USER MANUAL SP-M6 Auray

Desktop Studio Monitor Stand with Angle Adjust

Owner's Manual

Black industrial brake pedal with 'guray' and 'SP-S5' branding, no visible text or symbols on the device itself.

Thank you for choosing Auray.

Auray's Desktop Studio Monitor Stands with Angle Adjust are the ideal way to isolate your studio monitors on your desk and position them for better sound. Angle your studio monitors upward or downward with angle degrees of 5°, 10°, 13°, and 15°. This allows you to customize your setup for the best listening experience. Rubber pads and feet help to isolate your monitor's sound and minimize rumble and vibrations, as well as keep the stand and monitor in place. Solid metal construction provides a monitor base that will last through many recording sessions.

Precautions

• Please read and follow these instructions, and keep this manual in a safe place.
• Handle the unit with care.
  This unit includes moving parts and could cause injury.
• Do not attempt to disassemble or repair the equipment—doing so will void the warranty, and Auray will not be responsible for any damages.
  • Use only parts provided by the manufacturer.
• Clean the unit with a soft dry cloth.
• Make sure this product is intact and that there are no missing parts.
• Keep this unit away from children.
• All images are for illustrative purposes only.

Instructions

Monitor Angle Positions

1. Lift the plate and gently align the crossbar with the desired angle slot.

2. Gently press down until the crossbar is secure.

3D model of a mechanical device with multiple views and mounting brackets, shown from close-up to detailed detail (no text or symbols visible)

15^ 13^ 10^ 5^

Instructions (cont.)

Collapsing the Stand

Warning: Be careful with your fingers when collapsing the stand.

Lift the plate and push the crossbar toward the front slot. Gently collapse the stand until flat.

Black plastic chair with adjustable armrest and seat, showing a rotation arrow (no text or symbols)

Specifications

Material: Aluminum, steel, and rubber

Angle Adjustment: 5^ , 10^ , 13^ , and 15^

Mounts: SP-S5: 16 lb. (7.25 kg)

SP-M6: 22 lb. (10 kg)

SP-L8: 34 lb. (15.4 kg)

Dimensions (H × W × D):

SP-S5: 2 × 7 × 11.3 in. (5.1 × 17.75 × 28.7 cm)

SP-M6: 2 × 10.7 × 13.4 in. (5.1 × 27.2 × 34 cm)

SP-L8: 2 × 11.3 × 15.7 in. (5.1 × 28.7 × 39.9 cm)

Weight: SP-S5: 2.24 lb. (1 kg)

SP-M6: 3.2 lb. (1.45 kg)

SP-L8: 4 lb. (1.8 kg)

One-Year Limited Warranty

This AURAY product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. The warranty provider's responsibility with respect to this limited warranty shall be limited solely to repair or replacement, at the provider's discretion, of any product that fails during normal use of this product in its intended manner and in its intended environment. Inoperability of the product or part(s) shall be determined by the warranty provider. If the product has been discontinued, the warranty provider reserves the right to replace it with a model of equivalent quality and function.

This warranty does not cover damage or defect caused by misuse, neglect, accident, alteration, abuse, improper installation or maintenance. EXCEPT AS PROVIDED HEREIN, THE WARRANTY PROVIDER MAKES NEITHER ANY EXPRESS WARRANTIES NOR ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. This warranty provides you with specific legal rights, and you may also have additional rights that vary from state to state.

To obtain warranty coverage, contact the Auray Customer Service Department to obtain a return merchandise authorization (“RMA”) number, and return the defective product to Auray along with the RMA number and proof of purchase. Shipment of the defective product is at the purchaser’s own risk and expense.

For more information or to arrange service, visit aurayaudio.com or call Customer Service at 212-594-2353.

Product warranty provided by the Gradus Group. www.gradusgroup.com

AURAY is a registered trademark of the Gradus Group. © 2023 Gradus Group LLC. All Rights Reserved.

AURAY® A Gradus Group Brand
