U236-000-GBW - Network Card/Adapter Tripp Lite - Free user manual and instructions

Product Type	Network adapter
Brand	Tripp Lite
Model	U236-000-GBW
Interface	USB 2.0
Connector Type	RJ45 (female)
Data Transfer Rate	10/100/1000 Mbps
Supported Standards	IEEE 802.3, 802.3u, 802.3ab
Compatible Operating Systems	Windows, macOS, Linux
Chipset	ASIX AX88179
LED Indicators	Link/Activity
Cable Length	0.15 m (integrated USB cable)
Dimensions (W x D x H)	2.5 x 0.8 x 0.5 in (6.4 x 2.0 x 1.3 cm)
Weight	0.04 lb (18 g)
Power Source	Bus-powered via USB
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity Range	10% to 90% (non-condensing)
Color	Black
Warranty	3 years limited
Package Contents	USB to Ethernet adapter, quick start guide

Frequently Asked Questions - U236-000-GBW Tripp Lite

What is the Tripp Lite U236-000-GBW?

The Tripp Lite U236-000-GBW is a USB 2.0 to Gigabit Ethernet adapter that allows you to connect a computer with a USB port to a wired network at speeds up to 1000 Mbps.

Is the adapter compatible with my operating system?

Yes, it is compatible with Windows, macOS, and Linux operating systems. Drivers are typically installed automatically via Plug and Play.

What network speeds does it support?

It supports 10/100/1000 Mbps Ethernet speeds, auto-negotiating for the highest available connection.

Do I need to install drivers manually?

In most cases, no. The adapter uses the built-in driver of your operating system. For older systems, you may download drivers from the Tripp Lite website.

How do I install the adapter?

Simply plug the USB connector into an available USB 2.0 or 3.0 port on your computer, then connect an Ethernet cable to the RJ45 port. The adapter will be recognized automatically.

What does the LED indicator mean?

The LED indicates link and activity: solid green means a valid link, flashing means data activity. No light indicates no connection.

Does the adapter support Power over Ethernet (PoE)?

No, the adapter is not PoE-compatible. It is bus-powered from the USB port and does not supply power to the network cable.

What is the warranty period?

Tripp Lite offers a 3-year limited warranty against defects in materials and workmanship.

Can I use this adapter with a USB 3.0 port?

Yes, it is backward compatible with USB 3.0 ports, but the transfer speed will be limited to USB 2.0 (480 Mbps). The Ethernet speed is unaffected.

What is included in the package?

The package includes the USB to Ethernet adapter and a quick start guide. No external power supply is needed.

USER MANUAL U236-000-GBW Tripp Lite

USB 2.0 10/100/1000 Gigabit Ethernet Adapter

Model: U236-000-GBW (White)

USB 3.0 10/100/1000 Gigabit Ethernet Adapter

Models: U336-000-GBW (White) and U336-000-R (Black)

Register your product for quicker service and ultimate peace of mind. You could also win an ISOBAR6ULTRA surge protector—a \$100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

Copyright © 2017 Tripp Lite. All rights reserved.

Product Features

• U236-000-R ensures true 10/100 Mbps network speeds
• U236-000-GBW supports Gigabit networks at speeds up to 480 Mbps
- U336-000-R and U336-000-GBW ensure true 10/100/1000 Mbps network speeds
• Compliant with IEEE 802.3, 802.3u, and 802.3ab standards
- IEEE 802.3az (Energy Efficient Ethernet) compliant
- Supports full-duplex with IEEE 802.3x flow control and half-duplex with back-pressure flow control
• Supports IPv4 and IPv6 pack Checksum Offload Engine (COE) to reduce CPU loading
- Suspend mode and remote wakeup supported via link-change, Magic Packet, Microsoft® Wakeup Frame and external wakeup pin
• Supports Wake-on-LAN

System Requirements

• An available USB port
- Compatible with Windows®, Mac® and Linux®

Package Contents

• USB Ethernet Adapter
• Quick Start Guide

Installation

1. Plug the USB connector on the adapter into an available USB port on your computer. Upon connecting the adapter to your computer, the device will begin installing.
2. Wait for the installation process to reach completion. You may need to restart your computer.
3. Connect the Ethernet port on the adapter to your LAN port using a Cat5e/6 cable.

Warranty and Product Registration

3-Year Limited Warranty

TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of three (3) years from the date of initial purchase. TRIPP LITE's obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. To obtain service under this warranty, you must obtain a Returned Material Authorization (RMA) number from TRIPP LITE or an authorized TRIPP LITE service center. Products must be returned to TRIPP LITE or an authorized TRIPP LITE service center with transportation charges prepaid and must be accompanied by a brief description of the problem encountered and proof of date and place of purchase. This warranty does not apply to equipment, which has been damaged by accident, negligence or misapplication or has been altered or modified in any way.

EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, TRIPP LITE is not liable for any costs, such as lost profits or revenue, loss of equipment, loss of use of equipment, loss of software, loss of data, costs of substitutes, claims by third parties, or otherwise.

Warranty and Product Registration

PRODUCT REGISTRATION

Visit www.triplite.com/warranty today to register your new Tripp Lite product. You'll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*

* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

FCC Notice, Class B

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

Any changes or modifications to this equipment not expressly approved by Tripp Lite could void the user's authority to operate this equipment.

Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life support equipment or to significantly affect its safety or effectiveness is not recommended.

WEEE Compliance Information for Tripp Lite Customers and Recyclers (European Union)

Under the Waste Electrical and Electronic Equipment (WEEE) Directive and implementing regulations, when customers buy new electrical and electronic equipment from Tripp Lite they are entitled to:

• Send old equipment for recycling on a one-for-one, like-for-like basis (this varies depending on the country)
• Send the new equipment back for recycling when this ultimately becomes waste

Tripp Lite has a policy of continuous improvement. Product specifications are subject to change without notice.

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

17-11-342 93-330C_RevB
