Product Type	Washing Machine
Brand	Tricity Bendix
Model	FD852A
Loading Type	Front Load
Dimensions (H x W x D)	85 cm x 60 cm x 55 cm
Net Weight	70 kg
Energy Efficiency Class	C
Rated Capacity	8 kg
Maximum Spin Speed	1200 rpm
Water Consumption per Cycle	50 L
Annual Energy Consumption	220 kWh
Noise Level (Wash)	56 dB(A)
Noise Level (Spin)	76 dB(A)
Number of Programs	15
Delay Start	Yes, up to 24 hours
Display Type	LED
Child Lock	Yes
Quick Wash	Yes
High Temperature Wash	Yes, up to 90°C
Warranty	2 years

Frequently Asked Questions - FD852A Tricity Bendix

How do I start a wash cycle on the Tricity Bendix FD852A?

Load the laundry, add detergent, select the desired program using the program dial, and press the Start/Pause button. The machine will begin the cycle.

What should I do if the machine does not drain?

Check the drain hose for kinks, clean the drain filter located at the bottom front, and ensure the pump is not blocked. Refer to the manual for filter cleaning steps.

How can I clean the detergent drawer?

Remove the drawer by pressing the release lever, wash it under warm water with a soft brush, and dry it before reinserting. Do not put it in the dishwasher.

What is the maximum spin speed of this model?

The maximum spin speed is 1200 rpm. You can adjust it depending on the fabric type.

How do I use the delay start feature?

Select the desired program, then press the Delay Start button repeatedly to set the delay in increments (e.g., 1-24 hours). The machine will start automatically after the set time.

What is the capacity of the Tricity Bendix FD852A?

The rated capacity is 8 kg for cotton and other standard fabrics. Do not overload to ensure efficient washing.

How do I activate the child lock?

Press and hold the Child Lock button (usually marked with a padlock) for 3 seconds until the indicator lights up. To deactivate, press and hold again.

What does error code E20 mean?

Error code E20 indicates a drainage problem. Check the drain hose and filter for blockages, and ensure the drain pump is functioning.

Can I use liquid detergent?

Yes, you can use liquid detergent. Pour it into the detergent drawer in the appropriate compartment. For best results, use the dosing guide.

How do I clean the drum?

Run a drum cleaning or maintenance wash cycle with an empty drum, using a washing machine cleaner or a cup of white vinegar at a high temperature (90°C).

USER MANUAL FD852A Tricity Bendix

Tricity Bendix, 55-77 High Street, Slough, Berkshire SL1 1DZ

Consumer care telephone number.....08705 950950

TRICITY BENDIX

FRIDGE-FREEZER

FD 852 A

© Electrolux Household Appliances Limited 2001

From the Electrolux Group. The world's No. 1 choice.

The Electrolux Group is the world's largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chair saves and lawn mowers) are sold each year to a value of approximately USD 14 billion in more than 150 countries around the world.

2222 076-73

IMPORTANT SAFETY INFORMATION

It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is left with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant safety information.

This information has been provided in the interest of safety. You MUST read it carefully before installing or using the appliance.

Installation

• This appliance is heavy. Care should be taken when moving it.
• It is dangerous to alter the specifications or attempt to modify this product in any way.
• Care must be taken to ensure that the appliance does not stand on the electrical supply cable. If the supply cord is damaged, it must be replaced by a special cable available from your local Service Force Centre.
• Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person.
• Parts which heat up should not be exposed. Whenever possible, the back of the appliance should be close to a wall but leaving the required distance for ventilation as stated in the installation instructions.
  • The appliance should be left for 2 hours after installation before it is turned on, in order to allow the refrigerant to settle.

Child Safety

• Do not allow children to tamper with the controls or play with the product.
• Keep all packaging well away from children.

During Use

• This appliance is designed for domestic use only, specifically for the storage of edible foodstuffs only.
• Frozen food must NOT be re-frozen once it has thawed out.
• Do not place carbonated or fizzy drinks in the freezer.
• Do not remove items from the freezer if your hands are damp/wet, as this could cause skin abrasions or frost/freezer burns.

• Ice lollies can cause 'frost/freezer burns' if consumed straight from the freezer.

• Manufacturers' storage recommendations should be strictly adhered to. Refer to relevant instructions.
  • The cooling plate or refrigerated freezer shelves in this appliance contain channels through which the refrigerant passes. If these are punctured this will cause substantial damage to the appliance and result in food loss. DO NOT USE SHARP INSTRUMENTS to scrape off frost or ice. Under NO circumstances should solid ice be forced off the lining or shelves. Solid ice should be allowed to thaw, when defrosting the appliance. See Defrost Instructions.

Maintenance and Cleaning

- Switch off and unplug the appliance before carrying out any cleaning or maintenance work.

Servicing

• This product should be serviced by an authorised engineer and only genuine spare parts should be used.
  • Under no circumstances should you attempt to repair the machine yourself. Repairs carried out by inexperienced persons may cause injury or serious malfunctioning. Refer to your local Service Force Centre and always insist on genuine spare parts.

At the end of the Appliance Life

• When disposing of your appliance, use an authorised disposal site.
• Remove the plug and ensure that any locks or catches are removed, to prevent young children being trapped inside.

Door reversal directions

1. Disconnect from the electricity supply.
2. Remove all loose items, including food, store food in a cool place.
3. Remove the ventilation grill (D).
4. Unscrew the bottom hinge (E).
5. Remove the freezer door by releasing it from the middle hinge (H).
6. Unscrew the middle hinge.
7. Slide out the fridge door from pin (G), unscrew the latter and then screw it down into the hinge provided on the opposite side, after having removed the small plugs which should then be fitted on the opposite side.
8. Refit the fridge door and replace the middle hinge to the left hand side.
9. Replace the door and bottom hinge (E) on the opposite side.
10. Remove the plug (F) from the ventilation grill (D) and replace it on the opposite side. Re-assemble the ventilation grill (D).

The doors can be aligned by adjusting the middle hinge, with help of a tool, after having slackened the two screws.

After having reversed the opening direction of the doors check that all the screws are properly tightened and that the magnetic seal adheres to the cabinet.

Attention

After completion of the door reversing operation, check that the door gasket adheres to the cabinet. If the ambient temperature is cold (i.e. in Winter), the gasket may not fit perfectly to the cabinet. In that case, wait for the natural fitting of the gasket or accelerate this process by heating up the part involved with a normal hairdryer on a low setting.

Printed on recycled paper

Electrical connections

Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person.

WARNING: THIS APPLIANCE MUST BE EARTHED.

The manufacturer declines any liability should this safety measure not be observed.

If the plug that is fitted to your appliance is not suitable for your socket outlet, it must be cut off and the appropriate plug fitted.

Remove the fuse from the cut off plug.

The cut off plug should then be disposed of to prevent the hazard of shocks in case it should be plugged into a 13amp socket in another part of your home.

Important

The wires in the mains lead are coloured in accordance with the following code:

Green and Yellow - Earth Blue - Neutral

Brown

- Live

If you fit your own plug, the colours of the wires in the mains lead of your appliance may not correspond with the markings identifying the terminals in your plug, proceed as follows:

Connect the Green and Yellow (earth) wire to the terminal in the plug which is marked with the letter «E» or the earth symbol ⊖ or coloured green and yellow.

Connect the blue (neutral) wire to the terminal in the plug which is marked with the letter «N» or coloured black.

Connect the brown (live) wire to the terminal in the plug which is marked with the letter «L.» or coloured red.

The plug moulded onto the lead incorporates a fuse. For replacement, use a 13amp BSI362 fuse. Only ASTA or BSI approved fuses should be used.

The plug must not be used if the fuse cover/carrier is lost. The cover/carrier is indicated by the coloured insert at the base of the plug.

A replacement cover/carrier must be obtained from your local Tricity Bendix Service Force Centre.

This appliance complies with the E.E.C. Directive No. 87/308 of 2.6.87 relative to radio interference suppression.

CE This appliance complies with the following E.E.C. Directives:

- 73/23 EEC of 19.2.73 (Low Voltage Directive) and subsequent modifications;

- 89/336 EEC of 3.5.89 (Electromagnetic Compatibility Directive) and subsequent modifications.

Please ensure that when the appliance is installed it is easily accessible for the engineer in the event of a breakdown.

CONTENTS

Instructions for the User

Important Safety Information 2

Description of the Appliance 4

Operation 5

Before use 5

Setting the temperature 5

The freezer compartment 5

Freezing fresh food 5

Thawing 5

Making Ice cubes 5

Fresh food refrigeration 6

Normal operating sounds 6

Movable shelves 7

Positioning the door shelves 7

Freezing Calendar 7

Health and Safety Guidelines 8

Maintenance and Cleaning 9

Internal cleaning 9

External cleaning 9

When the appliance is not in use 9

Changing the light bulb 9

Defrosting 9

Something Not Working

Service and Spare Parts 12

Customer Care

Guarantee Conditions 1

Instructions for the Installer

Technical Specification 16

Installation 17

Positioning 17

Rear spacers 17

Electrical Connection 18

Door Reversal 19

DESCRIPTION OF THE APPLIANCE

A - Thermostat control for both compartments
B - Dairy compartment (for dairy products to prevent taining)
C - Can storage shelf
D - Movable shelf
E - Bottle storage shelf
F - Compartment for freezing fresh food
G - Compartment for frozen food storage
H - Salad crisper (to keep fruit and vegetables fresh)
I - Glass shelf
J- Cooked foods storage shelves

INSTALLATION

Warning

IF YOU ARE DISCARDING AN OLD APPLIANCE THAT HAS A LOCK OR CATCH ON THE DOOR, YOU MUST ENSURE THAT IT IS MADE UNUSABLE TO PREVENT YOUNG CHILDREN BEING TRAPPED INSIDE.

Depending upon the position which you choose for your appliance, you may wish to reverse the way in which the door opens. To do this, refer to instructions on "Door reversal directions" paragraph.

Positioning

This appliance is designed to operate in ambient temperatures between 10°C (50°F) and 32°C (90°F). It should be located in a dry atmosphere, out of direct sunlight and away from extreme temperature e.g. not next to a boiler or radiator, or in a very cold room e.g. an outhouse, where the temperatures may fall below 10°C (50°F). If these temperatures are exceeded i.e. colder or warmer, then the appliance may not operate correctly.

You should also ensure that air can circulate freely around the back and the top of the cabinet. There must also be at least 100 mm (4") distance between the top of the cabinet and any overhanging kitchen furniture (A). Ideally, the appliance should not be positioned beneath overhanging furniture (B).

There should also be a gap of 25 mm either side of the appliance. Do not obstruct the space underneath. The back of the cabinet may be placed close to the wall but must not touch it. DO NOT install in places with restricted ventilation.

Adjust the level of the appliance by screwing out the adjustable fool, or feet, at the bottom of the cabinet using your fingers.

Rear spacers

In the bag with the documentation there are two spacers which must be fitted in the two top corners.

Slacken the screws and insert the spacer under the screw head, then re-tighten the screw.

TECHNICAL SPECIFICATIONS

DIMENSIONS
	Height 150 cm
	Width 55 cm
	Depth 60 cm
POWER SUPPLY VOLTAGE AND FREQUENCY 220-240 V / 50 Hz
TOTAL POWER ABSORBED 130 w
AVERAGE DAILY UNITS ELECTRICITY * 1.30 kWh
GROSS CAPACITY
	Fridge	174	I
	Freezer 76 I
NET CAPACITY
	Fridge	170	I
	Freezer 60 I
STAR RATING		###

* This figure is based on standard test results in accordance with European Standard EN 153. Actual consumption will depend on how the appliance is used and where it is located.

OPERATION

Before using

Remove all securing tapes. Wash inside the appliance with lukewarm water and bicarbonate of soda (5 ml to 0.5 litre of water).

Do not use soap or detergent as the smell may linger. Dry thoroughly.

Setting the temperature

The temperature inside the refrigerator is regulated by a thermostat with 6 temperature positions and an "OFF" (O) position.

Position 1 = minimum coldness

Position 6 = maximum coldness

Turn the thermostat dial to the required position.

The Intermediate position is usually the most suitable (3-4).

The thermostat setting can vary as the temperature inside the refrigeration compartment depends on the following factors:

- room temperature

- how often the door is opened

- how much food is stored

- position of the appliance

Important

During prolonged periods of abnormally hot weather, if the thermostat is set on too high a number, the cooling system may operate continuously and the fridge cooling plate may not defrost. Turning the knob to a lower number will cause the automatic defrosting to resume.

The freezer compartment

The four-star freezer compartment is suitable for storage of commercially frozen food and for freezing fresh foods.

Freezing fresh food

It is not necessary to adjust the thermostat setting when freezing fresh food.

In any 24 hours you can freeze up to 3 kg. of fresh food.

Place food to be frozen in the bottom drawer of the freezer as this is the coldest part.

Important

In the event of a power cut do not open the door. The food in the freezer will not be affected if the power cut is short and if the freezer is full. Should the food begin to thaw, it must be consumed quickly and must not be re-frozen.

Thawing

Frozen food, prior to being used, can be thawed in the fridge or at room temperature depending on the time available. Small food items may even be cooked from frozen; in this case cooking will take longer.

Any frozen food which is allowed to thaw accidentally should either be eaten as soon as possible or thrown away. Alternatively, if the food is uncooked and has not been completely defrosted it can be cooked and then retrozen.

Meat, fish and fruit should be thawed in the refrigerator compartment and small pieces of meat can even be cooked while still frozen, but you must ensure that it is thoroughly cooked through.

Vegetables should be directly immersed in boiling water; ready-cooked dishes can be placed directly in the oven in their aluminium wrapping.

A microwave oven is particularly suitable for thawing any type of frozen or deep-frozen food: follow the oven instructions, particularly regarding the placement of aluminium wrapping or containers in the oven.

Defrosted cooked food must never be refrozen.

Making ice cubes

The appliance is provided with one or more trays for ice-cubes trays.

Fill the tray(s) 3/4 full to give the ice space to expand and place them in the freezer compartment.

To release the ice cubes simply give the tray a slight twist.

Do not use sharp or metallic instruments to remove the trays from the freezer.

Fresh food refrigeration

To obtain the best performance, do not store warm food or evaporating liquids in the refrigerator; do cover or wrap the food, particularly if it has a strong flavour.

Do not cover the shelves with any protective material, such as paper, cardboard or plastic, which may obstruct the air circulation through them.

To help you use your refrigerator correctly, here are some more useful hints:

Raw meat (beef, pork, lamb & wild fowl): wrap in polythene bags and place on top of the salad crispers.

Meat can only be stored safely in this way for one or two days at the most.

Fruit & vegetables: these should be thoroughly cleaned and placed in the bottom salad crispers.

Butter & cheese: these should be placed in special airlight containers or wrapped in aluminium foil or polythene bags to exclude as much air as possible.

Milk bottles: these should have a cap and should be stored in the bottle rack on the door.

Normal Operating Sounds

• You may hear faint gurgling or bubbling sounds when the refrigerant is pumped through the coils or tubing at the rear, to the cooling plate/evaporator or to the fixed freezer shelves.
• When the compressor is on, the refrigerant is being pumped round, and you will hear a whirring sound or pulsating noise from the compressor.
• A thermostat controls the compressor, and you will hear a faint 'click' when the thermostat cuts in and out.

GUARANTEE CONDITIONS

Standard guarantee conditions

We, Tricity Bendix, undertake that if within 12 months of the date of the purchase this Tricity Bendix appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that:

The appliance has been correctly installed and used only on the electricity supply stated on the rating plate.

The appliance has been used for normal domestic purposes only, and in accordance with the manufacturer's instructions.

The appliance has not been serviced, maintained, repaired, taken apart or tampered with by any person not authorised by us.

All service work under this guarantee must be undertaken by a Tricity Bendix Service Force Centre. Any appliance or defective part replaced shall become the Company's property.

This guarantee is in addition to your statutory and other legal rights.

Home visits are made between 8.30am and 5.30pm Monday to Friday. Visits may be available outside these hours in which case a premium will be charged.

Exclusions

This guarantee does not cover:

Damage or calls resulting from transportation, improper use or neglect, the replacement of any light bulbs or removable parts of glass or plastic.

Costs Incurred for calls to put right an appliance which is Improperly Installed or calls to appliances outside the European Community (EC) or European Free Trade Area.

Appliances found to be in use within a commercial environment, plus those which are subject to rental agreements.

Products of Tricity Bendix manufacture which are not marketed by Tricity Bendix.

European Guarantee

The standard one year guarantee is for the same period and the same extent for labour and parts as exists in the new country of use for this brand or range of products.

Customer Care Centre:

Ireland

Dublin

353-1-4090752

If you should move to another country within Europe then your guarantee moves with you to your new home subject to the following qualifications:

The guarantee starts from the date you first purchased your product.

The guarantee is for the same period and to the same extent for labour and parts as exists in the new country of use for this brand or range of products.

This guarantee relates to you and cannot be transferred to another user.

Your new home is within the European Community (EC) or European Free Trade Area.

The product is installed and used in accordance with our instructions and is only used domestically, i.e. a normal household.

The product is installed taking into account regulations in your new country.

Before you move please contact your nearest Customer Care centre, listed below, to give them details of your new home. They will then ensure that the local Service Organisation is aware of your move and able to look after you and your appliances.

France Senlis [phone]

Germany Nürnberg [phone]

Italy Pordenone [phone]

Sweden Stockholm [phone]

UK Slough [phone]

SERVICEFORCE

To contact your local Service Centre telephone [phone]

MIDLANDS		LONDON & EAST ANGLIA		SOUTH EAST
DIMINGHAM	03 Strch Road EastWorley Trading EstateWhittonBirminghamBy 1DB	BECKENHAM	1st Gardner Ind. EstateKent House LaneBeckinghamKent 3BP 102	ASHFORD	Unit 2Bridge Road Business CentreBridge RoadAsburyKent 1403 1BB
DOORNE	Perfoid RoadBournoPE 10 8HT	CHELMERFORD	Hornbury RoadWolford Inst. EstateChelmsfordEssexOM12 3AE	FLEET	Unit 1Rathbridge Inst. EstateChurch CreekhamFleetHartspire, GU13 9BD
REDONORTH	6 St. Mary's StreetBridgworthShropshireWVE 4DR	COLNOXALE	Unit 14Capitol ParkCapitol WayColinoleLondon NWS 5EQ	KEYWARDSHEATH	21-25 Bridge RoadPlayoverha HealthSundance RH12 10A
OLDGESTER	101 Ryochoh StreetGloucesterGU 14RB	FLTHAM	194 Court RoadMcGlenburnEthanumLondon 3EF 4EW	TOWRIDGE	Unit 10Pracon Tlading EstateMowry RoadTurnbridgeTN9 19A
HERSTORI	Under 2 & 4Bank BuildingsCattle marketHarfordHge 3PLR	EMFIELD	264 Alma RoadEnfieldLondonEN3 7BD
HONWATERKERS	10 High StreetHigham ForestNorthamptonNH13 3PL	CHAVESEND	Unit B4Imperial Business EstateWest RdGravensandKentSD11 6OL
LEDESTON	Unit 2Funrise RoadHouston DE1 SEP			BARNSTATE	Main RoadFreemingtonSamtsbpsNorth Haven E631 2NT
LEDESTER	Unit 7Oaks Industrial EstateCorning RoadNorthcolnLeCoastershireLES 1GP	IPSWICH	Unit 6CEllon Park Business CentreHadleigh RoadIsaedcnIP2 10D	BOURNEMOUTH	63-45 Curzon RoadSourismouthDurvalBH1 4PW
LINCOLN	Unit 3Citton StreetStone Field ParkLincolleLMS 8LO	LEITCHWORTH	16-17 Woodlods Inc. ParkWorks RoadLatchworthHillsSGS 1LA	SARDEWAYMER	6 Harwell Business ParkSolomon ParadeUrquasterSonnerent TA5 SPY
KONCASTLEUNDER LYG	18-21 Crash RoadBrenton Ind. EstateNewcastle under LynsStymporth toS15 3TW	LONDON	2 - 4 Royal LaneYersklyWest ClaytonMadrasasU87 8DL	BRISTO	11 Elloy WayEdgewall Trading EstateBristolBld 5QQ
NEUDOTCH	13 Thornhill RoadNorth Moors RoadReditchBloomstershireBS8 9ND	MADEHEAD	Reform RoadMalderheadBerkeleySL5 8BY
		MOLESEY	10 Island Park AvenueWest MolsleySurreyK18 2JZ		ISLE OF WIGHT Unit 3Enterprise CourtRute Business FairRydaAce of Wight PO31 12B
TANWORTH	Unit 3Starting ParkCitymoreTownworthB77 5DC	NEWBURY	7 Pijare CourtBerkeley DriveThutthamBerkeleyRG19 JER		NEWTON ABBOT Unit 2Zazuky Ind. EstateKingboroughNewton AbbotTD12 3T3
YUMBERSTER	Units 1 & 2Northbanks CloseGregory Mill Ind. EstateWarchesterWRS 8BP	NORWICH	20 Tufallape StreetNorwichNR1 3HN		RECRUTH Unit 10Pool Ind. EstateDivide RoadRedruthConway TR15 3RH
		SUNBURY	Unit 1aThe SummitHanworth RoadSumbury on ThamesTN16 6DR

Movable shelves

The walls of the refrigerator have runners so that shelves can be positioned as desired.

Positioning the door shelves

To permit storage of food packages of various sizes, the door shelves can be adjusted in height.

To do this proceed as shown in the diagram:

Gradually pull the shelf in the direction of the arrows until it comes free, then reposition as required.

Freezing Calendar

The symbols show different types of frozen goods.

The numbers indicate storage times in months for the appropriate types of frozen goods. Whether the upper or lower value of the indicated storage time is valid depends on the quality of the foods and pre-treating before freezing.

HEALTH AND SAFETY GUIDELINES

Because of consumer demand, preservatives have been removed from many pre-prepared foods. This together with the changes in shopping habits to a once-a-week shop, mean that safe handling and storage of food is even more important than ever.

The following tips should help you to ensure that the food in your home is in as perfect condition as possible.

• Keep the time between buying chilled food and placing it in your fridge as short as possible. Tests showed that the temperature of 1 litre of orange juice rose to 22°C in an hour between the supermarket and home. It then took 11 hours to get down to 7°C in the refrigerator.
• Keep the refrigerator door closed as much as possible.
• Do not push food together too much, try to allow air to circulate around each item.
• Cool cooked food as quickly as possible but do NOT place in the refrigerator until cool. (Leave food in a cool place in order that it can then be put in the refrigerator as soon as possible).
• Do NOT mix raw and cooked meat, they must be in separate containers. Take care not to let the meat juices drip onto other food. If the meat does drip, remove everything and clean thoroughly.
• Do not store food uncovered.
  • The best way to defrost food is to put it in the refrigerator to thaw slowly.
• Remove suspect food from your refrigerator and clean (refer to "Maintenance and Cleaning").
• Never allow spillages to dry and harden.
• Ensure that food placed in the freezer is dated and labelled and used in date order to ensure that food is consumed at its best.
• It is important that food is used before its "best before" date.
• Store eggs in the egg rack provided in the refrigerator door. Discard any broken or chipped eggs.
• Regularly check the refrigerator door seal to ensure that it is clean and free from debris.
  • Always wash your hands with soapy water and dry them with a clean towel before handling food.
• Keep work surfaces clean and avoid cross contamination by not using the same work surface or knife, without washing them thoroughly in between.
  • The fresh foods to be frozen must be fresh and of the best quality.

• The size of each pack should be small enough to ensure that it is used in one go. Small packs freeze more quickly and uniformly and give better results.
- Frozen food, once thawed, must not be refrozen. Lean food keeps better and longer than fatty food, salt reduces the storage time.
- Wrap the food in polythene or aluminium freezing bags or foil so that they adhere to the food and provide an airtight seal.
- Packaging which is swollen or has traces of refrozen water droplets on the pack could indicate that the product has not been kept at a suitable temperature and that it may have lost its original quality. Partially thawed food must not be refrozen, it must be consumed within 24 hours. Never exceed the storage times indicated.
- Never place hot food, bottles or cans of fizzy drink in the freezer as they may explode. Containers with a lid must not be filled to the brim.
- Do not open the door or place extra fresh food in the freezer next to food which is already frozen as this could cause the temperature of the frozen food to rise and its quality and storage life to reduce.

SERVICEFORCE

To contact your local Service Force Centre telephone [phone]

CHANNEL ISLANDS		ISLE OF LEAVES	NO Marched 16 James Street Stomney Sale of Lewis PAST 20W	NORTH EAST
OUVERNSEY	Guernsey Electricity PO Box 4 Vail, Guernsey Channel Islands GY1 34D	KELSO	2,5 & 8 Woodmarket Ketso Botties TDS TAX	GATESHEAD Unit 366 Dutresway Court Dutresway Dutreshead NE11 60H
JERSEY	Jersey Electricity Company Road De La Lorme Roa De Maui De Lorme Trinity Jersey Channel Islands JE3 5FG	ORKNEY	7 King Street Kirkwell Orkney KWHS 1/F	CRIMSBY Unit 12 Haiton Avenue Cranachy N. E. Lirico DK32 9AS
				HILL Unit 1 Bourovert Industrial Estate Hull HIL 8AXY
SCOTLAND		PORTH	Scottish Hydro Electric Central Warehouse Interlandm Path: PH1 3AF	LEEDS Unit 14 65 Cross Gate Road Dress Gate Leeds NE11 9TX
ARIFREN	54 Clamont Street Monitton AR19 6RA	OWN SALES	1-4 Carlton Place Lentwick Shelstand ZE1 4PW	NEBATON AYCUFFE Unit 23 Northfield Way Aptifila Industrial Park Newton Aysiliffe OL5 6EJ
AUGITERMOCHY	75 Boroniaire Auchinmethoty Fife KY14 TAJ	SHETLAND	Delta Shetland 26 North Road Lentwick Shelstand ZE1 6PE	SHETFIELD Potashie House Roman Ridge Road Sheffield 50 12R
BHINTLE	Unit 5 Block 2 Auchenworth Ind. Estate Rosendale Way Blamoya GT2 3BU	OWN SALES	Lewis Electrical Hansdale Symbolist, Whiskey Shelstand ZE1 9PE
DUERTICS	53 Iron Street Durham SG1 2 PG	WHOLEAY	NORTHERN IRELAND	NORTH WEST
DURON	7 Hill Street Sunton Angyl PA22 7AI	OWN SALES	Oshenkore House Khees Business Park Dunterry Boisea DT17 8HD	BRKENHEAD 1 Kalen Park Dock Road Bickwood CHH 1L*
EDMURGH	Unit 12 Dumaryden Ind. Estate 2 Dum dryden Road Edinburgh EH14 2AB	BELFAST	OWHTORIHO House Khees Business Park Dunterry Boisea DT17 8HD	CARLILE Unit B-T James Street Workshops James Street Castle Cumbria CA2 5AH
CLASCONY	Unit 4 Wellington Road Shimpongga Glasgow G64 2RA	CANOFT	WALES Unit 4 Guardian Industrial Estate Clademrul Road Canall CF1 2US	ISLE OF MAN South Quay Ind. Exicate Doyles Mills of Man MH 5AT
EVERNESS	Unit 201 Smithton Ind. Estate Smithton Avantense IV2 7WL			BOLTON Unit B Central Industrial Estate St Marks Street Bollon BL3 5NR
ISLE OF ARBIAN	Arrae Dynamics The Engages Centre Brook Bile of Arrain KA27 9A2	CLAWID	Unit 6-7 Crowd Pass Abargale Road Rhodston Chayal LL10 5UG	PRESTON Unit 250 Dawson Plaza Barnier Bridge Preston Lancashire PRS 6AL
ISLE OF BARBA	2 Zenith 34 Brasnish Iase of Barra Westam Islands HS9 5GY	BYFED	Unit 9 St. Clews Business Park Terby Road St. Clews Camathieu SA21 4XV	STOCKPORT Unit 20-High Parx High Avenue Stockport SK4 12K
ISLE OR BUTS	Walker Engineering Clembraer Upper Serenntine Road Rodrway Nile of Buta PA20 9DH	OSHESTRY	Plax Flynsone Warehouse Walderton Road Osserlity GY11 2PF

SERVICE AND SPARE PARTS

In the event of your appliance requiring service, or if you wish to purchase spare parts, please contact your local Tricity Bendix Service Force Centre by telephoning:-

0870 5 929929

Your telephone call will be automatically routed to the Service Force Centre covering your post code area. The addresses are listed on the following pages.

Before calling out an engineer, please ensure you have read the details under the heading 'Something Not Working?

When you contact the Service Force Centre you will need to give the following details:

1. Your name, address and post code
2. Your telephone number
3. Clear and concise details of the fault
4. The model and serial number of the appliance (found on the rating plate)
5. The purchase date

For service in the Republic of Ireland contact

Tricity Bendix

Long Mile Road

Dublin 12

Telephone : [phone]

CUSTOMER CARE DEPARTMENT

For general enquiries concerning your Tricity Bendix appliance or for further information on Tricity Bendix products, please contact our Customer Care Department by letter or telephone as follows:-

Customer Care Department

Tricity Bendix

55-77 High Street

Slough

Berkshire

SLI IDZ

08705 950 950 (*)

(*) calls to this number may be recorded for training purposes.

MAINTENANCE AND CLEANING

Before any maintenance or cleaning work is carried out, DISCONNECT the appliance from the ELECTRICITY supply.

Internal cleaning

Clean the inside and accessories with warm water and bicarbonate of soda (5ml to 0.5 litre of water). Rinse and dry thoroughly.

NEVER USE DETERGENTS, ABRASIVE POWDERS, HIGHLY PERFUMED CLEANING PRODUCTS OR WAX POLISHES, TO CLEAN THE INTERIOR AS THESE WILL DAMAGE THE SURFACE AND LEAVE A STRONG ODOUR.

External cleaning

Wash the outer cabinet with warm soapy water. Do NOT use abrasive products.

An accumulation of dust will affect the performance of the appliance and cause excessive electricity consumption.

You MUST ensure that the appliance is switched OFF.

Once or twice a year dust the condenser (black grill) and the compressor at the back of the appliance, with a brush or vacuum cleaner, see figure.

When the appliance is not in use

When the appliance is not in use for long periods, disconnect from the electricity supply, empty all foods and clean the appliance, leaving the doors ajar to prevent unpleasant smells.

Changing the light bulb

Should the interior light fall to work, first switch off the appliance and disconnect from the electricity supply, then replace the bulb as follows;

Unscrew the light cover and then pull it outward by pressing as shown in the figure. Unscrew the bulb and replace it with a new 15 watt bulb (available from your nearest Service Force Centre).

Replace the light cover by sliding it into its original position and replacing the screw.

Defrosting

Refrigerator

The refrigerator automatically defrosts every time the compressor stops. The water is discharged, via the pipe, into a tray located at the back of the appliance above the compressor, where it evaporates.

Important

To avoid defrost water overflowing into the fridge, periodically clean the water discharge hole in the centre of the V shaped drip collector at the back of the refrigerator compartment behind the fruit and vegetable drawer. Use the defrost cleaner provided which you will find already inserted into the discharge hole.

Remember to wash the defrost cleaner in hot soapy water at regular intervals. Dry throughly before replacing.

Freezer

When the frost has reached a thickness of up to 4mm it can be removed using the ice scraper provided with the appliance. During this operation it is not necessary to disconnect the appliance from the mains and remove the food. Never use metal tools for this operation.

For complete defrosting (once or twice a year) proceed as follows:

• turn the thermostat dial to the "OFF" position (O) or disconnect the appliance from the mains.
• Remove any food from inside the freezer and fridge, wrap it in several sheets of newspaper and store in a cool/dry place.

- Leave the door open and insert the ice scraper under the channel in the centre of the lower part of the appliance; place a low-sided container beneath the scraper to collect the water (see fig.).

- Clean and dry thoroughly.

- Replace the scraper in one of the drawers.

- Reconnect the appliance to the mains or reset the thermostat to a functioning position.

- After letting the appliance run for at least half an hour, replace the previously removed food into the compartment.

Important

When defrosting the freezer, the fridge is also controlled by the thermostat and will not be operational during this period. A temperature rise of the frozen food packs, during defrosting, may shorten their safe storage life.

Attention!

In the event of a power failure causing the temperature within your freezer to rise, do not re-freeze the food without checking its condition. The following guidelines should assist you.

Ice-cream: once thawed should be discarded. Fruits & Vegetables: If soft should be cooked and used up.

Breads & Cakes: can be re-frozen without danger. Shellfish: should be refrigerated and used up quickly.

Cooked Dishes: i.e. casseroles should be refrigerated and used up.

Large Pieces of Meat: can be re-frozen providing there are still ice crystals remaining within them. Small Joints: should be cooked and can then be re-frozen as cooked dishes. Chicken: should also be cooked and re-frozen as a cooked dish.

10

SOMETHING NOT WORKING

Important: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation a charge will be made, even if the appliance is under guarantee.

Before contacting your local Service Force Centre, check the following points:

Symptom	Solution
No power to the appliance	Check there is power at the socket.
	Check there is not a power cut by checking the household lights.
	Check the fuse has not blown.
The light does not come on	Ensure that the bulb is correctly fitted.
	Replace the bulb if it has blown.
	Check the door light switch is not jammed.
The temperature in the fridge or freezer section is too high	Check the temperature in the fridge is turned to the correct setting relative to ambient conditions.
	Check the ambient temperature is within the appliance's operating limits of 10^ to 32^ . Relocate the appliance if necessary.
The freezer door will not open	Has door just been opened? If so leave for a few minutes to allow the air pressure to equalise.
The compressor runs continuously	Adjust the thermostat control knob to give correct temperature control. See "Setting the temperature".
	Check that the doors are closed.
	Large quantities of food have recently been placed in the cabinet and/or door is frequently opened.
	Check that air ventilation is not obstructed.
Excessive frost and ice has built up	Ensure the doors are not left open.
	Check that nothing is preventing the doors from closing.
	Is the door gasket intact and clean.
	Has advised periodic defrosting been carried out.
Noise	Refer to normal operating sounds.
Water under the salad crisper	Check the drain hole is not blocked. (see Maintenance and Cleaning).
