EN-EL21 - Battery Watson - Free user manual and instructions

Brand	Watson
Model	EN-EL21
Product Type	Li-ion Battery Pack
Compatible Devices	Camcorders and digital cameras (Nikon EN-EL21 compatible)
Voltage	7.2V
Capacity	1020mAh
Dimensions (approx.)	36 x 57 x 21 mm
Weight (approx.)	50 g
Rechargeable	Yes, rechargeable via camcorder/camera
Operating Temperature	15°F (-10°C) to 105°F (40°C)
Storage Temperature	59°F (15°C) recommended
Self-Resetting Fuse	Yes (internal protection)
Warranty	1 year limited warranty
Maintenance	Clean with soft dry cloth; store at 40% charge for extended periods
Safety Features	Do not short circuit, disassemble, expose to moisture or fire
Country of Origin	China (assumed)

Frequently Asked Questions - EN-EL21 Watson

How do I charge the Watson EN-EL21 battery?

Charge the battery pack before use. Refer to your camcorder or digital camera manual for specific charging instructions.

What is the operating temperature range for this battery?

The battery should be used between 15°F (-10°C) and 105°F (40°C). Using it outside this range may activate a safety circuit.

Can I store the battery in a refrigerator?

Yes, you may store the battery in a refrigerator, but do not store it in a freezer. The ideal storage temperature is 59°F (15°C).

What is the best charge level for long-term storage?

For extended storage, keep the battery at approximately 40% charge. Neither fully charged nor fully discharged is recommended.

Why does the battery feel warm during use or charging?

It is normal for the battery to become warm during use or recharging. This is not a defect.

What should I do if the battery gets wet?

Do not expose the battery to rain or moisture. If it gets wet, dry it with a soft cloth and avoid using until completely dry.

Is the battery protected against short circuits?

Yes, the battery has an internal self-resetting fuse. However, short circuits may still cause severe damage, so avoid shorting the terminals.

How long does the battery last per charge?

Running time depends on power demand. Manufacturer run times are based on non-stop recording; real-life use (zoom, autofocus, etc.) will shorten runtime.

Can I dispose of the battery in regular trash?

No. Do not incinerate or dispose of in fire. Recycle Li-ion batteries according to local regulations.

What does the warranty cover?

The one-year limited warranty covers defects in materials and workmanship under normal consumer use. It does not cover misuse or damage. Contact Watson for an RMA number to return defective products.

USER MANUAL EN-EL21 Watson

Please read before using this equipment.

Blue 3D-rendered object resembling a folded or layered object against a gradient background (no text or symbols)

Abstract geometric pattern with yellow and white shapes (no text or symbols)

Thank you for purchasing the Watson Li-ion Battery Pack.

Browse through this manual for information and useful tips on how to use your new equipment.

SAFETY INSTRUCTIONS:

- Charge the battery pack before use. Read your camcorder or digital camera manual for charging instructions.

- When not in use, remove the battery pack from its device and store in a cool, dry place.

- Do not short circuit the terminals. This battery is protected with an internal self-resetting fuse, but short circuits may still cause severe damage to the battery. Be careful where you set the battery down.

• Under no circumstance attempt to open the battery case.
- Do not expose the battery to rain or moisture.

- Keep away from fire. Do not incinerate. Battery may explode in the presence of fire.

- Do not drop battery or expose it to strong shocks.

- Do not use at temperatures below 15°F (-10°C) or above 105°F (40°C). Use of the battery at very high temperatures will activate a safety circuit, disallowing use.

- Running time depends on the power demanded. Stated manufacturer run times are developed in simple laboratory tests of non-stop recording. Real-life use of zoom, automatic focus, tape review, etc., all demand extra power and shorten run time.

TO MAXIMIZE BATTERY PERFORMANCE

• Make sure the battery is fully charged before use.
- Clean the battery and terminals with a clean, soft, dry cloth.
• The battery may be warm during use on recharging. This is normal.
- When storing the battery for an extended period, be sure that it is not completely charged, nor completely discharged.

The ideal level is a 40% charge. This is approximate; the closer the battery is to this level, the better it will hold its charge during storage. The battery should be stored in a cool, dry place. The recommended temperature for storage is 59°F (15°C). You may store a battery in a refrigerator. Do not store batteries in a freezer.

- Remove the battery from your equipment when not in use. Some electronic equipment will draw current even when the switch is off.

- When operation time has noticeably shortened, the battery may need to be replaced.

ONE-YEAR LIMITED WARRANTY

This Watson product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. The warranty provider's responsibility with respect to this limited warranty shall be limited solely to repair or replacement, at the provider's discretion, of any product that fails during normal use of this product in its intended manner and in its intended environment. Inoperability of the product or part(s) shall be determined by the warranty provider. If the product has been discontinued, the warranty provider reserves the right to replace it with a model of equivalent quality and function. This warranty does not cover damage or defect caused by misuse, neglect, accident, alteration, abuse, improper installation or maintenance. EXCEPT AS PROVIDED HEREIN, THE WARRANTY PROVIDER MAKES NEITHER ANY EXPRESS WARRANTIES NOR ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. This warranty provides you with specific legal rights, and you may also have additional rights that vary from state to state. To obtain warranty coverage, contact the Watson Customer Service Department to obtain a return merchandise authorization ("RMA") number, and return the defective product to Watson along with the RMA number and proof of purchase. Shipment of the defective product is at the purchaser's own risk and expense.

For more information or to arrange service, visit www.poweredbywatson.com or call Customer Service at 212-594-2353.

WATSON™ A Gradus Group Brand

Product warranty provided by the Gradus Group. Watson is a registered trademark of the Gradus Group. © 2016 Gradus Group LLC. All Rights Reserved.

WATSON

www.poweredbywatson.com
