T480R)

SJ-CT440R, SJ-CT480R

(Само за SJ-T440R, SJ-T480R)

Monday, November 26, 2007

12:04 PM Monday, November 26, 2007

12:04 PM It is recommended that the inner parts e.g. shelves should be placed at the position as purchased in order to keep the high energy efficiency.

(Refer to the chapter of DESCRIPTION㧕

The position of the inner parts

عKeep the ventilation space as much as possible around the refrigerator.

عKeep your refrigerator out of direct sunlight, and do not place next to heat generating appliance. عOpen your refrigerator door as briefly as possible. عHot foods should be cooled before storing. عPlace the food evenly on the shelves to allow the cooling air to circulate efficiently.

Tips for saving energy

Monday, December 10, 2007

2:32 PM SHARP CORPORATION SHARP ELECTRONICS (EUROPE) GMBH.

Sonninstrasse 3, 20097 Hamburg Federal Republic of Germany
